DeWalt DCC2560 Manual

60v max 2.5 gallon cordless air compressor
Hide thumbs Also See for DCC2560:
Table of Contents

Advertisement

Quick Links

DCC2560
60V Max* 2.5 Gallon Cordless Air Compressor
Specifications
Model
Weight
Height
Width
Length
Air tank capacity
Approx cut-in pressure
Approx. Cut-out pressure
Scfm @ 90 psi
Noise level
Fuse type
Regulated pressure rating (approximate)
Quick connect type
Pump Type
**Tested per iso 1217:1996
+Tested per iso 3744:1994
DCC2560
21.5 Lbs. (9.75 Kg)
15.5" (393.7 mm)
12.5" (317.5 mm)
14.0" (355.6 mm)
2.5 Gallon (9.5 Liters)
105 Psi
135 Psi
1.2 **
79.0 DBA
+
Time delay
0–135 Psi
1/4" (6.4 mm) industrial
Oilless
Manual

Advertisement

Table of Contents
loading

Related Manuals for DeWalt DCC2560

Summary of Contents for DeWalt DCC2560

  • Page 1 Manual DCC2560 60V Max* 2.5 Gallon Cordless Air Compressor Specifications DCC2560 Model Weight 21.5 Lbs. (9.75 Kg) Height 15.5" (393.7 mm) Width 12.5" (317.5 mm) Length 14.0" (355.6 mm) Air tank capacity 2.5 Gallon (9.5 Liters) Approx cut-in pressure 105 Psi Approx.
  • Page 2 Definitions: Safety Alert Symbols and Words This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of personal injury or property damage. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 3: Save All Warnings And Instructions For Future Reference

    SAVE ALL WARNINGS AND DANGER: RISK TO BREATHING (Asphyxiation) INSTRUCTIONS FOR FUTURE REFERENCE What can happen how to prevent it The compressed air directly from Air obtained directly from the DANGER: RISK OF EXPLOSION OR FIRE your compressor is not safe for compressor should never be breathing.
  • Page 4 What can happen how to prevent it Exceeding the pressure rating of Follow the equipment air tools, spray guns, air operated manufacturers recommendation Touching exposed metal such as Never touch any exposed metal accessories, tires, and other and never exceed the maximum the compressor head, engine head, parts on compressor during or inflatables can cause them to...

  • Page 5: Batteries And Chargers

    ...... Class II ..... wear respiratory What can happen how to prevent it Construction protection A portable compressor can fall Always operate compressor in a (double insulated) ..... wear eye from a table, workbench, or roof stable secure position to prevent n o .......
  • Page 6 • If battery contents come into contact with the skin, The battery label indicates two Watt hour ratings (see immediately wash area with mild soap and water. If example). Depending on how the battery is shipped, the appropriate Watt hour rating must be used to determine battery liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases.
  • Page 7 the Call 2 Recycle® program provides an environmentally Minimum Gauge for Cord Sets conscious alternative. Volts Total Length of Cord in Feet (meters) Call 2 Recycle, Inc., in cooperation with D WALT and other 120 V 25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7) battery users, has established the program in the United 240 V 50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)

  • Page 8: Charger Operation

    Wireless Certifications and Safety • The shortwave radio frequency signals of a Bluetooth® device may impair the operation of other electronic and Information medical devices (such as pacemakers or hearing aids). • This device is CAN ICES-3(B)/NMB-3(B) compliant. NOTE: The Bluetooth® word mark and logos are registered •...

  • Page 9: Electronic Protection System

    If the charger indicates a problem, take the charger and does not indicate a problem. To facilitate the cooling of battery pack to be tested at an authorized service center. the battery pack after use, avoid placing the charger or battery pack in a warm environment such as in a metal hot/Cold Pack Delay shed or an uninsulated trailer.

  • Page 10: Assembly And Adjustments

    ASSEMBLY AND ADJUSTMENTS Know Your Air Compressor WARNING: To reduce the risk of serious personal READ THIS OWNER’S MANUAL AND SAFETY RULES BEFORE injury, turn unit off and remove the battery pack OPERATING YOUR UNIT. Compare the illustrations with before making any adjustments or removing/ your unit to familiarize yourself with the location of installing attachments or accessories.

  • Page 11: Before Starting

    5. Set the Auto On/Off switch to "Auto On" position. Fig. E Quick-Connect Coupler  9  : The quick connect body accepts industrial quick connect plugs. How to Use Your Unit (Fig. E) How to Stop 1. Set the Auto On/Off switch  1  to "Off".
  • Page 12 Storage Fig. F Before you store the air compressor, make sure you do the following: 1. Review the Maintenance section on the preceding pages and perform scheduled maintenance as necessary. 2. Always toggle Auto On/Off Switch to "Off" and remove battery. Drain water from air tank. See To Drain Tank under Maintenance.

  • Page 13: Troubleshooting Guide

    Troubleshooting Guide This section provides a list of the more frequently encountered malfunctions, their causes and corrective actions. The operator or maintenance personnel can perform some corrective actions, and others may require the assistance of a qualified D WALT technician or your dealer. Code Possible Cause Possible solution...
  • Page 14 WALT BATTERY AND CHARGER SYSTEMS Chargers/Charge Time (Minutes) . 120 Volts 12 Volts Battery Output Cat # Voltage DCB609 20/60 DCB606 20/60 DCB404 DCB406 DCB407 DC9360 DCB361 DC9280 DW0242 DCB200 45/30** DCB201 DCB203 DCB203BT* DCB204 60/40** DCB204BT* DCB205 75/47** DCB206 DCB207 DC9182 DCB120...
