Stamina 1735 Owner's Manual

Full body power tower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on the pull-up bar, dip station, VKR,
and push-up stand not to exceed 300 lbs.
Weight on the bench not to exceed 400 lbs
including user and weights.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 50-1735
S/N: _____________
STAMINA PRODUCTS
MADE IN CHINA
©
2018 Stamina Products, Inc.
2018, 12

Advertisement

Table of Contents
loading

Related Manuals for Stamina 1735

Summary of Contents for Stamina 1735

  • Page 1 Weight on the bench not to exceed 400 lbs including user and weights. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N Alliance Ave, Springfield, MO 65803 Customer Care © 2018 Stamina Products, Inc. 1 (800) 375-7520 2018, 12 www.staminaproducts.com...

  • Page 2: Table Of Contents

    17. The Stamina® Full Body Power Tower 1735 should be used by only one person at a time. 18. The Stamina® Full Body Power Tower 1735 is for consumer use only. It is not for use in public or semipublic facilities.
  • Page 3 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Stamina® Full calling for assistance. Body Power Tower 1735. We take great pride Read this manual carefully before using the in producing this quality product and hope it will Stamina® Full Body Power Tower 1735.

  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Stamina® Full Body Power Tower 1735. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels.

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 3 Attach the UPRIGHT SUPPORTS(7) to the BASES(1) on both sides with HEX BOLTS(M8x1.25x35mm) (35) and WASHERS(M8)(37). Attach the UPRIGHT SUPPORTS(7) to the UPRIGHTS(3) on both sides with HEX BOLTS(M10x1.5x65mm)(31), WASHERS(M10)(36), and NYLOCK NUTS(M10x1.5)(38). STEP 4 Insert both of the UPPER UPRIGHTS(5) into the UPRIGHTS(3).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 5 Attach the RIGHT DIP ARM(9) to the UPRIGHT(3) and UPPER UPRIGHT(5) on right side with HEX BOLTS(M10x1.5x65mm)(30), WASHERS(M10)(36), and NYLOCK NUTS(M10x1.5)(38). Repeat on other side. STEP 6 Attach the PULL-UP BAR(12) to the UPPER UPRIGHTS(5) with HEX BOLTS(M8x1.25x85mm)(32), WASHERS(M8)(37), and NYLOCK NUTS(M8x1.25)(39).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 Attach a DIP ARM SUPPORT(10) to the UPRIGHT(3) on right side with HEX BOLT(M10x1.5x65mm)(30), WASHERS(M10)(36), and NYLOCK NUT(M10x1.5)(38). Attach other end of the DIP ARM SUPPORT (10) and ARM CUSHION(18) to the RIGHT DIP ARM(9) with HEX BOLTS(M8x1.25x65mm)(33) and WASHERS(M8)(37).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 9 Refer to the detail view and illustration below. Attach the BENCH SUPPORT(15) to the BENCH FRAME (14) with HEX BOLT(M8x1.25x55mm)(34), WASHERS(M8)(37), and NYLOCK NUT(M8x1.25)(39). Lock the BENCH SUPPORT(15) in position by inserting the PULL PIN(16) through one of the adjustment holes in the U bracket under the BENCH FRAME(14) and the holes in the BENCH SUPPORT(15).

  • Page 12: Storage

    STORAGE 1. To store the Stamina® Full Body Power Tower 1735, simply keep it in a clean dry place. 2. Fold up the bench. Use two people to lift from the back of the BASES(1) and PULL-UP BAR(12) to move the Stamina® Full Body Power Tower 1735.

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 14: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 15: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance Ave, Springfield, Missouri, USA, MO 65803, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 16: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 17: Parts List

    PARTS LIST PART# PART NAME Base Base Cross Bar Upright Serial Decal Upper Upright Upright Cross Bar Upright Support Left Dip Arm Right Dip Arm Dip Arm Support Locking Bar Pull-Up Bar Ankle Support Bench Frame Bench Support Pull Pin Cushion Arm Cushion Foam Pad (ø23 x ø70 x 120mm)

  • Page 18: Notes

    NOTES...

  • Page 19: Fax/Mail Ordering Form

    2040 N Alliance Ave, Springfield, MO 65803 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
