- Page 1 USER’ S TFT LCD MONITOR MANUAL MODEL: TME19WE/TME22WE/TME24WE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS FCC information ---------------------------------------------------------------------- 3 CE information ------------------------------------------------------------------------ 3 Safety Precautions ------------------------------------------------------------------- 3 Scope -------------------------------------------------------------------------------------- 5 Functional specification ------------------------------------------------------------- 5 Controls and indicators -------------------------------------------------------------- 6 OSD Menu --------------------------------------------------------------------------------7 Mechanical ----------------------------------------------------------------------------- 9... -
Page 3: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 4 8. Route power cords so that they cannot be walked upon or tripped over. Do not allow anything to rest on the power cord. 9. Do not install monitor in wet areas, or where it may be exposed to rain or water. Do not spill liquid of any kind on the unit.
-
Page 5: Scope
BNC input and HDMI input. In BNC mode, the system can automatically detect the NTSC signal and PAL signal. In HDMI mode, this system can support up to 1920 x 1080 VESA standard (TME19WE only supports up to 1600x900). The user friendly OSD menu is also provided to make this system easy to operate. -
Page 6: Controls And Indicators
DC INPUT: Use the supplied 12V DC power supply HDMI: HDMI Connector HD Analogue 1 IN: BNC Connector support CVBS/TVI/AHD/CVI HD Analogue 2 IN: BNC Connector support CVBS/TVI/AHD/CVI HD Analogue 2 OUT: BNC Connector support CVBS/TVI/AHD/CVI Set up sequence Make sure the power of PC and/or Video source were turned off. Connect the video signal to monitor. -
Page 7: Osd Menu
4. OSD Menu BNC (HD Analogue) mode ： PICTURE Picture Brightness Menu Contrast Information Saturation Exit Brightness: Adjust the image brightness (0-100) Contrast: Adjust the image contrast (0–100) Saturation： Adjust the image Saturation (0–100) Hue: Adjust the image hue (0–100) MENU Picture Language... - Page 8 Information 720P25 Exit Display video format, resolution, and frequency of the video signal HDMI mode ： PICTURE Picture Brightness Menu Contrast Information Saturation Exit Brightness: Adjust the image brightness (0-100) Contrast: Adjust the image contrast (0–100) Saturation： Adjust the image Saturation (0–100) Hue: Adjust the image hue (0–100) MENU...
-
Page 9: Mechanical
Display video format, resolution, and frequency of the video signal 5. Mechanical 5.1 Cabinet Material: Plastic Finish: Black 5.2 Dimensions Model Unit 461.7 275.8 350.6 43.5 127.0 TME19WE Inch 18.18 10.86 13.80 1.71 508.0 305.9 379.4 43.3 137.0 TME22WE Inch 20.0... - Page 10 - Size Unit Model TME19WE Inch 19.88 13.78 4.33 TME22WE Inch 21.57 14.57 4.33 TME24WE Inch 23.54 15.75 4.33 - Weight: TATUNG COMPANY OF AMERICA, Model TME19WE 7.72 INC. TME22WE 3.75 8.27 LIMITED WARRANTY TME24WE 10.58 COMMERCIAL DISPLAY MONITOR PRODU...
- Page 11 Tatung Company of America, Inc. (“Tatung”) warrants to you, the original commercial purchaser of this new Tatung product (the “product”), that all parts of this product will be free from defects in materials or workmanship, as hereinafter provided, for three years from the date of original purchase.
- Page 12 1. Defects, malfunction or failures resulting from causes beyond the control of Tatung or the manufacturer of the product, including, but not limited to, shipping or transit accident, abuse, misuse, operation contrary to furnished instructions, improper or insufficient ventilation, operations with incorrect power supplies, operation with...
- Page 13 This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This is the only express warranty applicable to the product; Tatung neither assumes nor authorizes anyone to assume for it any other express warranty. This...
