Chamberlain CPS-OPEN4 Quick Start Manual

Weatherproof, Durable and Dependable
®
LiftMaster's CPS-OPEN4 Monitored Dual-Sided Photo Eyes are weatherproof
and durable. The flexible rubber housings absorb minor contact allowing the
photo eyes to maintain alignment. With its NEMA 4X safety rating, the CPS-
OPEN4 provides moisture protection, corrosion resistance, making it the perfect
addition to LiftMaster's quality line of safety sensors. Our photoelectric eyes and
edge sensor models are UL/cUL Listed for use with all LiftMaster Commercial
Door Operators. The CPS-OPEN4 can be used as a primary and/or ancillary
entrapment device and meets UL 325 2010 safety standards.
Flexible housing maintains alignment position after minor contact
•
NEMA 4X enclosure protects against direct water–spray and corrosion
•
Dual-sided infrared sensors
•
For indoor/outdoor use
•
Maximum range of 45 feet
•
Solid sensor lights indicate correct sensor alignment
•
Polarized cables for proper signal continuity and feedback
•
UL 325 requires all commercial door operators to be either constant pressure to
close or be equipped with a primary external monitored entrapment protection
device. The CPS-OPEN4 meets this requirement. Failure to use the appropriate
sensor or failure to install the sensor properly, may expose the installer and
customer to liability, should an accident occur.
LiftMaster's full line of Monitored Photo Eyes
CPS-UN4 CPS-RPEN4
LiftMaster.com
CPS-OPEN4
CPS-OPEN4 CPS-U
MONITORED DUAL-SIDED PHOTO EYES
Available Accessories:
Interface Card
(CPS3CARD)
Provides the option of adding a
second set of monitored photo
eyes or a monitored edge to a
door opening. For extra door
protection.
