Panasonic Lumix DMC-F3P Service Manual
Hide thumbs
Also See for Lumix DMC-F3P:
- Specifications (2 pages) ,
- Basic operating instructions manual (28 pages)
Table of Contents
Advertisement
Quick Links
DMC-F3P
Model No.
DMC-F3PC
DMC-F3PR
DMC-F3PU
DMC-F3EB
DMC-F3EE
DMC-F3EF
DMC-F3EG
DMC-F3EP
DMC-F3GC
DMC-F3GF
DMC-F3GN
DMC-F3GT
DMC-F4EB
DMC-F4EE
DMC-F4EG
DMC-F4EP
Colour
[ DMC-F3 ]
(S)...........Silver Type (except PC/EF/GT)
(K)...........Black Type
(P)...........Pink Type (except PC)
[ DMC-F4 ]
(S)...........Silver Type (only EE)
(K)...........Black Type (except EE)
© Panasonic Corporation 2010 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1002017CE
B26
Digital Camera
Advertisement
Table of Contents
Related Manuals for Panasonic Lumix DMC-F3P
Summary of Contents for Panasonic Lumix DMC-F3P
- Page 1 DMC-F4EP Colour [ DMC-F3 ] (S)...Silver Type (except PC/EF/GT) (K)...Black Type (P)...Pink Type (except PC) [ DMC-F4 ] (S)...Silver Type (only EE) (K)...Black Type (except EE) © Panasonic Corporation 2010 Unauthorized copy- ing and distribution is a violation of law.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the Capacitor on Flash P.C.B.----------------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices ----------5 2.2. -
Page 3: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. -
Page 4: How To Discharge The Capacitor On Flash P.c
1.4. How to Discharge the Capacitor on Flash P.C.B. CAUTION: 1. Make sure to discharge the capacitor on FLASH P.C.B.. 2. Be careful of the high voltage circuit on FLASH P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2. -
Page 5: Warning
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD). -
Page 6: Caution For Ac Cord(For Eb
A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. -
Page 7: How To Dispose The Lithium Battery
2.4. How to dispose the Lithium Battery 2.4.1. Removal Procedure 1. Remove the Main P.C.B. (Refer to Disassembly Procedures.) 2. Remove the Lithium battery (Ref. No.“Z3001” at component side of Main P.C.B.) and then dispose it. It should be disposed of in waste products destined for burial rather than incineration. NOTE: This Lithium battery is a critical component. -
Page 8: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. -
Page 9: Important Notice 1
3.3. Important Notice 1: [1.Component on P.C.B.] 1. The P.C.B.’s in this unit is not component replacement excluding following part. MAIN P.C.B. --------- Fuse (F5001, F5002, F5005, F5006) FLASH P.C.B. -------- Flash Charging Capacitor(C5412)), Trigger Coil(T5402) Other than above component on P.C.B.’s are defected, replace each P.C.B. as a unit. [2.MAIN P.C.B.] AFTER REPLACING THE MAIN P.C.B. -
Page 10: How To Define The Model Suffix (Ntsc Or Pal Model)
3.4. How to Define the Model Suffix (NTSC or PAL model) There are six kinds of DMC-F3/F4, regardless of the colours. • a) DMC-F3P/PC • b) DMC-F3EB/EF/EG/EP, F4EB/EG/EP • c) DMC-F3EE, F4EE • d) DMC-F3GT • e) DMC-F3GN • f) DMC-F3PU/PR/GC/GF What is the difference is that the “INITIAL SETTINGS”... - Page 11 3.4.2. INITIAL SETTINGS: 1. PURPOSE OF INITIAL SETTINGS: There are two cases to perform the INITIAL SETTINGS. 1. Refresh the unit:The INITIAL SETTINGS can be used to erase all back up data. (Not only user setting and image data stored in “Built-in Memory”, but also clock data is reset.) 2.
- Page 12 Step 2. Setup: 1. Attach the Battery or AC Adaptor with a DC coupler to the unit. 2. Set the [ REC/PLAY ] switch to “REC” mode. 3. Set the recording mode to [ Normal Picture ] mode. *.Turn on the power switch and then press the “MODE” button. *.Choose the [ Normal Picture ] mode with cursor buttons, then press the “MENU/SET”...
- Page 13 Step 3. Execute the software “DscCalDi” : 1. Choose the “Adj Soft (DscCalDi)” and execute the adjustment software.(Refer to Fig.X1:Connection) [ “Start” ---> “Program(P)” ---> “Win Tatsujin” ---> “Dsc” ---> “DMC-F3,F4 series” ---> “Adj Soft (DscCalDi)” ] The following main screen is appear on the PC monitor. NOTE: Without connecting the USB cable between DSC (USB mode with power on) and PC, adjustment software does not exe- cuted.
- Page 14 Step 4. Select the Model suffix (Factory Code): 1. Click on the pull down menu tag of the “Factory Code”. The model suffix list is displayed. 2. Choose the appropriate model suffix.
- Page 15 Step 5. Default settings (Test): 1. Click on the pull down menu tag of the “Test”. (The Test item list is displayed.) 2. Choose the “Set Default” in order to refresh the unit (Factory shipping condition). Step 6. CONFIRMATION: 1. Close the “DscCalDi.exe” by clicking on the “X” located on the top right corner. 2.
-
Page 16: Specifications
4 Specifications... -
Page 17: Location Of Controls And Components
20 Card/Battery door 21 Release lever 22 DC coupler cover When using an AC adaptor, ensure that the Panasonic DC coupler and AC adaptor are used. We recommend you use a battery with sufficient battery power or the AC adaptor when recording motion pictures. - Page 18 The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used.) Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.
-
Page 19: Service Fixture & Tools
6 Service Fixture & Tools 6.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit. - Page 20 REMARKS 1. ABOUT “Siemens star chart”: The PDF version of Siemens star chart together adjustment software is available at “software download” on the “Support Infor- mation from NWBG/VDBG-AVC” web-site in “TSN system”. Download its PDF file and print out it, then stick on the suitable panel. For your convenience, there are two kinds of PDF files are available.;...
-
Page 21: Disassembly And Assembly Instructions
7 Disassembly and Assembly Instructions 7.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 7.2. PCB Location... -
Page 22: Disassembly Procedure
7.3. Disassembly Procedure Item Removal Rear Case Unit (Fig.D1) Card (Fig.D2) Battery 4 Screws (A) 1 Screw (B) Connector (A) LCD Unit (Fig.D3) 3 Screws (C) (Fig.D4) LCD Holder Connector (B) Flash P.C.B. & (Fig.D5) Flex Cable Lens Unit (Fig.D6) 2 Screws (D) (Fig.D7) Lens Holder... - Page 23 7.3.2. Removal of the LCD Unit 7.3.3. Removal of the Flash P.C.B. & Lens Unit (Fig.D5) (Fig.D3) (Fig.D6) (Fig.D4)
- Page 24 (Fig.D7) 7.3.4. Removal of the Front/Top Case Unit (Fig.D9a) (Fig.D8)
- Page 25 7.3.5. Removal of the Main P.C.B. and Top Operation P.C.B. & Battery Case Unit (Fig.D9b) (Fig.D11) (Fig.D10)
- Page 26 7.3.6. Removal of the CCD Unit NOTE: (When Assembling) [Definitions of mount side of Optical filter.] NOTE: • Put the Optical filter on the white sheet. 1. Make sure no dust or dirt gets into the lens. • When the "non -coating side is face up condition, it can be 2.
-
Page 27: Measurements And Adjustments
8 Measurements and Adjustments 8.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. To perform the adjustment, it is necessary to use the “DscCalDi” software. The Adjustment software “DscCalDi” together with its installation instruction are available at “TSN Website”. To download, click on “Support Information from NWBG/VDBG-AVC”. -
Page 28: Execute The Adjustment Software "Dsccaldi.exe
8.3. Execute the Adjustment software “DscCalDi.exe”. Step 1.Preparation: 1. Attach the Battery or AC Adaptor with a DC coupler to the unit. 2. Set the [ REC/PLAY ] switch to “REC” mode. 3. Set the recording mode to [ Normal Picture ] mode. •... -
Page 29: Adjustment Procedures
8.4. Adjustment procedures 8.4.1. BF ADJUSTMENT(1) [ 1meter adjustment ] [ PREPARATION ] 1. Perform the “8.3 Execute the Adjustment software “DscCalDi.exe”” in advance. [ CAUTION ] 1. Do not apply any vibration to the camera during adjustment. [ ADJUSTMENT CONDITION ] 1. - Page 30 3. When the adjustment is completed, the “Focus Result value list” is displayed. 4. Compare the Value displayed on the PC monitor and the following table. If the adjustment value is out of specification, replace the Lens unit and try it again. 5.
- Page 31 8.4.2. BF ADJUSTMENT(2) [ Infinity adjustment ] [ PREPARATION ] 1. Perform the “8.3 Execute the Adjustment software“DscCalDi.exe”” in advance. [ CAUTION ] 1. Do not apply any vibration to the camera during adjustment. [ ADJUSTMENT SETTINGS ] 1. Click on the pull down menu tag of the “Test”. (The Test item list is displayed.) 2.
- Page 32 3. When the adjustment is completed, the “Infinity calibration value list” is displayed. 4. Compare the Value displayed on the PC monitor and the following table. If the adjustment value is out of specification, replace the Lens unit and try it again. 5.
- Page 33 8.4.3. ISO/WBL/SHT ADJUSTMENT [ PREPARATION ] 1. Perform the “8.3 Execute the Adjustment software“DscCalDi.exe”” in advance. 2. Remove the Front block of the Lightbox. (Refer to the “6 Service Fixture & Tools” section for details.) 3. Turn on the Lightbox. [ ADJUSTMENT SETTINGS ] 1.
- Page 34 NOTE: When the following “AWB Results:” (without data) message is displayed instead of displaying the above “AWB Result value list”, try this adjustment again. 4. Compare the Value displayed on the PC monitor and the following table. If the adjustment value is out of specification, replace the Lens unit and try it again. 5.
- Page 35 8.4.4. BKI ADJUSTMENT [ PREPARATION ] 1. Perform the “8.3 Execute the Adjustment software“DscCalDi.exe”” in advance.] 2. Remove the front block of the Lightbox. (Refer to the “6 Service Fixture & Tools” section for details.) 3. Turn on the Lightbox. [ ADJUSTMENT SETTINGS ] 1.
- Page 36 [ AFTER ADJUSTMENT ] NOTE: If you want to perform other adjustments continiously, click on the pull down menu tag of the “Test” and choose the “OFF” in stead of perform the following 1 to 3. (The LCD display becomes black fade.) Do not perform the same adjustment, continuously.
- Page 37 8.4.6. USB STORAGE INFO. REGISTRATION [ PREPARATION ] 1. Perform the “8.3 Execute the Adjustment software“DscCalDi.exe”” in advance. [ SETUP ] 1. Click on “Get” button. (The USB Strage data is displayed.) 2. Confirm that the following data is displayed in each frame. If not, revise the data as follows.
-
Page 38: Maintenance
9 Maintenance 9.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;... -
Page 39: Block Diagram
10 Block Diagram 10.1. Overall Block Diagram CA1 BOARD PROGRAM FLASH CP1 BOARD SDRAM CAA BLOCK SD CARD 64MByte/64MByte PAON3 SIO TO ASIC CDS, AGC, A/D C DATA1 LVDS DATA2 H.DRIVER 12M CCD ADDRESS2 SG/TG ADDRESS1 V. DRIVER JPEG SDRAM CARD CONTROLLER USBD[+,-]... -
Page 40: Wiring Connection Diagram
11 Wiring Connection Diagram BATTERY LENS SD CARD USB & AV CN952 CN541 UNREGST CN911 CN901 UNREGST FLASH UNREGST UNREGST VMONIT FLCTL AL3.2V +12V(A) P.C.B. +12V(A) AL3.2V FLCTL VOUT VOUT VMONIT UNREGST (ST1) UNREGST UNREGST UNREGST TRIGGER TRANS SUBGT2 SUBGT2 SUBGT SUBGT MSUBSW... -
Page 41: Printed Circuit Board
12 Printed Circuit Board 12.1. Fuse location on MAIN P.C.B. The following drawings show the location of the fuse on MAIN P.C.B. [FOIL SIDE ....: F5001,F5002 COMPONENT SIDE..: F5005,F5006] F5002 F5001 F2 2A F5002 F5001 JW184 GY BK JW181 JW182 JW183 (FOIL SIDE) - Page 42 S1. Replacement Parts List Note: 1. *Be sure to make your orders of replacement parts according to this list. 2. IMPORTANT SAFETY NOTICE Components identified with the mark have the special characteristics for safety. When replacing any of these components, use only the same type. 3.
- Page 43 S2. Exploded View S2.1. Frame and Casing Section (1) 13-1 24-2 24-1 24-3 17-2 17-1 13-2...
- Page 44 S2.2. Frame and Casing Section (2)
- Page 45 S2.3. Packing Parts and Accessories Section (DMC-F3EE/EF/EG/EP/GF, F4EE/EG/EP) (DMC-F3EB/GC,F4EB) (EXCEPT:DMC-F3P/PC/PU) (DMC-F3GN) (DMC-F3P/PC/PU) (DMC-F3PR) (DMC-F3GT)
- Page 46 DMC-F3, F4 Series Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks ---- ELECTRICAL REPLACEMENT PARTS SECTION -------- [S2.2.Frame & Casing section (2)] F5001 VU4230340905 FUSE 32V/2A 1 (INCLUDED IN MAIN P.C.B.) F5002 VU4230340905 FUSE 32V/2A 1 (INCLUDED IN MAIN P.C.B.) VU6361420211 FRONT/TOP CASE KIT...
- Page 47 DMC-F3, F4 Series Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQT2K37 O/I SOFTWARE 1 F3P/PC VQT2K39 O/I SOFTWARE 1 F3EG, F4EG VQT2K38 O/I SOFTWARE 1 F3PU/PR [ S2.3.PackingPartsandAccessoriesSection ] VQT2K40 O/I SOFTWARE 1 F3EP, F4EP DE-A60AA BATTERY CHARGER...
