Page 1: Cleaning Instructions
® Cleaning Instructions, Pilot Replacement and Valve Change Model No.: 233010 Natural Gas... -
Page 2: Tools Required
1. Installation and repair should be done by a qualified service person. 2. Use only Blue Rhino Global Sourcing, LLC. factory authorized parts. The use of any part that is not factory authorized can be dangerous. This will also void your warranty. - Page 3 ® For assistance call 1.800.762.1142. Steps 1-4 1. Turn gas supply off and disconnect from gas supply. Important: make sure your gas supply is off. 2. Remove dome. 3. Remove engine from post. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 4 ® For assistance call 1.800.762.1142. Step 5 Remove the three bolts which secure the emitter to the emitter bottom using a 9mm wrench. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 5 ® For assistance call 1.800.762.1142. Step 6 1. Clean the carbon build-up off the inside of the emitter bottom with a non-abrasive scouring pad or bottle brush. Clean the outside of the emitter bottom with the scouring pad. 2. Use the air compressor to blow away any excess soot. DANGER: Never use any flammable solutions or material to clean heater or heater parts.
- Page 6 ® For assistance call 1.800.762.1142. Step 7 Disconnect the pilot supply tube using #10 open-ended wrench. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 7 ® For assistance call 1.800.762.1142. Step 8 Disconnect the burner supply tube from the control valve using 5/8” open-ended wrench. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 8 ® For assistance call 1.800.762.1142. Step 9 1. Disconnect the burner from the emitter bottom by removing the 2 phillips screws on the bottom of the emitter bottom. 2. Carefully remove the burner. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 9 Disconnect the thermal couple wire from the control valve: 1. Remove the screw that holds the access panel to the housing. 2. Remove the nut from the back of the control valve using 8 mm open-ended wrench. Note: Be very careful not to damage any wires. Cleaning burner, pilot replacement and valve change.
- Page 10 Remove the heat and pilot shield from the emitter bottom. 1. Remove the 4 screws in emitter bottom. Note: 2 screws are near pilot opening, and 2 screws are on the back side of the emitter bottom. 2. Lift the heat shield assembly out. Note: Be very careful not to damage any wires.
- Page 11 1. Remove the pilot assembly by removing the 2 screws that hold the pilot assembly in place Note: you may need to use a pair of needle nose pliers to hold the nuts in place. 2. If replacing the pilot: A.
- Page 12 ® For assistance call 1.800.762.1142. Step 13 1. Remove the orifice by placing the 12 mm open-ended on the pilot orifice and the 10 mm open-ended on the hex tube just below the pilot hood. 2. Use a pipe cleaner to clean both the inside and outside of the pilot orifice. 3.
- Page 13 ® For assistance call 1.800.762.1142. 1. Use a heavy-duty pipe cleaner to clean the bottom of the black hex tube on the pilot assembly. Make sure to extend the pipe cleaner past the silver hood. 2. Clean the port at the side of the pilot hood with a heavy-duty pipe cleaner. 3.
- Page 14 ® For assistance call 1.800.762.1142. Step 14 Insert bottle brush into venturi tube and give a couple of twists. This will clear any debris or spider webs from the venturi tube. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 15 ® For assistance call 1.800.762.1142. Step 15 1. Insert a heavy-duty pipe cleaner into each burner port to clean them. Use a non-abrasive scouring pad to clean the outside of the burner. 2. Using an air hose or can of compressed air to blow any excess soot from the burner ports and the venturi tube. 3.
- Page 16 ® For assistance call 1.800.762.1142. Step 16 If this is all you need to do then follow instructions in reverse to reassemble heater. If not, please continue. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 17 Replacing the control valve: 1. Remove the control valve by removing the 3/4” brass nut on the front side of the valve housing. 2. Push the control valve back and pull it out from the front of the valve housing. Note: Be careful not to damage the pilot supply tube.
- Page 18 ® For assistance call 1.800.762.1142. 4. Attach the pilot supply tube to the new control valve 5. Install the new control valve. Note: Make sure the valve is secure. 6. Reattach the 3/4” brass nut. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 19 ® For assistance call 1.800.762.1142. Step 18 1. Place pilot assembly with heat shield into the emitter bottom 2. Attach the pilot supply tube to the pilot. 3. Tighten the screws that hold the guard in place. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 20 ® For assistance call 1.800.762.1142. Step 19 1. Reinstall the thermal couple by attaching the nut on the back of the control valve, using the 8 mm open-end wrench. Note: Finger tighten the nut, plus a 1⁄4 turn 2. Reinstall the access panel. Cleaning burner, pilot replacement and valve change.
- Page 21 ® For assistance call 1.800.762.1142. Step 20 Insert the burner and burner supply tube, secure into place with screws. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 22 ® For assistance call 1.800.762.1142. Step 21 Attach the burner supply tube nut on the control valve. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 23 ® For assistance call 1.800.762.1142. Step 22 Attach the three bolts which secure the emitter to the emitter bottom using a 9mm wrench. Cleaning burner, pilot replacement and valve change. Model No. 233010 Natural Gas 501310...
- Page 24 23. Attach the engine to the post 24. Burner Connections 1. Make sure the regulator valve and hose connections are securely fastened to the burner and the tank. 2. If your unit was assembled for you, visually check the connection between the burner pipe and orifice.
- Page 25 Step 27 - IMPORTANT Perform leak check. If you smell gas - 1. Shut off gas to appliance. 2. Extinguish any open flame. 3. If odor continues, immediately call your gas supplier or your fire department. 1. Do not operate if gas leak is present. Gas leaks may cause a fire or explosion. 2.
- Page 26 Gas Line Connection 1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are off. 3. Turn gas source ON at valve. 4. Spoon leak check solution onto gas line and control valve connections. 5.
- Page 27 1.800.762.1142, www.bluerhino.com © 2004 Blue Rhino Global Sourcing, LLC All Rights Reserved. ® Endless Summer is a registered trademark of Blue Rhino Global Sourcing, LLC All Rights Reserved. ® Blue Rhino is a registered trademark of Ferrellgas, L.P. All Rights Reserved.
