IMPORTANT: Read safety rules and instructions carefully before operating equipment.
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if
any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required
by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark
arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131,
Page 1
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131, Cleveland, Ohio 44136-0019. TROY-BILT LLC., P.O. BOX 361131, CLEVELAND, OHIO 44136-0019 PRINTED IN U.S.A. 20" Mulching Rotary Lawn Mower 770-10755D.fm...
A sample model plate is explained below. For future reference, please copy the model number and the serial number of the equipment in the space below. (Model Number) (Serial Number) TROY-BILT LLC P. O. BOX 3 6 1 1 3 1 www.troybilt.com CLEVELAND, OH 44136...
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
other safety protective devices in place and working. Never operate mower with damaged safety devices. Failure to do so, can result in personal injury. 21. Muffler and engine become hot and can cause a burn. Do not touch. 22. Only use parts and accessories made for this machine by the original equipment manufacturer (O.E.M).
Page 5
meet the original equipment specifications may lead to improper performance and compromise safety!” Mower blades are sharp and can cut. Wrap the blade or wear gloves, and use extra caution when servicing them. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
SECTION 3: ASSEMBLING YOUR LAWN MOWER To Remove Unit From Carton • Remove staples, break glue on top flaps, or cut tape at carton end and peel along top flap to open carton. • Remove loose parts included with your unit (i.e., operator’s manual, etc.).
• With the spark plug wire disconnected and grounded, hold the blade control handle against the upper handle, and pull the starter rope out of the engine. Release the blade control handle. Slip the starter rope into the rope guide. Tighten the wing nut.
SECTION 5: OPERATING YOUR LAWN MOWER WARNING: Keep hands and feet away from the chute area on cutting deck. The blade will be rotating whenever the engine is running. Be sure no one other than the operator is standing near the lawn mower while starting the engine or operating the mower.
SECTION 6: MAKING ADJUSTMENTS WARNING: Do not at any time make any adjustment to your lawn mower without first stopping the engine and disconnecting the spark plug wire. Handle Height Your mower is shipped with the handle in the higher height position.To lower the handle height for your convenience, proceed as follows.
Lubricate Lubricate Bearings Figure 10 WARNING: Be sure to disconnect and ground the spark plug wire before performing any repairs or maintenance. NOTE: When tipping the unit, empty fuel tank and keep engine spark plug side up. Cutting Blade WARNING: When removing the cutting blade for sharpening or replacement, protect hands by using heavy gloves or a rag to grasp...
performance and flooding usually indicates that the air cleaner should be serviced. To service the air cleaner, refer to the engine manual. • The spark plug should be cleaned and the gap reset once a season. Spark plug replacement is recommended at the start of each mowing season;...
Page 13
Safety & Decorative Labels Location (MODEL PLATE ON LEFT SIDE) 777S30143 777S30118 777S30108 777D06000 ON SIDE DISCHARGE DOOR TO REDUCE THE RISK OF INJURY,DO NOT OPERATE UNLESS THIS GUARD IS IN IT'S PROPER PLACE. IF DAMAGED, REPLACE IMMEDIATELY. 20" CUT 6.5 HP...
Page 16
MANUFACTURER’S LIMITED WARRANTY FOR: The limited warranty set forth below is given by Troy-Bilt LLC with respect to new merchandise purchased and used in the United States, its possessions and territories. Troy-Bilt LLC warrants this product against defects for a...
