Tripp Lite ECO350UPS Mounting Template

INTERNET350U, INTERNET350SER, ECO350UPS and BC350
Note: This graphic represents actual-sized center-to-center spacing for drilling holes to mount the unit. This portion can be printed and cut out to use as a template for mounting purposes.
In your PDF print setup menu, be sure to turn the Page Scaling feature OFF or set to NONE, to insure proper measurments.
Refer to the full product drawing for measurements of the entire unit in relation to the cut out holes and determine where to place your
template for proper mounting.
Dimensions: [mm] INCHES
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
