Viking Use/Installation Guide
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
24" Wide Undercounter/Freestanding
vikingrange.com
Refrigerated Beverage Center
F20347B EN
(030508J)
Advertisement
Table of Contents
Related Manuals for Viking 24" W. Undercounter/Freestanding Refrigerated Beverage Center
Summary of Contents for Viking 24" W. Undercounter/Freestanding Refrigerated Beverage Center
- Page 1 Viking Use/Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at 24” Wide Undercounter/Freestanding vikingrange.com Refrigerated Beverage Center F20347B EN (030508J)
-
Page 2: Important - Please Read And Follow
IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty. • Please observe all local and national codes and ordinances. •... -
Page 3: Specifications & Dimensions
SPECIFICATIONS/DIMENSIONS DESIGNER SERIES Basic Electric Data •115 VAC/60 Hz •Maximum amps - 3.3 •Approximate shipping weight - 140 lbs (63.2 kg) 30 3/4” (78.1 cm) Side View DUAR 47 1/4” (120.0 cm) Side View DFUR 22” (55.9 cm) 24 3/8” (61.9 cm) 25 3/8”... - Page 4 CUSTOM WOOD FRAME INSTALLATION INSTRUCTIONS (DFUR MODEL) Note: Weight of wood panel must not exceed 20 lbs. Wood Screws 1. A #10 pan head wood screw should be used to properly secure the wood frame. A total of 10 screws will be needed for a 3 1/2”...
-
Page 5: Leg Leveler Installation
Attaching the Handle Attach the handle of your choice by drilling mountingholes through panel. Countersink or counterbore holes from back side of panle for handle screw heads to be flush Attaching the Wood Frame to the Door (DFUR MODEL) 1. If the door is attached to the unit, remove by unscrewing the top allen head set screw at the top hinge. Remove the door by angling the door off of the bottom hinge pin. -
Page 6: Final Preparation
FINAL PREPARATION 1. Some stainless steel parts may have a plastic protective wrap which must be peeled off. The interior of the refrigerated beverage center should be washed thoroughly with hot, soapy water, rinsed and wiped dry to remove film residue and any installation dust or debris before being used. -
Page 7: Cleaning And Maintenance
•Name of dealer from whom purchased If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking at (888) 845-4641 or write to: VIKING PREFERRED SERVICE 111 Front Street Greenwood, Mississippi 38930 USA Record the following information indicated below. -
Page 8: One Year Full Warranty
Any sealed refrigeration system component, as listed below, is warranted to be free from defective materials or workmanship in normal household use during the second through the fifth year from the date of original retail purchase. Viking Range Corporation, warrantor, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period.
