Yale Smart Living EF-KP Quick Start Manual

smart
Living
Y ale
2
1
4
7
3
Description
1. LED Indicator: Displays Key Pad status.
2. Numeric Keys: Used for entering PIN
codes.
3. Arm Key: Press for Away Arming.
4. Panic Keys A and B: Press both for
Panic alarm.
5. Home Arm Key: Press to Part Arm.
6. Disarm Key: Used with PIN code to turn
system off or to silence alarm.
7. Learn Button: Press button 8 and 9
together.
8. Battery saver tab (pull tab out to activate)
9. Knockouts for wall mounting
Inside the Box
• 1 x Remote Key Pad
• 2 x wall plug/screws
• 1x CR2032 coin cell battery (fitted)
For more information on this product
and Yale Smart Living Range visit
www.yale.co.uk/smart-living
Consumer Support: info@yale.co.uk
4A
4B
1
2 3
6
5
7
9
8
6
0
5
Programming & Location
Program your Key Pad before installation and test
afterwards. Please see your current Alarm user
manual.
Locate the Key Pad taking into account the
following points:
• Mount at chest height for ease of use
• Designed for indoor use only
• Key Pad should be accessible from a protected
entry/exit point
• Ensure that the Key Pad is not visible from the
outside of the premises.
The 2 year guarantee for this
product is active from the date
2
of purchase (A copy of this
guarantee is available on our
website).
Key Pad
(EF-KP)
8
9
