SELECTRONIC
I.C. Faucet
Certified to comply with:
• ASME A112.18.1
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Selectronic
or e-mail us at: CRTTEAM@americanstandard.com
For Parts, Service, Warranty or other Assistance,
please call (844) CRT-TEAM / (844) 278-8326 (In Canada: 1-800-387-0369)
© 2019 AS America Inc.
®
I.C. Faucet shown installed on
American Standard 9118.111 Sink
(In Toronto Area only: 1-905-306-1093)
CAUTION: Use only American Standard supplied
transformers and cable sets. Using non-AS
supplied cables, or cutting, splicing or modifying
any components will void the warranty.
Product No.'s & Options
Specifications
Faucet Installation
Electrical Installation
Start-up / Maintenance
FAQ's / Troubleshooting
Parts
Products visit our website at: www.americanstandard-us.com
®
1
MODEL NUMBERS
6053.193
6055.193
605B.193
1
2
2-3
4-6
7-8
9-10
11
M965651 Rev. 2.0 (3/19)
Advertisement
Related Manuals for American Standard SELECTRONIC 6053.193
Summary of Contents for American Standard SELECTRONIC 6053.193
- Page 1 Parts Certified to comply with: • ASME A112.18.1 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Selectronic Products visit our website at: www.americanstandard-us.com ® or e-mail us at: CRTTEAM@americanstandard.com For Parts, Service, Warranty or other Assistance,...
- Page 2 Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly--please read these instructions carefully before you begin. All American Standard Products Are Water Tested At Our Factory. UNPACKING Some Residual Water May Remain In The Valve During Shipping The illustration below shows the fitting and all loose items after they have been removed from the carton.
-
Page 3: Faucet Installation
2-1/8" DIA. 5-1/4" 5-1/4" MOUNTING MOUNTING and standards. SURFACE SURFACE CAUTION: Use only American Standard supplied 60mm 60mm transformers and cable sets. Using non-AS supplied cables, (2-3/8) MAX. (2-3/8) MAX. 125mm 125mm or cutting, splicing or modifying any components will void... - Page 4 Fig. 2 21" (533mm) NOTE: The illustration shows the Infection Control faucet mounted on the American Standard Infection Control Sink. Faucet can be installed on any sink or countertop. For futher instructions regarding faucet installation on the 14" American Standard Infection Control Sink, see instruction...
-
Page 5: Electrical Installation
Fig. 1d. 6. Reinstall CONTROL BOX COVER (1). Tighten cover screws firmly. Fig. 1d CAUTION: Use only American Standard supplied cable sets. STANDARD Using non-AS supplied cables, or cutting, splicing or modifying BATTERY any components will void the warranty. - Page 6 6b. Connect the10' EXTENSION (10b) to the POWER Fig. 2c SUPPLY CABLE (15). Fig. 2c. 10' EXTENSION CAUTION: Use only American Standard supplied cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty. BLACK & WHITE...
- Page 7 Max. of 15 Units on one AC POWER SUPPLY. 7. Reinstall CONTROL BOX COVERS. Tighten cover screws firmly. CAUTION: Use only American Standard supplied transformers and cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty. M965651 Rev. 2.0 (3/19)
-
Page 8: Maintenance
TEST INSTALLED FAUCET Fig. 1 TO ENSURE A LAMINAR WATER FLOW, the air must be slowly purged from the spout. To do so, cover the SENSOR (1) while slowly opening the water supply valves. When the water flows as a solid, smooth, steady stream, uncover the SENSOR (1) and fully open the water supply valve. - Page 9 INSTALL / REPLACE THE BATTERY or Fig. 4 PWRX BATTERY PACK; Fig. 4 STANDARD 1. Remove CONTROL BOX COVER (1). BATTERY 2. Disconnect Battery Holder (3) from CABLE (5). 3. Remove old BATTERY from Battery Holder (3). Install new BATTERY (2) making sure the terminal side is inserted first and shape of the battery follows the shape of the BATTERY HOLDER (3).
- Page 10 GENERAL CLEANING; Fig. 5 Fig.6 1. Only use a damp, soft cloth to clean the spout and the sensor. 2. For tougher dirt, use a soft cloth with diluted dish washing detergent. Wipe the area using a wet cloth. Do not scratch the sensor when cleaning. Avoid using CAUTION any abrasives or harsh detergents or chemicals.
-
Page 11: Troubleshooting Flowcharts
IN CANADA 1-800-387-0369 (TORONTO 1-905-306-1093) Weekdays 8:00 a.m. to 7:00 p.m. EST Pro du ct names listed herein are trademark s of AS America, Inc. ©2019 To learn more about American Standard Selectronic ® Products visit our website at: www.americanstandard-us.com or e-mail us at: CRTTEAM@lixilamericas.com M965651 Rev.
