USB
128MB–512MB JetFlash™
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Transcend USB JetFlash

Summary of Contents for Transcend USB JetFlash

  • Page 1 128MB–512MB JetFlash™ User’s Manual...

  • Page 2: Table Of Contents

    Table of Contents Introduction Package Contents ... 1 Features ... 1 System Requirements ... 2 Before Use ... 2 Driver Installation Driver Installation for Windows 98SE... 3 Driver Installation for Windows Me, 2000, and XP ... 4 Driver Installation for Mac OS 9.0 or Later... 4 Driver Installation for Linux Kernel 2.4 or Later ...
  • Page 3 MP3 Function To Download or Upload MP3/WMA files ... 10 To Play MP3 Music... 11 AB Repeat Function Voice Recording Function To Record Voice... 11 To Play the Recorded Files ... 12 LED Indication ... 13 Recover JetFlash To Recover JetFlash in Windows 98SE ... 13 To Recover JetFlash in Windows Me, 2000, and XP ...

  • Page 4: Package Contents

    Thank you very much for purchasing Transcend’s JetFlash™. This small device is more than a USB Flash Drive. It combines a USB Flash Drive with MP3, AB repeat, and voice recording functions. With a USB connector, it can expedite exchanging huge amounts of data between any desktop or laptop computers with a USB port.

  • Page 5: System Requirements

    recorder; Power Saving Function: Auto-powers off after two minutes without use. • LEDs indicate the usage status of JetFlash. • System Requirements Desktop or notebook computer with USB port One of following operating systems: Windows 98SE • Windows Me • Windows 2000 •...

  • Page 6: Driver Installation

    Driver Installation for Windows 98SE Put the Driver CD into the CD-ROM (Auto-Run supported). Click Win98 Driver button. Click Next to continue. The Install Shield Wizard guides you through the installation process. Driver Installation...

  • Page 7: Driver Installation For Windows Me, 2000, And Xp

    Plug JetFlash into an available USB port. Your computer automatically detects this new device. A new Removable Disk drive with a newly assigned drive letter appears in the My Computer window. Driver Installation for Windows Me, 2000, and XP No driver is required. These Windows operating systems have built-in drivers to support JetFlash.

  • Page 8: Driver Installation For Linux Kernel 2.4 Or Later

    Driver Installation for Linux Kernel 2.4 or Later No driver is required. Just plug JetFlash into the USB port and mount it. Example: Create directory of /mnt/JetFlash first: mkdir /mnt/JetFlash mount JetFlash: mount –a –t msdos /dev/sda1 /mnt/JetFlash After installing the driver, simply plug JetFlash into an available USB port and you can use it like a hard drive or other data storage device.

  • Page 9: Uninstall

    Put the Driver CD into the CD-ROM (Auto-Run supported). Click Win98 Driver button. Click OK to continue. How to Unplug JetFlash Safely Before removing JetFlash, please make sure the LED is not flashing! If you remove JetFlash while the LED is flashing, unpredictable damage to the files or JetFlash may occur.

  • Page 10: To Remove Jetflash In Windows 98Se

    To Remove JetFlash in Windows 98SE Unplug JetFlash from your system directly when data are not transferring. To Remove JetFlash in Windows Me, 2000, and XP Click the icon on the system tray. The Safely remove USB Mass Storage Device pop-up menu will appear. Click to continue.

  • Page 11: Product Overview

    Enter MP3 Mode 1. Disconnect JetFlash from your computer. 2. Press and hold the PLAY/PAUSE MP3 mode). The Power/Play LED turns green. To exit from MP3 mode, press and hold the PLAY/PAUSE seconds till the LED turns off. Enter Record Mode 1.

  • Page 12: Play A Track

    Play a Track Press the PLAY/PAUSE Power/Play LED blinks green and there is track playback. If there is no track in your JetFlash, the Power/Play LED turns green. Pause a Track Press the PLAY/PAUSE LED turns green and the track is paused. To resume track playback, press the PLAY/PAUSE button again.

  • Page 13: Repeat All Tracks

    Repeat All Tracks Press the Track Control Wheel Control Wheel orange. To resume normal playback, press the Track Control Wheel Repeat a Portion of One Track (AB Repeat) 1. Press the Volume Control Wheel wish to repeat. The Repeat LED blinks orange. 2.

  • Page 14: To Play Mp3 Music

    To Play MP3 Music Make sure you have downloaded MP3 or WMA files to the root directory of your JetFlash. Disconnect JetFlash from your computer. Connect the earphone with the earphone jack Set HOLD switch to “OFF” position. Press and hold the PLAY/PAUSE MP3 mode).

  • Page 15: To Play The Recorded Files

    Press and hold the REC Record LED turns red. Press the REC Press the REC Press the REC The recorded files (VXXX.WAV format) are saved on the folder “Voice”, in an ascending order. With sufficient power: 128MB memory can store up to 9 hours of recorded voice. To achieve better quality recording, please keep voice source close to the microphone of JetFlash.

  • Page 16: Led Indication

    Record LED Power/Play LED (Red) (Green) fast blink normal blink normal blink normal blink normal blink normal blink normal blink normal blink normal blink normal blink normal blink normal blink If your JetFlash is ever damaged, you can use the Recovery program to restore its default settings.
  • Page 17 Do not release the PLAY/PAUSE completed. Found New Hardware and New Hardware Found messages appear. (Only the first time you recover the JetFlash.) Click the Recovery button on the JetFlash splash screen. MSCN Format status bar message appears. If above message does not appear, click the Recovery button on the JetFlash splash button until the Recovery procedures are...
  • Page 18 screen again. If this still doesn’t work, press and hold PLAY/PAUSE re-plug JetFlash first. Then, click the Recovery button on the JetFlash splash screen again. New Hardware Found messages appear. (Only the first time you run the Recovery program.) Click the Recovery button on the JetFlash windows splash screen again. MSCN Format dialog box appears.
  • Page 19 remains unchecked. Click Start to initiate the low-level format. 10. Complete message appears. Click Close to complete the Recovery procedures. 11. Release the PLAY/PAUSE status for your usage. button. JetFlash has been returned to its initial...

  • Page 20: To Recover Jetflash In Windows Me, 2000, And Xp

    To Recover JetFlash in Windows Me, 2000, and XP Skip steps 1-3 if the Utility program has already been installed. Put the Driver CD into the CD-ROM (Auto-Run supported) and click the Utility button on the JetFlash splash screen. SigmaTel MSCN Audio Player Setup window appears. Click Next to continue. The InstallShield Wizard guides you through the Utility installation.
  • Page 21 Press and hold the PLAY/PAUSE USB port. Do not release the PLAY/PAUSE completed. Found New Hardware messages appear. (Only the first time you recover the JetFlash.) If using Windows Me or 2000, go directly to step 9. Wait a while until Found New Hardware Wizard windows appears. Click Next to continue.
  • Page 22 Found New Hardware Wizard window appears. Click Finish to continue. (Only appears the first time you recover the JetFlash.) Click the Recovery button on the JetFlash splash screen. 10. MSCN Format status bar message appears. If above message does not appear, click the Recovery button on the JetFlash splash screen again.
  • Page 23 If using Windows Me or 2000, go directly to step 15. 12. Found New Hardware Wizard window appears. Click Next to continue. (Only appears the first time you run the Recovery program.) 13. Found New Hardware Wizard window appears. Click Next to continue. (Only appears the first time you run the Recovery program.)
  • Page 24 14. Completing the Found New Hardware Wizard message appears. Click Finish to continue. (Only appears the first time you run the Recovery program.) 15. MSCN Format dialog box appears. Click Start in the Media Recovery tab to initiate the low-level format.
  • Page 25 16. Complete message box appears. Click Close to complete the Recovery procedures. 17. Release the PLAY/PAUSE button. JetFlash has been returned to its initial status for your usage.

  • Page 26: Troubleshooting

    Q1: Why doesn’t the driver CD Auto-Run after it is inserted into the CD-ROM drive in Windows? A1: This problem usually occurs because the Auto-Insert function of the CD-ROM drive is disabled. Please enter Device Manager in Control Panel and enable the Auto-Insert function of the CD-ROM drive.
  • Page 27 Why do the three LEDs just blink a moment and extinguish when press the PLAY/PAUSE button to turn on JetFlash? A7: Please press and hold the PLAY/PAUSE button a second or two longer, until the three LEDs blink once and the Power/Play LED turns green. If the problem persists, please check to see whether the battery power is used up.
  • Page 28 Q13: Why does JetFlash turn off automatically after entering MP3 mode or Record mode? A13: JetFlash features a power-save function. If your JetFlash is idle for two minutes, power-save is triggered and the power turns off automatically. Q14: Why is JetFlash automatically removed from the operating system when I use it as a USB Flash Drive? A14: This problem occurs when you press the PLAY/PAUSE JetFlash is connected with a USB port.

  • Page 29: Specifications

    Specifications Size: 97 mm × 31 mm × 18 mm • Weight: 25 g (without battery) • Data retention: Up to 10 years • Shock resistance: 1000 G (maximum) • Erase cycles: 1,000,000 times • Signal-to-Noise Ratio: 90dB • Output frequency: 20Hz–20KHz •...
  • Page 30 This warranty is not affected in any part by Transcend providing technical support or advice. Transcend Information, Inc. www.transcendusa.com The Transcend logo is a registered trademark of Transcend Information, Inc. *All logos and marks are trademarks of their respective companies.
