Pioneer DV-310-S Service Manual
  1. Manuals
  2. Brands
  3. Pioneer Manuals
  4. DVD Player
  5. DV-310-S
  6. Service manual

Pioneer DV-310-S Service Manual

Hide thumbs Also See for DV-310-S:
Table of Contents

Advertisement

Quick Links

DVD PLAYER
DV-310-S
DV-310-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
DV-310-S
WYXZT5
DV-310-S
WSXZT5
DV-310-K
WYXZT5
DV-310-K
WSXZT5
For details, refer to "Important Check Points for good servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION
STANDBY/ON
Power Requirement
AC 220 V to 240V
AC 220 V to 240V
AC 220 V to 240V
AC 220 V to 240V
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
2008
2
3
5
6
7
TOP MENU
MENU
OPEN/CLOSE
ENTER
DVD/USB
USB
HOME
RETURN
MENU
13
12
9
8
DV-310-S
Region No.
2
5
2
5
T-ZZV MAY
ORDER NO.
RRV3756
Remarks
2008 Printed in Japan

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DV-310-S

Summary of Contents for Pioneer DV-310-S

  • Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936...

  • Page 2: Safety Information

    2. When the cover is open, close viewing through the objective lens with the naked eye will cause exposure to the laser beam. ST AN Y/ ON ∗ : See page 26. /C LO D/ US M EN M EN DV-310-S...
  • Page 3 DV-310-S...

  • Page 4: Table Of Contents

    10.8 POWER PCB ASSY(1/2) ............................58 10.9 POWER PCB ASSY(2/2) ............................60 10.10 WAVEFORMS ................................62 11. PCB CONNECTION DIAGRAM ............................64 11.1 DVD MT PCB ASSY..............................65 11.2 OPERATION PCB ASSY ............................67 11.3 POWER PCB ASSY..............................68 11.4 LOADING MOTOR and SW ............................70 12. PCB PARTS LIST ................................71 DV-310-S...

  • Page 5: Service Precautions

    • Soldering time: Within 3 seconds • Soldering combination: Sn-3.0Ag-0.5Cu • When Soldering/Removing of solder, use the draw in equipment over the Pick Up Unit to prevent the Flux smoke from it. Short circuit using a soldering iron. Pick Up PCB Fig. 1 DV-310-S...

  • Page 6: Disc Removal Method

    • Place the unit on a workstation equipped to protect against static electricity, such as conductive mat. • Soldering iron with ground wire or ceramic type is used. • A worker needs to use a ground conductive wrist strap for body. DV-310-S...

  • Page 7: Specifications

    2. SPECIFICATIONS 2.1 ACCESSORIES Accessories • Remote control x1 • Power cable x1 • Audio / Video cable(1.2m) x1 (1206158802) (red/white/yellow) (076E0PP031:DV-310-S) (06CPBA2006) (076E0PP041:DV-310-K) STANDBY/ON OPEN/CLOSE AUDIO SUBTITLE ANGLE DVD/ CLEAR MENU TOP MENU ENTER • Dry cell batteries x2 •...

  • Page 8: Specifications

    Wow and flutter ....Limit of measurement (±0.001%W. PEAK) or lower Digital output Coaxial digital output......RCA DV-310-S...

  • Page 9: Disc/Content Format

    •DRM (Digital Rights Management) compatible: No (DRM- protected audio files will not play in this player •File extensions: .mp3, .wma, .m4a (these must be used for the player to recognize MP3, WMA and MPEG-4 AAC files–do not use for other file types) Super VCD DV-310-S...
  • Page 10 DiviX videos burned on CD-R/-RW/-ROM discs. Keeping the additional compatibility information. same terminology as DVD-Video, individual DivX video files are called “Titles”. When naming files/titles on a CD-R/-RW disc prior to burning, keep in mind that by default they will be played in alphabetical order. DV-310-S...

  • Page 11: Panel Facilitiles

    Displays a DVD disc (or DiviX media files) menu —this varies with the disc and may be the same as the ‘top menu’. RETURN Returns to the previously displayed menu screen. HOME MENU Display/exit the on-screen display. 10 USB port (Type A) DV-310-S...
  • Page 12 Press to display information about the disc ENTER menus. Press to select an option or playing. execute a command. 24 ZOOM HOME MENU Press to change the zoom level. Display/exit the on-screen display. Use for reverse slow motion playback, frame reverse and reverse scanning. DV-310-S...

  • Page 13: Basic Items For Service

    • Before shipping out the product, be sure to clean the following positions by using the prescribed cleaning tools: Position to be cleaned Position to be cleaned Position to be cleaned Cleaning tools Cleaning tools Cleaning tools Remark Remark Remark Pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 DV-310-S...

  • Page 14: Pcb Locations

    DVD MECHA ASSY DVD MT PCB ASSY OPERATION PCB ASSY Mark No. Description Part No. LIST OF ASSEMBLIES 1..DVD MT PCB ASSY A2L103A130 1..OPERATION PCB ASSY(WYXZT5) A2L103A270 1..OPERATION PCB ASSY(WSXZT5) A2L109A270 1..POWER PCB ASSY A2L103A240 1..DVD MECHA ASSY A2L101A650 DV-310-S...

  • Page 15: Jigs List

    Lubricants and Glues No. Lubricants and Glues No. Lubricants and Glues No. Remark Remark Remark Daifree GEM1036 (ZLX-ME413A) Refer to "9.3 DVD MECHA SECTION" Grease GYA1001 (ZLB-PN397B) Refer to "9.3 DVD MECHA SECTION" Grease GEM1018 Refer to "9.3 DVD MECHA SECTION" DV-310-S...

  • Page 16: Block Diagram

    CAUTION :SINCE THESE PARTS MARKED NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED CRITICAL FOR SAFETY,USE ON WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST DESCRIBED IN PARTS LIST ON WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL. DV-310-S...
  • Page 17 DVD MECHA ASSY (A2L101A650) ATTENTION :LES PIECES REPAREES PAR UN ETANT DANGEREUSES AN POINT DE VUE SECURITE N’UTILISER QUE CELLS DECRITES DANS LA NOMENCLATURE DES PIECES E THESE PARTS MARKED BY ICAL FOR SAFETY,USE ONES CRIBED IN PARTS LIST ONLY DV-310-S...

  • Page 18: Overall Block Diagram

    4.2 OVERALL BLOCK DIAGRAM RESET DV-310-S...

  • Page 19: Dvd Loader/Mpeg Block Diagram

    4.3 DVD LOADER/MPEG BLOCK DIAGRAM CR OUT CB OUT Y2 OUT RESET DV-310-S...

  • Page 20: Power Block Diagram

    4.4 POWER BLOCK DIAGRAM DV-310-S...

  • Page 21: Diagnosis

    DECK DOES NOT ACCEPT OPEN/CLOSE Is the voltage at Check P.CON 6V line of pin 8 and 19 of IC2301 POWER BLOCK. about DC6V ? Check CD2302 Is the lose connection connection to DECK. at CD2302 to DECK ? Change DVD LOADER. DV-310-S...
  • Page 22 NO PLAYBACK PICTURE OF AV JACK Is there Check IC4001 and a signal at pin 99 of peripheral circuit. IC4001 ? Y es Is there Check J7302 and peripheral video signal at pin 33 circuit. of IC7301 ? Change IC7301. DV-310-S...
  • Page 23 NO ANALOG AUDIO ON PLAYBACK Is there Check J8003 and peripheral AUDIO signal at pins 1 and 7 circuit. of IC8003 ? Is there Check AT pins 116 and 118 AUDIO signal at of IC4001 C8051 and C8053 ? Change IC8003. DV-310-S...
  • Page 24 Any kind of symptoms (no power, a failure in any of the servo, video and audio systems, etc.) may be (DVD MT PCB Assy : IC4001) generated, because the DVD processing is performed by a single chip. 64M SDRAM No power. (DVD MT PCB Assy : IC4005) Block noise is generated during playback. DV-310-S...

  • Page 25: Method For Diagnosing Degradation Of The Lds On The Pickup Assy

    C4134 C7306 R7306 C7305 C4072 C4012 C7307 R7301 C7308 D7305 R4059 R4061 R8037 D7306 C7309 W832 R7305 C8036 R4060 R4062 R2319 B8004 C7310 C4049 C4102 W802 IC4003 C4089 R4015 R4016 C2307 C2305 IC4005 DMG099A C4007 R4031 B4007 SIDE A DV-310-S...

  • Page 26: Service Mode

    • After going into service mode, if you play back the disc, "DISC-NON" is displayed. • The video signal and the audio signal are outputted during the servicemode. • The SKIP key and the SCAN key are effective during the service mode. SERVICE MODE: OFF POWER GGF1381 Service mode remote control unit DV-310-S...

  • Page 27: Service Mode In

    3 LD ON DVD : Press the [TEST] (A8-5E) and [1] (A8-01) keys in order, and turn on the laser diode (650n). : Press the [TEST] (A8-5E) and [4] (A8-04) keys in order, and turn on the laser diode (780n). DV-310-S...

  • Page 28: Display Specification Of The Service Mode

    : [NTSC] PAL system : [PAL] Automatic setting : [AUTO] Scart terminal output [SK − ∗ ∗] (Display only the WY model which can do the output setting of scart terminal.) VIDEO : [00] S-VIDEO : [01] : [02] DV-310-S...

  • Page 29: Functional Specification Of The Shortcut Key

    Region confirmation mode (ESC + A.MON [Service mode remote control unit] + "1"-"8" [Service mode remote control unit] keys) After you press the A.MON key while holding the ESC key pressed and then input the region number, if the number is different from that set in the unit, an error message is displayed, and the tray opens. DV-310-S...

  • Page 30: Functional Specification Of The Service Mode

    -2 : NG 7.0e -4 : NG 3 EDC/ID error history (ID Address, EDC/ID errors, last eight errors) Note: ∗ Error of AV1 is not supported in this player. Indication plan contents Character in bold : Item name : Information display DV-310-S...

  • Page 31: Disassembly

    PCB and DVD MT PCB connector. 1-4: DVD MT PCB (Refer to Fig. 1-4) Power PCB Remove the 3 screws (1). Remove the 4 screws (2). Remove the DVD MT PCB in the direction of arrow. DVD MT PCB Fig. 1-2 Fig. 1-4 DV-310-S...
  • Page 32 4. Remove the Traverse Ass'y. Loading Sub Ass'y Loader Sub Ass'y Gear Pulley Insulator (R) Loading Motor PCB Ass’y Traverse Ass'y • Screw Torque: 2.5±0.3kgf•cm (Screw • Screw Torque: 1.0±0.3kgf•cm (Screw Fig. 2-3-A • Screw Torque: 2.0±0.3kgf•cm Fig. 2-2-A DV-310-S...
  • Page 33 3 supports 1. between A and B. Fig. 2-3-D 2. Remove the Plate Clamper, Magnet Clamper and Clamper. Check Hook Check Hook Plate Clamper Magnet Clamper Main Frame Loading Motor PCB Ass’y Check Hook Clamper Fig. 2-3-E Fig. 2-5-A DV-310-S...
  • Page 34 6. Remove the Switch PCB Ass'y. 7. Remove the screw 4. Feed Motor 8. Remove the Gear Feed. 9. Remove the 2 screws 5. 10. Remove the Feed Motor. Safety surface for pressing 11. Remove the Gear Motor. of the insert. Fig. 2-7-C DV-310-S...
  • Page 35 1. When installing the FFC, fold it correctly and install it as shown from Fig. 2-8. NOTE 1. Do not make the folding lines except the specified positions for the FFC. [ 24 pin FFC ] Fold Printing Surface 79 1 mm Reinforcement Plate To Pick Up PCB Fig. 2-8 DV-310-S...

  • Page 36: Each Setting And Adjustment

    While the screen shown at left is being displayed, updating is in progress. DO NOT TURN OFF THE POWER DURING UPDATING. 4 Updating of the firmware is completed. When the screen with the Pioneer logo is displayed, updating is completed. The time required for updating is about 2 minutes. DV-310-S...
  • Page 37 1.16 CHIP VERSION 1389EE How to interpret the version code: Y J A 8 2 2 3 A Number of releases on the same release date Release date:(Example:2008.2.23) 8: Year 2: Month (1-9 [Jan-Sep], A-C [Oct-Dec]) 23: Day Fixed DV-310-S...

  • Page 38: Exploded Views And Parts List

    For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.) 9.1 PACKING Except WSXZT5 WSXZT5 Only DV-310-S...
  • Page 39 Operating Instructions (E/I) See Contrast table (2) Operating Instructions (G/F) See Contrast table (2) (2) CONTRAST TABLE DV-310-S/WYXZT5, DV-310-S/WSXZT5, DV-310-K/WYXZT5 and DV-310-K/WSXZT5 are constructed the same except for the following: Mark Symbol and Description DV-310-S/WYXZT5 DV-310-S/WSXZT5 DV-310-K/WYXZT5 DV-310-K/WSXZT5 Remote Control...

  • Page 40: Exterior Section

    9.2 EXTERIOR SECTION DV-310-S...
  • Page 41 Screw,Tap Tite(S)-Bind Wash. 816423063U Spring Earth 753WUAA013 Screw,Tap Tite(B)-R (3x5.5) 815223055U (2) CONTRAST TABLE DV-310-S/WYXZT5, DV-310-S/WSXZT5, DV-310-K/WYXZT5 and DV-310-K/WSXZT5 are constructed the same except for the following: Mark Symbol and Description DV-310-S/WYXZT5 DV-310-S/WSXZT5 DV-310-K/WYXZT5 DV-310-K/WSXZT5 OPERATION PCB ASSY A2L103A270 A2L109A270...

  • Page 42: Dvd Mecha Section

    Note : (SW PCB ASS'Y) CD2301 NOTE: Applying positions AA, AB and AC for the CLASS PART NO. MARK grease are displayed for this section. GREASE GEM1018 Check if the correct grease is applied for each GYA1001 position. GEM1036 DV-310-S...
  • Page 43 814011723U Rack,Loading 92P100121A Gear,Motor 92P100088A Feed Rack Assy 92AAA0017A Screw,T-Tite(B) (M1.7x5.0 P3) 813381750U Screw,Gear Feed 92P700007A Cord Jumper (CD2301) 12C1061601 Switch (SW1) 0515S32003 Push Switch (SW2) 0500101036 Screw,Tap Tite(P) (2.6x8) 811022680U Sems.Tap Tite(P) (2x8) 816112080U Screw (Bind 2x8) 811022080U DV-310-S...

  • Page 44: Schematic Diagram

    3.27 3.11 3.19 3.31 1.57 1.14 1.34 1.34 1.20 3.29 3.31 1.52 1.30 0.73 1.81 3.15 0.83 USB_GND V+3D NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIAGR MEASURED WITH THE DIGITAL TESTER OF PRINTING AND SUBJ DURING PLAYBACK. DV-310-S...
  • Page 45 0.00 1.10 0.82 0.85 0.94 C4104 0.01 B JG4091 JG4092 RXD/SQ R4032 JG4093 R4038 TXD/LE JG4094 TP4110 R4075 W825 4.7K PCB130 DMG099 OTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE. DV-310-S...

  • Page 46: D 10.2 Dvd Mt Pcb Assy(2/6)

    0.1 B V+3D D_GND USBN TP4001 USBP W844 USB+5V NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME MEASURED WITH THE DIGITAL TES OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE. DURING PLAYBACK. DV-310-S...
  • Page 47 DI (M to F) FP_SCK CP4004 B4B-PH-SM4-TB(LF)(SN) USBN USBP USB+5V GND(USB) D4003 L4001 DLP11SN201HL2L AVRL161A1R1NT USBN W831 USBP D4002 (SCHOTTKY 3.0A) AVRL161A1R1NT D4005 W844 USB+5V EC31QS04 PCB130 DMG099 OLTAGE EACH PART WAS CAUTION: DIGITAL TRANSISTOR D WITH THE DIGITAL TESTER LAYBACK. DV-310-S...

  • Page 48: Dvd Mt Pcb Assy(3/6)

    NOTE:THE DC V :LES PIECES REPAREES PAR UN ETANT :SINCE THESE PARTS MARKED BY MEASURE DANGEREUSES AN POINT DE VUE SECURITE CRITICAL FOR SAFETY,USE ONES DURING P N’UTILISER QUE CELLS DECRITES DESCRIBED IN PARTS LIST ONLY. DANS LA NOMENCLATURE DES PIECES. DV-310-S...
  • Page 49 2.88 VOTK- VOFC- 2.77 2.82 VOTK+ VOFC+ PCB130 DMG099 NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME MEASURED WITH THE DIGITAL TESTER OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE. DURING PLAYBACK. DV-310-S...

  • Page 50: Dvd Mt Pcb Assy(4/6)

    FROM/TO VIDEO JACK AUDIO_L AUDIO_R V+5V_A C8051 R8049 NA_P 10K +-1% R8048 470K NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT MEASURED WITH THE DIGITAL TESTER OF PRINTING AND SUBJECT TO CHANGE WITH DURING PLAYBACK. DV-310-S...
  • Page 51 68P CH YK_P KTC2875-B -1.1 R8048 470K R8077 R8063 AUDIO_R 220 +-1% 27K +-1% C8072 R8057 0.1 B AUDIO OUT J8003 RCA-207B(CUSN)-02 PCB130 DMG099 CAUTION: DIGITAL TRANSISTOR AGRAM IS THE LATEST AT THE TIME UBJECT TO CHANGE WITHOUT NOTICE. DV-310-S...

  • Page 52: Dvd Mt Pcb Assy(5/6)

    L7301 V+5V FROM POWER PORT 22uH 0405 V+5V_A V+5V W889 V+6A TP7303 D_GND D_GND NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIAGRAM IS THE LA MEASURED WITH THE DIGITAL TESTER OF PRINTING AND SUBJECT TO CHANG DURING PLAYBACK. DV-310-S...
  • Page 53 P-H/I-L_RGB-H RGB-H ASP/FS CVBS AUDIO L AUDIO R CVBS OUT 4CH BUS SW IC IC7302 SN74CBT3257PWR CVBS/Y/U/V J7302 RCA-405A(CUSN)-08 PCB130 DMG099 ATIC DIAGRAM IS THE LATEST AT THE TIME CAUTION: DIGITAL TRANSISTOR G AND SUBJECT TO CHANGE WITHOUT NOTICE. DV-310-S...

  • Page 54: Dvd Mt Pcb Assy(6/6)

    :LES PIECES REPAREES PAR UN ETANT :SINCE THESE PARTS MARKED BY MEASURED WITH THE DIG DANGEREUSES AN POINT DE VUE SECURITE CRITICAL FOR SAFETY,USE ONES DURING PLAYBACK. N’UTILISER QUE CELLS DECRITES DESCRIBED IN PARTS LIST ONLY. DANS LA NOMENCLATURE DES PIECES. DV-310-S...
  • Page 55 V_ADJ TP4036 D_GND R4063 R4072 R4073 +-1% PCB130 DMG099 NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME HE DC VOLTAGE EACH PART WAS OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE. MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK. DV-310-S...

  • Page 56: Operation Pcb Assy

    -18.0 -18.0 -18.0 -16.0 -16.0 -16.0 -16.0 -16.0 -16.0 SW662 SW663 EVQ11L05R EVQ11L05R -SKIP PAUSE SW664 SW665 EVQ11L05R EVQ11L05R NOTE:THE DC VOLTAGE EACH PART WAS NOTE:THIS SCHEMATIC DIA MEASURED WITH THE DIGITAL TESTER OF PRINTING AND SU DURING PLAYBACK. DV-310-S...
  • Page 57 .0 -16.0 -16.0 FFC(1.0mm pitch) V+3E V+3E C604 DGND CD601 C605 33P CH 2H0B1202 DGND FLDC+ FLDC+ -28V -28V FLDC- FLDC- V+3E PCB270 DEG149 NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE DV-310-S...

  • Page 58: Power Pcb Assy(1/2)

    OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOT DANGEREUSES AN POINT DE VUE SECURITE DESCRIBED IN PARTS LIST ONLY. N’UTILISER QUE CELLS DECRITES NOTE:THE DC VOLTAGE EACH PART WAS DANS LA NOMENCLATURE DES PIECES. MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK. DV-310-S...
  • Page 59 Q501 KTC3875S_Y_RTK PCB240 DPG017 S THE LATEST AT THE TIME CAUTION: DIGITAL TRANSISTOR NOTE: THE RESISTOR MARKED F IS FUSE RESISTOR. TO CHANGE WITHOUT NOTICE. THE ALUMI ELECTROLYTIC CAPACITOR MARKED NP T WAS IS NON POLAR ONE. AL TESTER DV-310-S...

  • Page 60: Power Pcb Assy(2/2)

    R8101 DVD_RGB_H_OUT Q8104 4.7K KRC104SRTK NOTE:THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIM E NOTE:THE DC VOLTAGE EACH PART WAS CAUTION: DIGITAL T OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE. MEASURED WITH THE DIGITAL TESTER DURING PLAYBACK. DV-310-S...
  • Page 61 CVBS_VIDEO_OUT 6.3V 1000 YK_P +-1% 1/10W DVD_RGB_H_OUT Q8105 KRA102SRTK R8109 D_RGB_H_OUT Q8104 68 1/10W +-1% C104SRTK * The parts except mark cannot be changed. On that occasion, replace whole Assy. CAUTION: DIGITAL TRANSISTOR CAUTION: DIGITAL TRANSISTO R PCB240 DPG017 DV-310-S...

  • Page 62: Waveforms

    Note : The encircled numbers denote measuring point in the schematic diagram. DVD MT PCB ASSY POWER PCB ASSY MPEG/MICON/DSP 21PIN/D-TERMINAL/DIGITAL IC4001-pin9 (XTALI) J8001-pin2 (Coaxial Out) V:500mV/div. H:200ns/div. IC4001-pin66 (SDCLK) V:0.5V/div. H:2ns/div. IC4001-pin93 (SPDIF) V:1.0V/div. H:200ns/div. AUDIO JACK J8003-pin3 (Lch_Out) J8003-pin2 (Rch_Out) DV-310-S...
  • Page 63 POWER PCB ASSY OPERATION PCB ASSY DISPLAY DV-310-S...

  • Page 64: Pcb Connection Diagram

    Symbol In PCB Symbol In Schematic Part Name Diagrams Diagrams C E B Capacitor Connector Transistor B C E SIDE A Transistor with resistor B C E Field effect SIDE B Chip Part P.C.Board transistor Resistor array 3-terminal regulator DV-310-S...

  • Page 65: Dvd Mt Pcb Assy

    C4002 L7301 D4003 W826 R4054 R4035 R4022 R4053 IC4001 C4011 Q7305 IC4004 R7308 C4134 C7306 R7306 C7305 C4072 C4012 C7307 R7301 C7308 D7305 R4059 R4061 R8037 D7306 C7309 R7305 C8036 R4060 R4062 B8004 C7310 C4049 IC4003 IC4005 DMG099A B4007 DV-310-S...
  • Page 66 SIDE B SIDE B DVD MT PCB ASSY W849 R4038 R4032 R4030 R4029 W836 W831 Q4003 W813 IC4007 R2343 R2341 DMG099A W834 D2301 D2302 W822 R4001 W821 W833 Q2306 W845 DV-310-S...

  • Page 67: Operation Pcb Assy

    C654 W004 W011 W005 W006 D669 C601 C605 W012 W007 C675 W013 W014 CP602 C610 R656 W017 C676 W016 C608 D652 R658 R657 D654 C611 D655 R655 D656 B601 D657 W019 W020 D665 W018 C613 C604 CP604 C651 R666 DV-310-S...

  • Page 68: Power Pcb Assy

    C538 C521 W015 D527 L503 IC501 C536 C8115 C520 W004 W019 R514 C522 A30C5 C8114 C528 R510_1 D528 Q502 L505 W819 C526 D521 W009 C8112 W010 W011 Q504 C517 L8101 D8101 D8104 CP502 D536 D531 D535 C519 D533 C8113 DV-310-S...
  • Page 69 SIDE B SIDE B POWER PCB ASSY DV-310-S...

  • Page 70: Loading Motor And Sw

    11.4 LOADING MOTOR and SW SIDE A SIDE B LOADING MOTOR LOADING MOTOR (INSERTED PARTS) (CHIP MOUNTED PARTS) DED021A M2603 CD2302 DED020A M2602 M2601 DV-310-S...

  • Page 71: Pcb Parts List

    8001 RCA JACK 060R401122 8003 RCA JACK 060R451012 X 4001 CRYSTAL (27MHz) 100GT02720 OPERATION PCB ASSY SEMICONDUCTORS IC 651 IC PT6315 IF4K063150 SWITCHES SW 652-667 SWITCH TACT 0504R01T38 OTHERS CP 602 CONNECTOR PCB SIDE 06G5AA1002 V 651 TUBE FLUORESCENT 096F80R401 DV-310-S...
