- Page 1 CDC-MP33R SERVICE MANUAL BASIC TAPE MECHANISM: AZL-2 ANF STEREO CAR CD RECEIVER BASIC CD MECHANISM: BZA-8 MP3NF • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-014-444-3T1...
- Page 2 UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O ACCESSORY 87-B10-141-010 0E NUT,5 TYPE-2 YZSTF CDC-MP33R O ACCESSORY 87-B10-143-010 0E UT1+5-15 W/O SLOT YZSTF CDC-MP33R O ACCESSORY 87-B10-144-010 0E W,5.2-10-0.5 YZSTF CDC-MP33R O ACCESSORY 87-B10-145-010 0E W-SPR,5.3-8.5-1.5...
- Page 3 K NO. DESCRIPTION SUFFIX MODEL NAME O E-VOL 0341 87-010-491-040 0E CAP,E 0.22-50 M 5L SRE YZSTF CDC-MP33R O E-VOL 0342 87-010-491-040 0E CAP,E 0.22-50 M 5L SRE YZSTF CDC-MP33R O E-VOL 0401 87-010-494-040 0E CAP,E 1-50 M 5L SRE...
- Page 4 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X E-VOL 0451 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R X E-VOL 0452 88-108-104-080 0E C-RES,U 100K-1/16W J YZSTF CDC-MP33R X E-VOL 0453 88-108-105-080 0E C-RES,U 1M-1/16W J YZSTF CDC-MP33R X E-VOL 0454 88-108-472-080 0E C-RES,U 4.7K-1/16W J...
- Page 5 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X ELECTRICAL 0653 88-118-471-080 0E C-RES,S 470-1/10W J YZSTF CDC-MP33R X ELECTRICAL 0654 88-118-331-080 0E C-RES,S 330-1/10W J YZSTF CDC-MP33R X ELECTRICAL 0655 88-108-152-080 0E C-RES,U 1.5K-1/16W J YZSTF CDC-MP33R X ELECTRICAL 0656 88-108-152-080 0E C-RES,U 1.5K-1/16W J...
- Page 6 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME X MICON 0462 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R X MICON 0463 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R X MICON 0464 88-108-102-080 0E C-RES,U 1K-1/16W J YZSTF CDC-MP33R...
- Page 7 K NO. = Only use japanese. UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O OTHERS 8B-KC7-210-010 0E HLDR,SP-R YZSTF CDC-MP33R O OTHERS 8B-KC7-211-010 0E HLDR,MECHA YZSTF CDC-MP33R O OTHERS 8B-KC7-212-010 -- HLDR,TR2-B YZSTF CDC-MP33R X OTHERS 8B-KC7-213-010 -- SH,ADH WINDOW...
- Page 8 K NO. DESCRIPTION SUFFIX MODEL NAME O POWER AMP 0507 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R O POWER AMP 0508 87-012-270-080 0E C-CAP,U 470P-50 K B YZSTF CDC-MP33R O POWER AMP 0510 87-010-498-040 0E CAP,E 10-16 M 5L SRE...
- Page 9 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME S POWER SUPPLY 0713 89-423-952-010 1A TR,2SD2395E YZSTF CDC-MP33R S POWER SUPPLY 0715 87-A30-287-040 0E C-TR,DTC114TKA YZSTF CDC-MP33R X POWER SUPPLY 0701 88-108-103-080 0E C-RES,U 10K-1/16W J YZSTF CDC-MP33R X POWER SUPPLY...
- Page 10 REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O SCREW 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R O SCREW 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R O SCREW 8Z-KC1-253-010 0E S-SCREW,PT 2*8 BH+ BLK YZSTF CDC-MP33R...
- Page 11 Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers. K NO. = Only use japanese. UNIT NAME REF NO. PARTS CODE K NO. DESCRIPTION SUFFIX MODEL NAME O TUNER TU 0101 8B-KC3-620-010 2Y TU UNIT, FAE347-E21 YZSTF CDC-MP33R – 11 –...
- Page 12 SCHEMATIC DIAGRAM – 1 (MAIN) – 12 –...
- Page 13 SCHEMATIC DIAGRAM – 2 (FRONT) – 13 –...
- Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2000068 Printed in Singapore...
