ADC PowerWorx Power Distribution User Manual page 11

REAR COVER FOR OUTPUT POWER TERMINAL BLOCKS,
ALARM TERMINALS, AND CHASSIS GROUND TERMINALS
REAR COVERS FOR INPUT
POWER TERMINAL BLOCKS
DESIGNATION CARD,
PROTECTIVE COVER,
AND CARD HOLDER
AND SCREWS FOR 19-INCH OR
Figure 2. Packaged Hardware Components
12-10 AWG WIRE (GROUNDING)
5/16-INCH (7.936 MM) 8-32
RACK MOUNTING
BRACKETS
3/8-INCH (9.525 MM) 12-24
SCREWS AND #12 WASHERS
RACK MOUNTING
BRACKETS
MOUNTING BRACKETS
23-INCH RACK INSTALLATION
ADCP-80-575 • Issue 2 • December 2006
#10 RING TERMINALS FOR
FLAT-HEAD SCREWS
19-INCH
23-INCH
