SERVICE MANUAL
Ver. 2 2006A
Revision History
Area
Model
American
US Canadian
2006A0500-1
© 2006 Sony Corporation
Published by VBD VAIO-GS Division
9-876-535-02
Lineup
VGC-RC110G
VGC-RC210G
[MA]
1
VGC-RC Series
This manual and the constituent data may not be
replicated, copied nor reprinted in whole or in part
without prior written authorization of Sony Corporation.
• Design and specifications are subject to change
without notice.
PERSONAL COMPUTER
S400
Advertisement
Related Manuals for Sony Vaio VGC-RC Series
Summary of Contents for Sony Vaio VGC-RC Series
- Page 1 [MA] S400 This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. • Design and specifications are subject to change without notice. PERSONAL COMPUTER 2006A0500-1 ©...
- Page 2 Service and Inspection Precautions 1. Obey precautionary markings and instructions Sony, VAIO and CLIE are trademarks or registered trademarks of Sony. Microsoft, Windows, Windows Labels and stamps on the cabinet, chassis, and components identify areas requiring special precau- Media, Outlook, Bookshelf and other Microsoft products are trademarks or registered trademarks of tions.
-
Page 3: Table Of Contents
CHAPTER 3. EXPLODED VIEWS AND PARTS LIST 3-1. Exploded View ........................3-1 (to 3-4) 3-2. Parts List ..........................3-5 (to 3-6) History of the changes is shown as the “Revision History” at the end of this data. – 3 – Sony Confidential VGC-RC Series (AM) -
Page 4: Chapter 1. Disassembly
Card Reader P1-4 P1-5 DVD-ROM Drive P1-7 P1-4 ENX-26 (US F) VGA (RADEON X300) Card AS/W Bracket Assy P1-3 P1-2 Memory P1-9 P1-8 CNX-334 MDC Modem Board P1-8 P1-6 Mother Board Switching Power P1-10 P1-11 Sony Confidential VGC-RC Series (AM) - Page 5 2 COVER R Assy ENX-26 (US F) AS/W BRACKET ASSY 1 Remove a connector. 2 Remove a screw. 3 Remove the ENX-26 (US F) AS/ FLOWCHART W Bracket Assy. 3 ENX-26 (US F) AS/W Bracket Assy Sony Confidential VGC-RC Series (AM)
- Page 6 3 Remove the HDD Door Assy. 4 Remove three claws. FLOWCHART 6 Side Door 5 Remove three claws. Assy 6 Remove the Side Door Assy. 7 Remove six claws. 8 Remove the Bezel Assy. 3 HDD Door Assy Sony Confidential VGC-RC Series (AM)
- Page 7 2 Remove a connector (power). 3 Remove FLOWCHART two screws. 4 Remove DVD+-RW Drive. 5 Remove a connector (ODD ATA66). 2 Remove a connector (power). 3 Remove two screws. 8 DVD-ROM Drive 4 Remove DVD-ROM Drive. Sony Confidential VGC-RC Series (AM)
- Page 8 7 Remove four claws. 8 Pull out the Heatsink Assy in the direction of arrow. 9 Remove a connector (DC Fan) 0 Remove the harness from Cable Clamp. qa Remove the 130W Heatsink Assy. 8qa130W Heatsink Assy Sony Confidential VGC-RC Series (AM)
- Page 9 6 CNX-334 Board 2 Pull out the AV PCB BKT Assy in the direction of arrow. FLOWCHART 3 Remove a connector (Video Harness). 4 Remove a connector (Audio Harness). 5 Remove two screws. 6 Remove CNX-334 Board. Sony Confidential VGC-RC Series (AM)
- Page 10 1 Remove a connector (Mini USB+1Port USB). 2 Remove two screws. FLOWCHART 3 Pull out the Card Reader in the direction of arrow. 4 Remove a connector (Mini USB). 5 Remove The Card Reader. 35 Card Reader Sony Confidential VGC-RC Series (AM)
- Page 11 : 0.5 g (as the same size as the tip of a match) (Pentium 4) at the splatter) * Take care not to apply the grease to any other places because it has high conductivity. Sony Confidential VGC-RC Series (AM)
- Page 12 Note2 : Make sure that clips are closed when the memory were inserted completely. Clip Note3 : Insert the memory, starting from the one having smallest bank number. Clip Boss DIMM soket Sony Confidential VGC-RC Series (AM)
- Page 13 MOTHER BOARD 1 Remove fourteen connectors. SATA cable 2 Remove seven screws. 3 Remove a boss. FLOWCHART 4 Remove the Mother Board in the direction of arrow. two claws 4 Mother Board Sony Confidential 1-10 VGC-RC Series (AM)
- Page 14 SWITCHING POWER 1 Remove two connectors (power) 2 Remove four screws. FLOWCHART 3 Remove the cable from Cable Clamps. 4 Remove the Switching Power in the direction of arrow. 4 Switching Power Sony Confidential 1-11 (END) VGC-RC Series (AM)
-
Page 15: Chapter 2. Frame Harness Diagram
Harness (SATA TYPE3) CAUTION POWER Do not change the jumper with the power turned on. Harness (SATA TYPE4) Before changing the jumper, turn off the power and disconnect the power cord from the set. Sony Confidential (END) VGC-RC Series (AM) -
Page 16: Chapter 3. Exploded Views And Parts List
CHAPTER 3. EXPLODED VIEWS AND PARTS LIST 3-1. Exploded View COVER SECTION drive section Sony Confidential VGC-RC Series (AM) - Page 17 DRIVE SECTION board section Sony Confidential VGC-RC Series (AM)
- Page 18 BOARD SECTION Sony Confidential VGC-RC Series (AM)
- Page 19 ACCESSORIES REMOTE COMMANDER (RM-MC10) IR RECEIVER MOUSE (USB) BATTERY COVER KEY BOARD SYSTEM SPEAKER (BOX TYPE) VIDEO CONTROLLER CORD, AC Sony Confidential VGC-RC Series (AM)
-
Page 20: Parts List
SCREW (NO.6-32UNC) EXTERIOR 2-649-474-01 DOOR IO 4-645-944-22 SCREW (SW) (NO.6-32UNC) 2-649-473-01 DOOR CARDREADER 4-673-018-02 SCREW SPECIAL HEAD 4-680-025-01 +PWH3X5 7-682-546-04 SCREW +B 3X5 4-218-254-22 SCREW (M2.6), +PTPWH 1-528-174-31 BATTERY, LITHIUM (CR2032 TYPE) 7-300-004-33 COMPOUND,SILICON (X-23-7762)1G Sony Confidential VGC-RC Series (AM) - Page 21 A-1178-697-A HDD/S-AYUMA-S (160GB) ASSY(S) 1-797-341-21 8-457-676-20 DRIVE, DVD DW-Q28A-VH 8-457-676-30 DRIVE, DVD DW-Q28A-VK 1-797-367-21 DVD+-RW/P-110-F 8-457-676-30 DRIVE, DVD DW-Q28A-VK 8-449-659-10 DVD-ROM DRIVE DDU1615-VR 8-457-676-20 DRIVE, DVD DW-Q28A-VH A-1057-182-A AOI (US H/B MCE) W/CARTON ASSY 1-777-786-12 CORD, AC Sony Confidential (END) VGC-RC Series (AM)
- Page 22 Revision History Suffix Ver. Date Contents QM No. Ver. 1 2005.09.26 First Edition Ver. 2 2006.01.12 Model Lineup FIT-D2005_156 [Sony Confidential] VGC-RC Series (AM)
