VCU110 Hardware Setup
SMA Connector
– http://www.amphenolconnex.com
– Part # 132169
– Connect BullsEye cable:
– 003-005 and 004-006 (Link 3)
– 007-009 and 008-010 (Link 2)
– 011-013 and 012-014 (Link 1)
– 015-017 and 016-018 (Link 0)
Connect GTY Ref Clock to 175 MHz clock source (not included)
– Connect to BullsEye Clocks:
– 019 and 020 (GTY Ref Clock)
Note: Presentation applies to the VCU110
