FT2-700-ELEC Series
FlipTop™ FT2 Series, 700 Size, Electrical
The Crestron®
FT2-700-ELEC
and the
management systems install into a table or other horizontal surface to
provide modular tabletop connectivity for users. The FT2-700-ELEC
series feature a one touch lid that retracts fully and disappears with the
tap of a button. When the lid is retracted, 12 module slots are arranged in
two rows of six. The flexible modular design may also be customized with
an assortment of Crestron accessories. For more information about the
accessories, please visit www.crestron.com/Crestron-FlipTops.
The FT2-700-ELEC Series features a built in electrical power bus, which
enables compatibility with one-touch cable retractors, active connector
plates, and USB rapid charging modules. It also enables backlighting of
the symbol icons on all retractors, connector plates, and USB charging
modules.
The FT2-700-ELEC-PTL offers an alternative pass-through lid style
which allows cables to be fully extended while the lid is closed.
The FT2-700-ELEC and the FT2-700-ELEC-PTL are functionally similar.
For simplicity within this document, they are both referred to as the
"FT2-700 assembly."
FT2-700-ELEC-PTL
FlipTop™ cable
In the Box
1
FT2-700-ELEC, FlipTop™ FT2 Series, 700 Size, Electrical
Additional Items
3
Bars, Locking, with Screws (P/N 4528906)
1
Cable, DC Power Splitter (P/N 2050094)
1
Holder, Power Supply (P/N 2048887)
4
Module, Blank Plate (P/N 2049602)
8
Module, Pass-Through Cable (P/N 4526880)
1
Power Cord, 5 ft 10 in. (1.78 m) (P/N 2042043)
1
Power Pack, 24 VDC, 2.5 A, 100-240 VAC (P/N 2045873)
4
Spacer, Plastic, FT2-700 (P/N 2050568)
1
Template, Cutout (P/N 4527491)
FT2-700-ELEC-AL Only
1
Bezel, FT2-700, Alloy (P/N 4529321)
FT2-700-ELEC-PTL-AL Only
1
Bezel, FT2-700, Pass-Through Lid, Alloy (P/N 4531563)
FT2-700-ELEC-PTL-B Only
1
Bezel, FT2-700, Pass-Through Lid, Black (P/N 4531562)
FT2-700-ELEC-B Only
1
Bezel, FT2-700, Black (P/N 4529320)
Quick Start
1
Advertisement
Related Manuals for Crestron FT2-700-ELEC Series
Summary of Contents for Crestron FT2-700-ELEC Series
- Page 1 Additional Items accessories, please visit www.crestron.com/Crestron-FlipTops. Bars, Locking, with Screws (P/N 4528906) The FT2-700-ELEC Series features a built in electrical power bus, which Cable, DC Power Splitter (P/N 2050094) enables compatibility with one-touch cable retractors, active connector Holder, Power Supply (P/N 2048887) plates, and USB rapid charging modules.
- Page 2 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical Replace the FT-600 FlipTop Assembly An FT2-700 assembly may replace an FT-600 FlipTop assembly and use Mount the FlipTop Assembly the existing mounting hole. The FT-600 FlipTop assembly mounting hole is larger than the mounting hole required for the FT2-700 assembly.
- Page 3 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical Secure the FlipTop Assembly 2. On the underside of the FT2-700 assembly, locate the power bus and connect the dual-connector ends of the DC power splitter to the two To prepare the FT2-700 assembly and secure it to the table surface: barrel jacks of the power bus.
- Page 4 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical 4. Carefully tighten the four swiveling dogs in each corner of the FlipTop assembly clockwise until the FT2-700 assembly is secured in place against the table. Do not overtighten the swiveling dogs.
- Page 5 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical To connect the power supply to the power bus: 4. Align the four keyed tabs on the power supply holder with four keyed slots on the FT2-700 assembly. Then, push the power supply holder up 1.
-
Page 6: Install The Modules
Installation procedures for most modules are available in separate product documentation. For more information, refer to the specific product manual located at www.crestron.com/manuals. The following sections provide best practices and installation procedures for pass- through cable modules and blank plate modules. - Page 7 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical Installing the Pass-Through Cable Module with 4K Cables 3. Attach the side plate to the module by snapping the plastic clips on the plate into the two slots on the module.
- Page 8 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical 5. Insert the cable plate into one of the three slots in the pass-through 6. Attach the side plate to the module by snapping the plastic clips on the module. Choose the appropriate slot based on the length of the cable plate into the two slots on the module.
- Page 9 Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical Blank and Keystone Plate Modules Install the Locking Bars 1. Position the locking bars so that the screws attached to the locking bars engage the screw holes in the FT2-700 assembly.
-
Page 10: Install The Bezel
Quick Start FT2-700-ELEC Series FlipTop™ FT2 Series, 700 Size, Electrical Install the Bezel Operate the FlipTop Assembly Place the bezel onto the FT2-700 assembly so that the retractable lid fits To operate the FT2-700 assembly: inside the bezel opening. The bezel is held in place using magnets. - Page 11 Service Providers (CSPs) under a limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. www.crestron.com/model/6509653 The product warranty can be found at www.crestron.com/warranty.
