- Page 1 QUICK REFERENCE GUIDE 2020...
- Page 2 Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.
- Page 3 INDEX OVERVIEW SAFETY & EMERGENCY FEATURES Floor mat installation Engine maintenance Seat belts Fuel tank door release & cap Spare tire & tools Hood release Star Safety System 26-27 ™ Indicator symbols Tire Pressure Monitoring Instrument cluster (warning) System (TPMS) Instrument panel Trunk-Internal release Instrument panel light control...
-
Page 4: Instrument Panel
OVERVIEW Instrument panel Paddle shifters* Meter control switches* Ignition switch* (behind the steering wheel) Audio control switches Cruise control switch Steering wheel controls Meters/Multi-Information Display (MID) Windshield wiper and washer control Headlight, turn signal and fog light* control Instrument panel light control Trunk opener switch “ENGINE START STOP”... - Page 5 * If equipped Air conditioning/heating controls Manual air conditioning/heating controls Emergency flasher switch Clock Rear window and outside rear view mirror defogger*/rear window defogger* switch rols Automatic air conditioning/heating cont USB media/AUX port Seat heaters* TRACK mode switch SPORT or SNOW mode switch* Power outlet Vehicle Stability Control (VSC)/TRAC OFF switch...
-
Page 6: Instrument Cluster
OVERVIEW Instrument cluster Monochrome display Tachometer Analog speedometer Fuel gauge km/h MPH switch Odometer/Trip meter Engine coolant temperature /Multi-Information Display gauge* Display switch* Digital speedometer Odometer/trip meter display change switch * If equipped Service indicators and reminders Color display* Tachometer Analog speedometer Digital speedometer km/h MPH switch... -
Page 7: Indicator Symbols
If the indicator does not turn off within a few seconds of starting the engine, there may be a malfunction. Have the vehicle inspected by your Toyota dealer. If the indicator flashes, there may be a malfunction. Refer to the Owner’s Manual. -
Page 8: Keyless Entry
OVERVIEW Keyless entry UNLOCKING OPERATION Smart Key Carry Smart Key remote Driver door unlock* Push ONCE: Driver door Grasp TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. * Driver door unlocking function can be programmed to unlock driver door only, or all doors. -
Page 9: Smart Key System ( If Equipped )
Smart Key system ( if equipped START FUNCTION NOTE: The Smart Key must be carried to enable the start function. With gear shift lever in Park and the brake pedal depressed (automatic transmission)/ with the gear shift lever in N and the clutch pedal depressed (manual transmission), push the “ENGINE START STOP”... -
Page 10: Hood Release
OVERVIEW Hood release Pull Push latch to the left and raise hood Grip When holding a supporting rod, hold it by the grip portion. Instrument panel light control Brightness control Brighter Darker... -
Page 11: Engine Maintenance
Engine maintenance Engine oil level dipstick Engine oil filler cap Engine coolant reservoir Windshield washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”... -
Page 12: Features & Operations
FEATURES & OPERATIONS Automatic transmission (if equipped) Shift lever + (“M” mode) Park* Reverse - (“M” mode) Neutral Paddle shifters* Drive “M” mode - (“M” mode) + (“M” mode) *If equipped * The engine switch must be in the “ON” position (without Smart Key) / “IGNITION ON”... -
Page 13: Driving Mode Select
Driving mode select AUTOMATIC TRANSMISSION (IF EQUIPPED) NORMAL SPORT SNOW Normal mode Sport mode Use for sporty driving or when driving in mountainous regions with lots of curves. Press this switch and the “SPORT” indicator illuminates. Snow mode Use for accelerating and driving on slippery road surfaces such as snow. Press this switch and the “SNOW”... -
Page 14: Cruise Control
FEATURES & OPERATIONS Cruise control TURNING SYSTEM ON/OFF System ON/OFF FUNCTIONS Resume Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal or the clutch pedal (manual transmission). The set speed may be resumed once vehicle speed exceeds 20 mph. Hill-start Assist Control (HAC) Hill-start assist control (HAC) helps to maintain braking force to assist starting off forward while facing uphill or starting off backward while facing downhill. -
Page 15: Vehicle Stability Control (Vsc)
Vehicle Stability Control (VSC)/ TRAC OFF switch The VSC OFF switch can be used to help free a stuck vehicle in surroundings like mud, dirt or snow. While the vehicle is stopped, press switch to disable the TRAC system. To disable both VSC and TRAC systems, press and hold the switch for at least 3 seconds. -
Page 16: Lights & Turn Signals
FEATURES & OPERATIONS Lights & turn signals HEADLIGHTS Low beam High beam flasher Headlights Parking lights AUTO High beam Daytime Running Light system (DRL) Automatically turns on under certain conditions to make vehicle more visible to other drivers. Not for use at night. Automatic light cut off system Automatically turns lights off after 30 second delay, or lock switch on remote is pushed after locking. -
Page 17: Seat Adjustments-Front
Seat adjustments-Front Seat position Seatback lock release (forward/backward) Seatback angle Height crank (diver’s side only) Seats-Folding rear Fold down Pull Seats-Head restraints Height Lock release button... -
Page 18: Multi-Information Display (Mid)
FEATURES & OPERATIONS Multi-Information Display (MID) MONOCHROME DISPLAY (IF EQUIPPED) Push “ODO TRIP” to change information in the following: (1) Odometer (2) Trip meter (3) Setting screen for the shift position indicator and shift-up indicator (manual transmission) Push “DISP” to change information in the following: (1) Outside temperature (2) Current fuel consumption (3) Average fuel consumption... -
Page 19: Steering Wheel Switches
Steering wheel switches Meter control switches Enter “ ” Select menu icons. “ ” Change displayed Returns to the previous screen. content, scroll up/down the screen and move the cursor Audio control switches “ ” Volume buttons. “ ” Use to search within “MODE”... -
Page 20: Steering Lock Release
FEATURES & OPERATIONS Steering lock release Without Smart Key system With Smart Key system Turn Turn Turn Push When starting the engine, the engine A message will be displayed on the switch may seem stuck in the “LOCK” multi-information display. position. -
Page 21: Trunk Release
Clock Round off Hour set minutes Minute set The engine switch must be in the “ACC” or “ON” position (without Smart Key) / ”ACCESSORY” or IGNITION ON” mode (with Smart Key) for use. Trunk release From inside From outside (without Smart Key) Push and hold... - Page 22 FEATURES & OPERATIONS Audio Touch screen display POWER/HOME button Volume controls button Voice recognition button [POWER/HOME button functions] Short press: Go to HOME screen Long press: Turn off Audio and Display Longer press greater than 6 seconds: Option to restart the Multimedia System [Volume controls buttons functions] Short press: Decrease/Increase volume of current source*by one-step Long press: Decrease/Increase volume of current source* continuously until button release or until...
-
Page 23: Power Outlets-12V Dc
USB media port Connecting a compatible device and cable into the USB media port will support charging and music playback through the audio multimedia system. Refer to the Owner’s Manual for more details. Power outlets-12V DC Console tray Glove box Designed for car accessories. -
Page 24: Air Conditioning/Heating
FEATURES & OPERATIONS Air conditioning/heating Manual air conditioning (if equipped) Airflow vent Rear window and outside “ ” and “ ” mode uses outside air only rear view mirror defoggers Temperature selector Air Conditioning ON/OFF Recirculate cabin air Fan speed Windshield airflow (outside air when OFF) Automatic air conditioning (if equipped) -
Page 25: Seat Heaters (If Equipped)
Seat heaters (if equipped) Rapid heating Normal heating The engine switch must be in “IGNITION ON” mode for use. Cup/bottle holders CUP HOLDERS Changing the position Changing the tray size Removing the cup holder BOTTLE HOLDERS (DOOR MOUNTED) -
Page 26: Safety & Emergency Features
If the light does not turn off, have the system checked by your Toyota dealer. If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. Refer to the Owner’s Manual for more details. Trunk-Internal release... -
Page 27: Spare Tire And Tools
Spare tire & tools TOOL LOCATION Screwdriver Jack handle Towing eyelet Wheel nut wrench Jack Spare tire Spacer* * Vehicles with a T145/70D17 compact spare tire REMOVING THE SPARE TIRE (1) Remove the spare tire cover. (2) Loosen and remove the bolt. Refer to the Owner’s Manual for jack positioning and tire changing procedures. -
Page 28: Star Safety System
ANTI-LOCK BRAKE SYSTEM (ABS) Toyota’s ABS sensors detect which wheels are locking up and limits wheel lockup by “pulsing” each wheel’s brakes independently. Pulsing releases brake pressure repeatedly for fractions of a second. This helps the tires attain the traction that current road conditions will allow, helping you to stay in directional control. -
Page 29: Traction Control (Trac)
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track. -
Page 30: Pairing Bluetooth
PAIRING BLUETOOTH PHONE FOR THE FIRST TIME ® ® **Do not attempt the Bluetooth Pairing process while driving.** ® To pair your compatible Bluetooth device, follow the steps below. 1. Touch the settings icon the HOME screen to display the functions menu. - Page 31 6. Touch [PAIR] to begin the pairing process. Once the pairing process is completed, a confirmation message is shown. 7. Touch [OK] on the message screen to complete the pairing process. The Multimedia System will automatically initiate the download of contacts, call history and messages.
- Page 32 Quick Reference Guide 2020 toyota.com Printed in U.S.A. 8/19 19-MKG-13485...
