Platinum Series II
2200 NG
Platinum Series II
3200 NG
WARNING: Do not operate this barbecue
without reading the entire operating guide.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Follow all leak check
procedures carefully in this manual prior to
barbecue operation. Do this even if
barbecue was dealer assembled.
PLATINUM
Natural Gas Barbecues
SERIES II
™
Step-By-Step Guide
Platinum Series II
3400 NG
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
gas supplier or your fire department.
CANADIAN GAS ASSOCIATION
®
A P P R O V E D
R
97461
12/96
Advertisement
Table of Contents
Related Manuals for Weber PLATINUM SERIES 2 2200 NG
Summary of Contents for Weber PLATINUM SERIES 2 2200 NG
- Page 1 Platinum Series II 2200 NG Platinum Series II 3200 NG WARNING: Do not operate this barbecue without reading the entire operating guide. THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. WARNING: Follow all leak check procedures carefully in this manual prior to barbecue operation.
-
Page 2: Install Gas Supply
INSTALL GAS SUPPLY General Specifications for Piping Note - Contact your local municipality for building codes regulating outdoor gas barbecue installations. In absence of Local Codes, you must conform to the latest edition of ANSI Z223.1. WE RECOMMEND THAT THIS INSTALLATION BE DONE BY A PROFESSIONAL. Some of the following are general requirements taken from ANSI Z223.1, for gas supply installations. -
Page 3: Tools Needed
While we give much attention to our products, unfor- tunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual and serial number of the barbecue available for reference. - Page 4 REMOVE GRILL FROM LOWER PACKAGING Make sure natural gas hose is free from lower packaging before lifting. WARNING: Lifting the barbecue from the lower packaging requires at least two people. With two people lift straight up and over lower packaging and cardboard support.
-
Page 5: Flavorizer Bars
INSTALLATION OF CATCH PAN INTO BOTTOM TRAY Hook the ends of the catch pan holder into the hole in the bottom tray. Figure 4. The front of the catch pan holder must be on the same side as the finger grip of the bottom tray. - Page 6 REINSTALLATION OF COOKING GRATES Note: The cooking grates are already in place. This stepp is for reinstallation only. Set the cooking grates onto the ledges in the cooking box. The open "U" of the cooking grate goes down. Figure 7. Figure 7 REINSTALLATION OF WARMING RACK...
-
Page 7: Install Warm-Up Basket
INSTALL WARM-UP BASKET Insert one end of the Warm-Up Basket into the hole in the right end of the lid and the other end into the slot in the left end of the lid. Figure 9. Figure 9 If you have the Platinum Series II 2200, go to step “Install Work Surfaces”... - Page 8 INSTALL WORK SURFACES FOR THE PLATINUM SERIES II 2200 You will need...left work surface, right work surface, four 1/4-20 x 1/2 inch bolts, four nylon washers and a 7/16 inch or adjustable wrench. Insert the left work surface tabs in the slots to the left of the cooking box.
- Page 9 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3200 (CONTINUED) Route the side burner hose around the tank panel so it will not interfere with the scale indicator rod. The side burner hose is connected in the following manner: Slide back the collar of the quick disconnect on the manifold.
- Page 10 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3400 You will need... left work surface, side burner assembly, four 1/4-20 x 1/2 inch bolts, four nylon washers and a 7/16 inch or adjustable wrench. Insert the left work surface tabs in the slots to the left of the cooking box.
- Page 11 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3400 (CONTINUED) Route the side burner hose so it will not interfere with the scale indicator rod. The side burner hose is connected in the following manner: Slide back the collar of the quick disconnect on the manifold.
-
Page 12: Check That All Burner Valves Are Off
INSTALL BOTTOM RACK Place the bottom rack between the frame supports. Figure 21. Figure 21 For the Platinum Series II 3400, place the bottom rack under the cart between the frame supports. Lift up one end of the rack so that it clears the crosspiece. Continue to lift until the opposite end clears the opposite crosspiece. -
Page 13: Check For Gas Leaks
CHECK FOR GAS LEAKS WARNING This gas connections of your Weber Gas Barbecue have been factory tested. We do however recommend that you leak check all gas connections before operating your Weber Gas Barbecue. Remove the knobs from the control panel. Figure 24. - Page 14 CHECK FOR GAS LEAKS WARNING: Do not ignite burners while checking for leaks. Check for leaks by wetting the connections with the soap and water solution and watching for bubbles. If bubbles form or if a bubble grows there is a leak. Check: a) Hose to manifold connection.
- Page 15 REINSTALL THE CONTROL PANEL Set the control panel in place over both frame braces. (Hold the Crossover Ignition button up while setting the control panel in place.) Slip washers on Phillips screws, insert into holes as shown, and tighten. Figure 27 (a). Push on the burner control knobs.
