Optional ExaMax/Interlaken Hardware Setup
Connect a USB Type-A to Micro-B
cable to the USB UART connector
on
both
VCU110 boards
Connect a USB Type-A to Micro-B
cable to the USB JTAG (Digilent)
connector on
both
VCU110
boards
– Connect these four cables to your
PC
Note: Presentation applies to the VCU110
