Installation - Operation - Maintenance Instructions - Repair Parts
READ THIS ENTIRE MANUAL, THOROUGHLY, BEFORE ATTEMPTING TO INSTALL AND/OR
BURN YOUR NEW AMERICAN HARVEST CORN AND PELLET MULTI-FUEL STOVE. FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURIES
Safety Notice: If this stove is not properly installed, a house fire may result.
For your safety, follow the installation directions. Contact local building or fire officials
about restrictions and installation requirements peculiar to your area. Do Not Plug
this appliance into an electrical outlet before reading and understanding all operations
and always unplug the unit before attempting any work or maintenance. Do not
connect this stove to any chimney flue already serving another appliance. Carefully
observe and maintain all clearances to combustibles.
A note about fuel: Use only dried shelled corn with a moisture content of 14%
or less (11 to 12% provides the best results); any pellet fuel used should have
an ash content of 1% or less. If not, efficiency will suffer, and your warranty may be
voided.
Your American Harvest Corn/Pellet Stove operates on a negative pressure. Therefore,
all venting connections (elbows, T-pipe) must be sealed and airtight.
Use Hi-Temp silicone at each joint or connection.
UNITED STATES STOVE COMPANY GRANTS NO WARRANTY, IMPLIED OR STATED,
FOR THE INSTALLATION OR MAINTENANCE OF THE STOVE AND ASSUMES NO
RESPONSIBILITY FOR ANY CONSEQUENTIAL DAMAGE(S).
UNITED STATES STOVE COMPANY - 227 INDUSTRIAL PARK ROAD-SOUTH PITTSBURG, TN. 37380
USSC
K e e p i n g
K e e p i n g
K e e p i n g
K e e p i n g
K e e p i n g
America
America
America
America
America
1 8 6 9
1 8 6 9
1 8 6 9
1 8 6 9
1 8 6 9
MULTIFUEL STOVE
6039, 6039I, 6039T
OWNER'S MANUAL
OR EVEN DEATH.
SAVE THESE INSTRUCTIONS
TECHNICAL ASSISTANCE (423) 837-2100 - (423) 837-2109 FAX
Warm
Warm
Warm
Warm
Warm
Since
Since
Since
Since
Since
851621E
1
Advertisement
Table of Contents
Related Manuals for United States Stove American Harvest 6039I
Summary of Contents for United States Stove American Harvest 6039I
- Page 1 UNITED STATES STOVE COMPANY GRANTS NO WARRANTY, IMPLIED OR STATED, FOR THE INSTALLATION OR MAINTENANCE OF THE STOVE AND ASSUMES NO RESPONSIBILITY FOR ANY CONSEQUENTIAL DAMAGE(S). UNITED STATES STOVE COMPANY - 227 INDUSTRIAL PARK ROAD-SOUTH PITTSBURG, TN. 37380 TECHNICAL ASSISTANCE (423) 837-2100 - (423) 837-2109 FAX USSC...
-
Page 2: Specifications
We strongly suggest installing smoke detectors in your home if not already installed. Initial burn off may cause slight smoke and odor the first few hours of operation. United States Stove Company reserves the right to alter products, specifications and price without notice. - Page 3 6039 PEDESTAL TRIM ASSEMBLY Assemble trim pieces as shown with the screws provided in the parts bag. USSC ASSEMBLY 1. The Auger is packed in the hopper or ash pan and must be installed properly as illustrated below. 2. Insert the Auger into the auger tube. Rotate the auger until it fits into the coupling that is already installed on the auger motor drive.
- Page 4 6039I ASSEMBLY DISCONNECT THE POWER CORD BEFORE SERVICING THIS STOVE For the following assemblies, we suggest locating the unit near it’s desired location. Depending on installation, you may want to connect the exhaust venting before installing the facade parts. Assembly - Facade (Surround)
-
Page 5: Component Location
COMPONENT LOCATION USSC... -
Page 6: Safety Steps
IMPORTANT: Proper installation of this stove is necessary for safe and efficient operation. Installing this product improperly may result in a house fire and personal injury. All applicable building codes for your location must be followed. In areas where building codes require additional steps to the installation of this product not included in this manual, the building codes will take precedent and must be followed. -
Page 7: Shelled Corn
BURNING SOLID FUELS SHELLED CORN • Corn must contain less than 14% moisture content. Wet corn will rapidly deteriorate stove components, reduce efficiency and void all warranties. Purchase a moisture tester if in doubt. • Corn must be clean and free from debris. Never burn corn right from the field. Damage caused by dirty corn is not covered by the product warranty. -
Page 8: Hearth Protection
CLEARANCES TO COMBUSTIBLES 6039(T) The stove must be installed with the following minimum clearances to side and back wall combustible materials. NOTE: These are minimum clearances to combustible walls established by the testing lab. PARALLEL - A - Sidewall to Top Edge of Unit B - Sidewall to Flue C - Backwall to Flue D - Backwall to Unit... - Page 9 CLEARANCES TO COMBUSTIBLES 6039I USSC...
-
Page 10: Guidelines For Exhaust Venting Systems Design
GUIDELINES FOR EXHAUST VENTING SYSTEMS DESIGN It is recommended that only an authorized installer install your pellet/corn stove, preferably an NFI certified specialist. The following installation guidelines must be followed to ensure conformity with both the safety listing of this stove and to local building codes. -
Page 11: Design Guidelines For Outside Combustion Air Connection
DESIGN GUIDELINES FOR OUTSIDE COMBUSTION AIR CONNECTION For installations with horizontal through-the-wall exhaust, it is strongly recommended that the stove combustion air be connected to the outside. If the home is newer or has been tightly insulated, it is required to install outside combustion air. -
Page 12: Installation Configurations
The American Harvest Multifuel Stove Model 6039/6039T may be installed as follows: 1) A freestanding unit The American Harvest Multifuel Stove Model 6039I insert may be installed as follows: 1) In a pre-fab firebox (Factory Built) 2) In an existing masonry fireplace... - Page 13 Note: Always check dimensions on unit before cutting hole in wall 3" PL Vent Termination Cap 3" PL Vent 90° Elbow 3" PL Vent (12" Long) 3" PL Tee w/ Cleanout 3’ Minimum 3" PL Vent (12" Long) Vertical Pipe 3"...
- Page 14 THROUGH THE WALL, VERTICAL PIPE INSTALLATION WITH TERMINATION CAP The Hearth Pad is not required under the unit if the floor is noncombustible but is required 6 inches (152mm) beyond the front of the unit and 6 inches (152mm) beyond each side of the door if the floor is a combustble floor. wood flooring, carpet, linoleum, etc.
- Page 15 DESIGN GUIDELINES FOR 6039I INSERT INSTALLATION INSTALLATION AS A BUILT-IN FIREPLACE A continuous sheet of non-combustible floor protection must be installed underneath the unit to prevent the possibility of embers falling through to the combustible floor. If the floor beneath the unit is of non-combustible material, the protector is not required.
-
Page 16: Installation Into A Masonry Fireplace
DESIGN GUIDELINES FOR 6039I INSERT INSTALLATION INSTALLATION INTO A MASONRY FIREPLACE When installing into a masonry fireplace, DO NOT remove any bricks or masonry, with the following exception: masonry or steel, including the damper plate, may be removed from the smoke shelf and adjacent damper frame, if necessary, to accom- modate a chimney liner. -
Page 17: Cleaning The Glass
GLASS MAINTENANCE, REMOVAL AND REPLACEMENT Your American Harvest Multifuel Stove comes to you with the glass door installed in place, ready for use. The glass is surrounded on the edges with a gasket and seated in a glass channel. It is held in place with two (2) clips. REMOVAL OF BROKEN OR DAMAGED CERAMIC GLASS Open the door and lift off of hinges. -
Page 18: Understanding The Control Board
American Harvest heater. The insert model 6039I is located on the left facade. This unit can be changed between an automatic operation or a manual operation. -
Page 19: Lighting Instructions
LIGHTING INSTRUCTIONS CAUTION: DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN BURNS. Before lighting your heater for the first time, make sure that all items are out of the hopper, ash pan and firebox area. -
Page 20: Disposal Of Ashes
The clinkers on the agitator and burnpot are easily removed when soaked in warm water for 10 minutes. • The ash pan (especially the model 6039I) should be cleaned out on a daily basis or as needed depending ash build-up. SPECIAL CLEANING/OPERATIONAL... -
Page 21: Spring Cleaning
Weekly Maintenance • Shut down the stove as directed in the operating instructions. Allow the stove to cool to room temperature. Remove the small clean-out slides in the lower corners of the firebox. Tap the sides of the burn chamber with a wooden stick. Do not tap the firewall behind the burn box as it may damage the ceramic firebrick. -
Page 22: Circuit Board Functions
CIRCUIT BOARD FUNCTIONS Once the control panel is turned to on, a timer begins that will start, stop and continue operation of the American COMPONENT Draft Fan Agitator Auger Room Fan Automatic Shutdown Normal Operation Once the Heater has reached the normal operating temperature and switched to the “OFF” position, the unit will continue to operate on a much lower setting for 10 minutes. - Page 23 ERROR CODES and DISPLAY INDICATORS CAUTION: When performing any internal electrical maintenance • Moving parts inside of the cabinet may cause injury. Do not operate unit with panels removed or open. • HOT parts. Do not operate the unit with panel open. •...
-
Page 24: Troubleshooting
Unplug stove before performing any maintenance PROBLEM ? Fire burns with a lazy, orange flame and/or fuel builds up in the firepot. Glass may become dirty. ? Fire goes out or stove shuts down. Fuel may stop feeding. ? Fire goes out or stove shuts down. Fuel may stop feeding. -
Page 25: Wiring Diagram
WIRING DIAGRAM USSC... - Page 26 REPAIR PARTS DIAGRAM-6039 USSC...
- Page 27 PART # 69516 25080MB 25409MB 69508MB 25451MB 69478MB 891138 25493 25468MB 25471MB 25472MB 25411MB 25412MB 25413MB 25448 25447 69477MB 69503MB 891125 69499 88116 88114 69498 88100 80473 80456 83511 83533 891136 88106 80472 80507 80488 88111 83534 25422 891132 86620 83901 25427 80381...
- Page 28 REPAIR PARTS-6039I USSC...
- Page 29 25582MB 891435 891135 891331 891299 For all other repair components not listed above, refer to the 6039 Repair list and USSC REPAIR PARTS LIST-6039I DESCRIPTION Pad, Door Hinge(Threaded) Weldment, Sub-Base Bracket, Caster Caster, Plastic 1/4-20 x 1-1/2 Hex Bolt Washer...
- Page 30 Part No. Descritption 25491 Feed Door 25492 Handle, Door 83506 Roll Pin, 3/8 x 1-1/4 88112 Gasket, 1/2” Sq. Rope 88087 Gasket, Glass (1 x 3/16) 891131 Glass Ceramic 6039T Parts Diagram & List NOTE: For internal parts, cabinet parts, etc. see pages 21-22 Part No.
- Page 31 Notes USSC...
-
Page 32: How To Order Repair Parts
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION AS SHOWN IN THIS LIST: 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 6039 6039I 6039T 4. THE SERIAL NUMBER:____________________ HOW TO ORDER REPAIR PARTS United States Stove Company 227 Industrial Park Road P.O.
