EN
WSD-F30
User's Guide
Thank you for purchasing this watch.
Before trying to use this watch, be sure to read the Safety Precautions in
the Quick Start Guide that comes with it. Make sure you use the watch
correctly.
© 2019 CASIO COMPUTER CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Casio WSD-F30

Summary of Contents for Casio WSD-F30

  • Page 1 Thank you for purchasing this watch. Before trying to use this watch, be sure to read the Safety Precautions in the Quick Start Guide that comes with it. Make sure you use the watch correctly. © 2019 CASIO COMPUTER CO., LTD.

  • Page 2: Table Of Contents

    About This Manual ............... EN-7 Getting Ready ................... EN-8 Basic Operations You Should Remember ........EN-14 Using Outdoor Watch Functions - Using CASIO Watch Faces and Apps ......................EN-19 Using CASIO Watch Faces ............EN-20 Using the Location Memory App ..........EN-23 Using the TOOL App ..............

  • Page 3: Introduction

    Your watch comes with a dual-layer color and monochrome display. The color display employs high contrast ratio organic electroluminescence (EL). The monochrome display is designed to show a greater amount of information (compared with previous CASIO products). Extend Mode Extend Mode activates an original power management system for the dual- layer display, which allows access to maps and GPS, even during overnight activities.
  • Page 4 Five-atmosphere Water Resistance + MIL-STD Even though this watch has a built-in voice recognition microphone, it still is water resistant up to five atmospheres. This means you can wear your watch while swimming, fishing, etc. MIL-STD-810G standard environment resistance allows you to wear your watch while engaged in a variety of vigorous outdoor activities, including: mountain climbing, cycle sports, fishing, and more.

  • Page 5: Measurement Functions

    Measurement Functions Your watch can take barometric pressure, altitude, bearing, and other readings. Its built-in watch faces and applications can use readings for display and other useful functions. Note that this watch is not a special purpose measuring instrument. Readings produced by measurement functions are intended as general reference information only.
  • Page 6 Altimeter, Barometer The watch’s Altimeter uses a pressure sensor to measure barometric pressure, and then calculates and displays relative altitude based on the measured value. Because of this, readings taken at different times at the same location may produce different altitude values due to changes in temperature, humidity, barometric pressure, and other factors.

  • Page 7: Overview

    Overview Package Contents Watch, AC adaptor, charger cable, Quick Start Guide, warranty General Guide ① ② ⑤ ⑥ ③ ⑦ ⑧ ④ A Charge LED E MAP button B Charger terminal F Power button C Pressure sensor G TOOL button D Microphone H Touch screen EN-6...

  • Page 8: About This Manual

    CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost ● profits due to loss of data caused by malfunction or maintenance of this product, or any other reason.

  • Page 9: Getting Ready

    Getting Ready Be sure to read the precautions in the “Quick Start Guide”, and also perform all of the steps under “Preparing the Watch for First Use” and “Preparing the Watch for Outdoor Use”. Preparing the Watch for First Use You must perform the steps below before using the watch for the first time.
  • Page 10 4. Install the CASIO MOMENT SETTER+ App on the Smartphone (Android Only) If you are using an Android smartphone, download the “CASIO MOMENT SETTER+” app on Google Play and install it. You can use the CASIO MOMENT SETTER+ app to configure the following watch settings from your smartphone:...
  • Page 11 In order to use all of the functionality provided by this watch, be sure to ● update all of your related CASIO apps to their latest versions before using your watch. For information about the update procedure, visit the website below.
  • Page 12 Apps for which updates are available will be shown under ● “Updates”. 4. If there is an update available for CASIO MOMENT SETTER+, be sure to update it. Updating any other apps that are available is also recommended. EN-11...
  • Page 13 GPS, Wi-Fi, and mobile network (data communication) settings. The settings in the steps below are required to enable the following functions: CASIO watch faces, the Location Memory app, the TOOL app, the Activity app, and all functions of the MOMENT SETTER app.
  • Page 14 5. Turn on the “Save daily activity records” setting. 1. While a watch face is displayed, press the TOOL button to display the Tool app. 2. Swipe the touch screen from right to left. On the “Settings” screen that appears, tap D to display the settings menu. 3.

  • Page 15: Basic Operations You Should Remember

    Basic Operations You Should Remember Important! Note that the operations described here are subject to change due to the ● type and version of the operating system being used by the smartphone connected with the watch, changes that occur when the watch’s operating system is updated, and other factors.
  • Page 16 Wake Up If you don’t tap the touch screen for a few seconds, the watch screen will dim. To wake up the watch and restore it to normal brightness, tap the touch screen or press the power button. Power Supply Operations To do this: Perform this operation: Charge the...
  • Page 17 Note For details about watch face operations, visit the website below. ● https://support.google.com/wearos/ For information about CASIO watch faces, see “Using CASIO Watch ● Faces”. EN-16...
  • Page 18 For information about the Location Memory, Point Navigation, TOOL, ● Activity, MOMENT SETTER, Extend Mode and Multi Timepiece apps, see “Using Outdoor Watch Functions - Using CASIO Watch Faces and Apps”. For details about Google apps (standard Wear OS by Google apps), visit ●...
  • Page 19 Though you can use a wide range of functions without connecting to a smartphone, some apps and services (dictation, smartphone related apps, etc.) are not available unless there is a connection between the watch and a smartphone. For details, visit the websites below. https://support.google.com/wearos/ https://support.casio.com/wsd/ EN-18...

  • Page 20: Using Outdoor Watch Functions - Using Casio Watch Faces And Apps

    Using Outdoor Watch Functions - Using CASIO Watch Faces and Apps This section explains how to interpret the contents of CASIO watch faces and how to use CASIO apps and make your outdoor adventures more interesting and enjoyable. Use this app:...

  • Page 21: Using Casio Watch Faces

    Using CASIO Watch Faces Your watch comes with the CASIO Watch Faces described below built in. Watch face names are used in the list of favorite watch faces and the list of all watch faces (see “Watch Face Operations”). Frontier Analog watch face on which areas you visit are color highlighted on a map.
  • Page 22 Important! While the “Always-on screen ” setting is off (default setting), the watch will ● automatically switch to the monochrome LCD when display illumination dims after the prescribed period of non-use, regardless of the currently selected watch face. To switch back to the original watch face, tap the touch screen.
  • Page 23 Settings” and perform one or more of the operations below. To calibrate this: See the information here: Barometer “Barometric Pressure Calibration” Altimeter “Altitude Calibration”, “Correct Altitude Using Location” Compass “Compass Calibration”, “Compass Magnetic Declination Calibration” Changing CASIO Watch Face Settings “Common Outdoor Function Settings”. EN-22...

  • Page 24: Using The Location Memory App

    Using the Location Memory App The Location Memory app makes it quick and easy to record map-related information. You can use the Location Memory app to perform the operations described below. Display a map to check your current location. ● Select from a variety of different map skins including street view, geographic ●...
  • Page 25 Location Memory App Basic Operations You can perform main Location Memory app operations using the MAP button and TOOL button. The operations you can perform with these two buttons are indicated by on-screen icons displayed to the left of each button. You can also perform the operations by tapping the icons.
  • Page 26 In order to be able to receive notifications triggered by “Revisit” marks, your ● Android phone must have the CASIO MOMENT SETTER+ app installed, and there must be a connection between the phone and watch. Note that notification receipt triggered by “Revisit” marks is not supported ●...
  • Page 27 Other Operations To view a recorded memo, swipe the displayed map from bottom to top. On ● the menu that appears, tap “History”. For information about how to track your route on a map, see “Enabling Route ● Tracking on the Map (Route Display)”.
  • Page 28 To display your route, use the procedure below to change “Route Display” on the setting menu from “OFF” (initial default setting) to “ON”. 1. While the map is displayed, swipe the touch screen from bottom to top. On the menu that appears, tap “Settings”. 2.
  • Page 29 Changing the “Revisit” Mark Notification Setting Use “Revisit” marks to record a mark and have the watch alert you whenever you are in the vicinity. Under the watch’s initial default settings, notification is performed when both of the conditions below are satisfied. You are <<within five kilometers>>...
  • Page 30 The exported KML file will be stored on your Google Drive in a folder ● named CASIO-WSD. To output a traveled route from a normal map display 1. While the map is displayed, swipe the touch screen from bottom to top.
  • Page 31 Using Point Navigation You can use Point Navigation to have the direction and distance to a destination displayed on the map. In addition to being available with the Point Navigation app, this capability can also be used with the Location Memory app and the Activity app.
  • Page 32 Point Navigation Basics To do this: Perform this operation: Start navigation 1. Use one of the operations below to start up Point Navigation. On the app menu, tap “Point Navigation”. ● While a map is displayed in the Location ● Memory app, swipe the touch screen from bottom to top and then tap “Point Navigation”.
  • Page 33 To do this: Perform this operation: Change the destination 1. Perform step 1 of “Start navigation”. during a navigation This will display the message “Navigation ● operation being performed.”. 2. Scroll the message downwards, and then tap “Reset Destination”. 3. On the confirmation message screen that appears, tap “Stop”.

  • Page 34: Using The Tool App

    Using the TOOL App The TOOL app displays a wide variety of information about the natural environment around the watch. TOOL Function List Compass Shows a compass needle on the face. A color display shows the latitude and longitude of the current location. Altimeter Two color screens are available.
  • Page 35 Basic TOOL Operations To do this: Perform this operation: Change the While the TOOL app is running, press the TOOL ● TOOL function button or MAP button. While the TOOL app is running, swipe the touch ● screen from top to bottom, or from bottom to top. Switch between To switch from screen A to screen B, swipe the touch the two color...
  • Page 36 Using Compass The pointer indicates true north. The value in the center of the display shows how many degrees there are in a clockwise direction from the north indication (which is 0°) to 12 o’clock on the watch. For example, if 12 o’clock on the watch is facing due east, the value will show 90°.
  • Page 37 Using Altimeter Altimeter has a color display Altimeter Screen (left), a color display Altitude Graph Screen (right), and a monochrome display. All of the screens show the altitude at your current location. ● The Altitude Graph Screen shows a graph of altitude changes over the past ●...
  • Page 38 Before Using Altimeter The watch’s Altimeter can be configured to use positioning information ● (GPS) to correct altitude readings automatically. Configure the settings below to use this function. Correctly configure the “Location” setting on the watch and smartphone. ー For more information, see step 1 under “Preparing the Watch for Outdoor Use”.
  • Page 39 Altimeter Precautions Do not use this watch while skydiving, hang gliding, paragliding, gyrocopter ● flying, glider flying, or engaged in other activities where altitude changes suddenly. Altitude readings produced by this watch are not intended for special- ● purpose or industrial level use. In an aircraft, the watch measures the in-cabin pressurized air pressure, so ●...
  • Page 40 Using Barometer Barometer has a color display Barometer Screen (left), a color display Barometric Pressure Graph Screen (right), and a monochrome display. All of the screens show the barometric pressure at your current location. ● The Barometric Pressure Graph Screen shows a graph of pressure ●...
  • Page 41 Using Sunrise/Sunset Sunrise/Sunset has a color display Time Screen (left), a color display Azimuth Screen (right), and a monochrome display. The Time Screen shows the following times: sunrise time (upper left), pre- ● dawn nautical twilight start time (lower left), sunset time (upper right), post- sunset nautical twilight end time (lower right), and the current time (bottom center).
  • Page 42 Using Tide Graph Tide Graph a color display Tide Graph Screen (left), a color display Fishing Time Screen (right), and a monochrome display. The Tide Graph Screen shows the current tide level and time (red ● characters in the center of the screen), along with the high tide (High) and the low tide (Low) that will occur up to 12 hours later.
  • Page 43 Interpreting Fishing Time Screen Contents Fish Marks (Projected Probability of Fishing Success Indicators) The number of fish marks on the Fishing Time screen indicates the projected probability of fishing success. Anywhere from zero to four white fish marks are displayed, and more white fish marks indicate that better success can be expected.
  • Page 44 Current Date’s Optimum Predicted Fishing Time Period The Fishing time Screen shows two orange time periods centered on hour angles 00:00 and 12:00, and two blue time periods centered on hour angles 06:00 and 18:00. Each region indicates periods during which optimum fishing can be expected.
  • Page 45 Current Moon Hour Angle and Moon Age Indications The location of the Moon indicator on the Fishing Time screen shows the current hour angle of the Moon, while the shape of the indicator shows the current Moon age. In the screen shown above, for example, the current Moon hour angle is 22:00 (12 o’clock position = hour angle 00:00, 6 o’clock position = hour angle 12:00), while the Moon age is 21.3 to 23.1.
  • Page 46 Using My Graph My Graph shows the status of your activities for the current day. Under initial default settings, both color and monochrome screens show ● how many calories you have burned from the start (00:00) of the current day. A color display shows what types of activities you have performed on the ●...
  • Page 47 To specify the type of values shown in the center of the My Graph screen 1. Swipe the touch screen from right to left. On the “Settings” Screen that appears, tap D. This displays the setting menu. 2. Scroll the setting menu upwards and downwards. When “Centered value / My Graph”...
  • Page 48 To specify activity types that appear on the Activity Graph screen 1. Swipe the touch screen from right to left. On the “Settings” Screen that appears, tap D. This displays the setting menu. 2. Scroll the setting menu upwards and downwards. When “Activity Specific Properties”...

  • Page 49: Using The Activity App

    Using the Activity App The Activity app shows cumulative elapsed time from when one of the outdoor activities listed below starts until it stops, a track of the route followed on a map, and a list of data (activity time, distance traveled, etc.) Trekking Paddle Fishing...
  • Page 50 Auto save of traveled route data (KML file) to ● Google drive The exported KML file is stored on Google Drive in a folder named “CASIO-WSD”. For details about the required procedure, see “Enabling History Auto Save”. History & Export Display a calendar (Google Calendar or →...
  • Page 51 Measurement in Progress Screens Swiping the screen left or right while measurement is in progress will switch between a measurement data screen, map screen, “STOP” screen, etc. The screens that can be displayed depend on the activity type. Basic Activity App Operations To do this: Perform this operation: Start measurement...
  • Page 52 Enabling History Auto Save Note “History Auto Save” settings are applied to both the Activity app and Extend ● Mode app. Because of this, you do not need to perform the procedure below if you have already enabled History Auto Save with the Extend Mode app. 1.
  • Page 53 Viewing History Data on a Phone Important! Note that your phone needs to have Google Calendar, Google Drive, and ● Google Earth installed in order to perform this procedure. 1. On the phone, start up Google Calendar. 2. On Google Calendar, tap the history data whose details you want to view.
  • Page 54 Note If the watch is paired with an Android phone, you can use watch menu ● operations to start up the phone’s Google Calendar. Using the Activity app: 1. Display the Activity app “START” screen or “BEGIN” screen. 2. Swipe the touch screen from bottom to top. On the menu that appears, tap “View History on Phone”.

  • Page 55: Using The Moment Setter App

    Using the MOMENT SETTER App For example, you can use the MOMENT SETTER app to receive notifications like the ones shown below. During an Activity app Trekking measurement operation, perform a vibration ● notification and display the remaining altitude when there are 200 m remaining to an altitude of 2000 m.
  • Page 56 MOMENT SETTER App Main Menu Starting up the MOMENT SETTER app first displays a Main Menu. Setting items included in the Main Menu are shown in the table below. Tapping this item: Displays this menu: Recent Menu of up to three notifications that were last turned on.
  • Page 57 Example MOMENT SETTER Operation This section shows an example operation for configuring notification settings for “Climbing, trekking”. This operation can be started from the MOMENT SETTER app or Activity app. 1. Start up the MOMENT SETTER app and scroll the main menu upwards and downwards.
  • Page 58 5. At the bottom of the display, tap to toggle it to 6. Press the power button to exit the MOMENT SETTER app. After performing the above operation, you need to start up the Activity ● app and start a Trekking measurement operation to actually receive notifications.

  • Page 59: Using The Extend Mode App

    Using the Extend Mode App The Extend Mode app records multiple days of trekking and other activity data as a continual log (location information log). Day 1 Plan* Day 3 Plan* Day 2 Plan* 9:00AM 3:00PM 9:00AM 2:00PM 6:30AM Logging: Start Pause Pause...
  • Page 60 This is just a brief explanation about how to use the Extend Mode app and ● perform its operations. For more information, refer to the Extend Mode help page at the website below. https://support.casio.com/wsd/ Precautions when Using the Extend Mode App Before performing a location information logging operation with the Extend ●...
  • Page 61 Extend Mode App Basics To do this: Perform this operation: Input a plan for the first 1. On the app menu, tap “Extend Mode”. day’s activity 2. Tap “Prepare”. 3. Perform the operations below in accordance with the displayed message. Confirm that map of your destination has ●...
  • Page 62 To do this: Perform this operation: Switch from the Press the MAP, POWER, or TOOL button. Note monochrome display to that the tapping the touch panel will not switch the map display during a the display. logging operation Advance the logging 1.
  • Page 63 Auto save of traveled route data (KML file) to Google drive ● The exported KML file will be stored on your Google Drive in a folder named CASIO-WSD. Perform the procedures below while there is no logging operation being performed by the Extend Mode app.

  • Page 64: Using The Multi Timepiece App

    Note History data logged with the Extend Mode can be viewed and exported ● using the Location Memory app. Using the Multi Timepiece App The Multi Timepiece app provides access to the Multi Timepiece Mode, which makes it possible to display the current time and particular information (battery level, or barometric pressure/altitude, etc.) only on the monochrome LCD.
  • Page 65 Display Styles There are two display styles in the Multi Timepiece Mode. You can select the display style each time you enter the Multi Timepiece Mode. Outdoor Style....Current time, barometric pressure, altitude, compass Daily Style......Current time, day of the week, day, battery level, step count Outdoor Style Daily Style...
  • Page 66 Multi Timepiece Mode Operations To do this: Perform this operation: Switch the watch to 1. On the app menu, tap “Multi Timepiece”. Multi Timepiece This displays the “Multi Timepiece” screen. ● Mode 2. Tap “Settings” and then configure the settings below as required.
  • Page 67 To do this: Perform this operation: Show or hide the Short-press the TOOL button. Each press toggles compass (Outdoor the compass between show and hide. Style only) Note If “CALI” appears on the screen when you try to ● use the compass, it means that you need to perform magnetization correction.

  • Page 68: Common Outdoor Function Settings

    Common Outdoor Function Settings CASIO apps and CASIO watch faces share the same outdoor functions such as Compass, Altimeter, etc. This section explains settings that are common to all CASIO apps and watch faces. Basic Operations for Configuring Common Settings Use the setting menu to configure common settings.
  • Page 69 Setting Item List The setting items displayed on the setting menu (see “Basic Operations for Configuring Common Settings”) are shown below. After displaying the setting menu, perform the operation required for the item whose setting you want to change. Note The letters to the right of each setting item indicate the screen from which ●...
  • Page 70 Altitude Calibration (WF/TL/AC/EX) Operation 1. If “Correct Altitude Using Location” is on, turn it off. 2. Tap “Altitude Calibration”. 3. On the altitude input screen that appears, input the elevation at your current location (which you obtained from local indications). Tap the digit of the value that you want to change, and then use ●...
  • Page 71 Correct Altitude Using Location (WF/TL/AC/EX) Operation Each tap of this setting item toggles between “ON” and “OFF”. Description Select “ON” for this setting to perform auto altitude calibration based on the watch’s or your smartphone’s location information (GPS). “OFF” must be selected for this setting to perform altitude calibration manually using “Altitude Calibration”.
  • Page 72 Centered value / My Graph (TL) Operation Tap this setting item and then scroll the list that appears upwards and downwards. When the type of value you want shown in the center of the My Graph Screen is displayed, tap it. Description This setting changes the type of value displayed in the center of the My Graph Screen.
  • Page 73 Operation 1. Move to an outdoor area where the sky is visible. 2. Perform the required operation on a CASIO watch face to display the setting menu, and then tap “GPS Time Calibration”. 3. Carefully read the message that appears on the display and then tap “Correct”.
  • Page 74 Port setting (TL) Operation Tap this setting item and then scroll the list that appears upwards and downwards. When the name of the point (port name or name of a city near the ocean) you want is displayed, tap it. Description This setting specifies the point (port) whose tide information is displayed by the “Tide Graph”...
  • Page 75 Save Daily Location Info (WF/MS/LM) Operation After tapping this setting, you then need to select “Every 6 minutes”, “Every 1 minute”, or “OFF”. Important! When you tap this setting item to toggle from “OFF” to “ON”, you will also ● need to tap “Every 6 minutes”...
  • Page 76 Each tap of this setting item toggles between “Metric” and “Imperial”. Description Use this setting to switch between metric units (meters, kilograms, hPa, etc.) and Imperial units (feet, pounds, inHg, etc.) for values displayed by CASIO watch faces and apps. Energy Unit (WF/TL/MS) Operation Each tap of this setting item toggles between “Cal”...
  • Page 77 Wrist where you wear the watch (TL/MS) Operation Each tap of this setting item toggles between “Right” and “Left”. Description The value you input for this item is used as basic information when calculating data displayed on the TOOL app’s “My Graph”. Target altitude (AC) Operation Tap this setting item and then use the screen that appears to specify a target...
  • Page 78 Auto Record (AC) Operation 1. Use the Activity app to display the Snow “BEGIN” screen, and then tap “BEGIN”. 2. Swipe the touch screen from right to left as many times as necessary to display the “Settings” Screen. Next, tap D. 3.
  • Page 79 Map Type (AC/MS/LM) Operation Each tap of this setting item toggles between “Google Maps” and “Mapbox”. Description This setting lets you select either Google Maps or Mapbox as the map type displayed by the Activity app and Location Memory app. Important! Maps displayed while “Mapbox”...
  • Page 80 Download Map (AC/MS/LM/EX) Operation 1. Tap “Download Map”. This displays a list of map skin names. ● 2. Scroll the list upwards and downwards. When the skin name you want is displayed, tap it. This displays a map with your current location in the center. ●...
  • Page 81 Description This item is for configuring settings related to the Activity app and the Location Memory app. It is for downloading a map to watch memory when “Mapbox” is selected for “Map Type”. If you want to use the map in an area where a network connection is not available, use this item beforehand in an area where a network connection is available to download the desired map.
  • Page 82 All Off (MS) Operation 1. Tap this item and a confirmation dialog box will appear asking if you want to disable all MOMENT SETTER notifications. 2. Tap “Turn off.” to disable notifications or “Cancel” to leave notifications enabled. Description Removing all check marks from the MOMENT SETTER app menu disables all notifications.

  • Page 83: Troubleshooting

    Request servicing by your original retailer or authorized CASIO service center. 1003 Charge the watch in an area where the ambient Too cold to charge. temperature is between 10°C and 35°C (50°F and 95°F).
  • Page 84 > Tap D. > Tap “System”. > Tap “Restart”. If this message/error code keeps appearing after restart, request servicing by your original retailer or an authorized CASIO service center. 9000 To restart the watch, first charge it for at least Some problem one hour.

  • Page 85: Important

    Important! Note the precautions in this section whenever using this watch. Precautions During Use Display Information Accuracy Tide Graph Precautions For Japan area oceans, tide times and level changes are predictively calculated using harmonic constant data obtained from Bibliography 742 Tidal Harmonic Constants Tables, Japanese Coast (February 1992) published by the Hydrographic Department of the Japan Coast Guard, and from the List of Tidal Stations (2015) published by the Japan Meteorological...
  • Page 86 To maintain water resistance, have the gaskets of your watch replaced ● periodically (about once every two or three years). Be sure to leave battery replacement up to an authorized CASIO service ● center or your original retailer. Unauthorized battery replacement may cause problems with the waterproof performance of the watch.
  • Page 87 CASIO service center or to your original retailer. Do not charge the watch if the watch or charger cable is wet. Wipe off all ●...
  • Page 88 Using GPS Outside Your Country Some countries or geographic areas put legal restrictions on the use of GPS, on the collection and logging of location information, etc. Your watch has built- in GPS functionality, so before embarking on international travel to a country or area outside of the country where you purchased your watch, you should check with the embassy of the countries you plan to visit, your travel agency, or some other reliable source of information to find out if there are any...
  • Page 89 Using this watch in the vicinity of a mobile phone or other device that uses ● 1.5 GHz band radio waves may make signal reception impossible. Depending on reception conditions, GPS positioning information may ● include error up to several hundred meters. Location information is not acquired while flying on an aircraft or otherwise ●...
  • Page 90 MIL-STD-810G This watch has been tested for the items described below in accordance with the MIL-STD-810G standard established by the U.S. Department of Defense. Shock resistance is based on the assumption of normal daily use. Throwing ● the watch, or subjecting it to excessive dropping or other extreme shock can cause it to break.
  • Page 91 Charging The watch and AC adaptor may become warm to the touch during charging. ● This is normal and does not indicate malfunction. Do not charge the watch while its charge level is high enough for watch ● operation. Waiting until the charge level is low until you charge will help to extend battery life.
  • Page 92 Take your watch to an authorized CASIO service center or to your original retailer for inspection and repair (for which you will be charged) or to have the band replaced (for which you will be charged).
  • Page 93 Magnetism Some watch functions may not operate normally in a location where ● magnetism is present. Very strong magnetism (from medical equipment, etc.) should be avoided because it can cause malfunction of your watch and damage to electronic components. Chemicals Do not allow your watch to come into contact with thinner, gasoline, ●...
  • Page 94 Watch Sensors A watch sensor is a precision instrument. Never try to take it apart. Never ● try to insert any objects into the openings of a sensor, and take care to ensure that dirt, dust, or other foreign matter does not get into it. After using your watch where it has been immersed in saltwater, rinse it thoroughly with fresh water.

  • Page 95: User Maintenance

    ● pins to fly out of position or to fall out. If you ever notice any abnormality immediately stop using your watch and take it to an authorized CASIO service center or to your original retailer. Even if the surface of the metal appears clean, sweat and rust in crevasses ●...

  • Page 96: Chargeable Battery Handling (Please Recycle

    The built-in lithium-ion battery includes valuable resources. When you are ready to discard your watch, follow proper procedures in order to recycle resources. For information about the proper procedure to follow when discarding the watch, contact an authorized CASIO service center or your original retailer. Important! Do not try to replace batteries by yourself.

  • Page 97: Main Specifications

    Main Specifications 1.2-inch dual layer display, Color organic electroluminescence (EL) (390 × ● 390 pixels) + Monochrome LCD Capacitive touch panel ● Microphone ● Vibration ● Battery: ● Type: Lithium-ion battery Charging time: Approximately 3 hours at room temperature (Be sure to use the special charger cable and AC adaptor.) Bluetooth: Bluetooth 4.1 (Low Energy support)
  • Page 98 Watch: ● Auto time correction: By communication with smartphone (Time can be adjusted manually.) By GPS information (Can be corrected manually.) Time zones (world time function): Supports multiple world time zones (Types depend on system time zones.) 12/24-hour timekeeping Full auto-calendar: Auto switching by linking with smartphone Summer time: Auto switching by linking with smartphone...
  • Page 99 TOOL App: ● Compass: Measurement range: 0° to 359° Measurement unit: 1° Continuous measurement duration: 1 minute North Indication hand, Magnetic declination calibration, Bearing memory, Gradient calibration Altimeter: Measurement range: –700 to 10,000 m (–2,300 to 32,800 ft) Measurement unit: 1 m (5 ft) Measurement accuracy: within ±75 m (within ±250 ft) (When frequent manual calibration is performed) Shortest measurement interval: 1 minute...
  • Page 100 Activity App: ● Trekking, Fishing, Cycling, Paddle, Snow MOMENT SETTER App ● Trekking, Fishing, Cycling, Paddle, Snow notifications Screen brightness setting: Auto, 5 levels ● Watch battery level indicator: Integer value, 0 to 100% ● Charger (AC adaptor): ● INPUT: AC 100 V to 240 V 50 Hz/60 Hz OUTPUT: 5.0 V Charger cable: ●...
  • Page 101 About MIL-STD-810G (United States military standard issued by the U.S. ● Department of Defense): Description: 1. Shock 2. Vibration 3. Humidity 4. Low Pressure Transport 5. Low Pressure Operation 6. High Temperature Transport 7. Low Temperature Transport 8. Temperature Shock 9.
  • Page 102 *1 CASIO test conditions *2 In order to be able to use these functions your Android phone must have the CASIO MOMENT SETTER+ app installed, and there must be a connection between the phone and watch. These functions are not supported in the case of iOS.

  • Page 103: Supplementary Information

    Supplementary Information Open Source Information CASIO uses GPL, LGPL and other source code that comes under an open source license in this product. CASIO discloses the source code in accordance with each open source license. For source codes and details about each open source license, visit the CASIO website.
  • Page 104 This device complies with part 15 of FCC Rules and Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 105 Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. The WSD-F30 has been tested and found to comply with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules.
  • Page 106 CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan S05_MA1902-B...
