- Page 1 Refrigerator User manual Free Standing Appliance Untitled-5 1 2018-08-22 2:32:13...
-
Page 2: Table Of Contents
Contents Safety information Important safety symbols and precautions: Severe warning signs for transportation and site Critical installation warnings Installation cautions Critical usage warnings Usage cautions Cleaning cautions Critical disposal warnings Additional tips for proper usage Saving Energy Tips This appliance is intended to be used in household and similar applications such as Instructions about the WEEE Installation Refrigerator at a glance... -
Page 3: Safety Information
Safety information • Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons... - Page 4 If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com. • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used.
- Page 5 • It is hazardous for anyone other than an Authorised Service Person to service this appliance. In Queensland – the authorized Service Person MUST hold a Gas Work Authorisation or Licence for hydrocarbon refrigerants, to carry out Servicing or repairs which involve the removal of covers.
-
Page 6: Important Safety Symbols And Precautions
Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. -
Page 7: Severe Warning Signs For Transportation And Site
Severe warning signs for transportation and site WARNING • When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes. - Page 8 Safety information • Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a fire hazard from overheated wires.
- Page 9 - Deteriorated insulation of electrical parts may cause an electric shock or fire. • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. English...
- Page 10 Safety information • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, fire, problems with the product, or injury.
-
Page 11: Installation Cautions
• If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents. • The fuse on the refrigerator must be changed by a qualified technician or service company. - Failing to do so may result in an electric shock or personal injury. -
Page 12: Critical Usage Warnings
Safety information • The socket must be easily accessible so that the appliance can be quickly disconnected from the supply in an emergency. It must be outside the area of the rear of the appliance. Critical usage warnings WARNING • Do not insert the power plug into a wall socket with wet hands. - Page 13 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 14 Safety information • Do not overfill the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage. • Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, fire, or problems with the product.
- Page 15 • Do not put fridge shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop. • Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.
- Page 16 • If the interior or exterior LED lamp has gone out, contact your nearest service center. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.
-
Page 17: Usage Cautions
Usage cautions CAUTION • Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury. - Page 18 • When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center. • Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.
-
Page 19: Cleaning Cautions
• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difficult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Page 20 Safety information • Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of fire or electric shock. •...
-
Page 21: Critical Disposal Warnings
Critical disposal warnings WARNING • Please dispose of the packaging material from this product in an environmentally friendly manner. • Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal. • R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. -
Page 22: Additional Tips For Proper Usage
Safety information Additional tips for proper usage • In the event of a power failure, call the local office of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. -
Page 23: Saving Energy Tips
Saving Energy Tips • Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example). • Not to block any vents and grilles is recommended for energy efficiency. -
Page 24: This Appliance Is Intended To Be Used In Household And Similar Applications Such As
Safety information This appliance is intended to be used in household and similar applications such as • staff kitchen areas in shops, offices and other working environments; • farm houses and by clients in hotels, motels and other residential type environments; •... -
Page 25: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... - Page 26 Installation Normal models 01 Fridge feature panel 02 Fridge door bin * 03 Multipurpose bin ** 04 Water tank ** 05 Foldable shelf * 06 Deodorizer 07 Freezer feature panel 08 Vegetable box * 09 Optimal Fresh Zone * 10 Freezer drawer * 11 Movable ice maker * 12 Tray ice maker * 13 Ice tray *...
- Page 27 NOTE • To quickly freeze large quantities of food, use the bottom drawer. • For best energy efficiency, make sure all of shelves, drawers, and baskets are placed in their original position. To secure more storage space (applicable models only) To get more space, you can remove the top drawer of freezer compartment since it does not affect thermal and mechanical characteristics.
-
Page 28: Step-By-Step Installation
Installation Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 29 Clearance See the pictures and table below for space requirements for installation. Model SRL336NW SRL304NW Depth “A” Width “B” Overall Height “C” 1700 1580 (unit : mm) English Untitled-5 29 2018-08-22 2:32:16...
- Page 30 Installation more than 50 mm recommended 115˚ 1210 (unit : mm) NOTE The measurements in the above table may differ, depending on the measuring method. STEP 2 Flooring • The surface to install the refrigerator must support a fully loaded refrigerator. •...
- Page 31 STEP 3 Adjust the levelling legs CAUTION • The refrigerator must be levelled on a flat, solid floor. Failing to do so can cause damage to the refrigerator or physical injury. • Levelling must be performed with an empty refrigerator. Make sure no food items remain inside the refrigerator.
- Page 32 Installation STEP 4 Initial settings By completing the following steps, the refrigerator should be fully functioning. 1. Remove the PE foam sheet on each shelf corner, which is attached to protect the refrigerator during transportation. 2. Plug the power cord into the wall socket to turn the refrigerator on. 3.
-
Page 33: Operations
Operations Feature panel Fridge Freezer 01 Fridge / Power Cool 02 Freezer Temp. (Coldest / Optimal / Colder) English Untitled-5 33 2018-08-22 2:32:18... - Page 34 Operations 01 Fridge / Power Cool (3 sec) To adjust the fridge temperature, press Fridge to select the corresponding temperature. Fridge You can change the temperature between 1 °C and 7 °C (default: 2 °C). Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature.
-
Page 35: Special Features
Special features The actual image and special functions of your refrigerator may differ, depending on the model and the country. Water dispenser (applicable models only) With the water dispenser, you can dispense water without opening the fridge door. The water tank must be filled with potable water before use. To fill the water tank with potable water Open the door and locate the water tank that is surrounded by the door bins. - Page 36 Operations 4. Put a water glass under the water outlet of the dispenser, and gently push the dispenser lever to dispense water. Make sure the water dispenser is unlocked. CAUTION • The water dispenser is designed to dispense potable water. Fill the water tank only with potable water.
- Page 37 NOTE • Make sure the ice cube storage bin is in place under the ice tray. • To dispense the ice cubes, turn the handle of the bin to the right to empty half of the ice cubes into the bin. Then, turn it to the left to empty the other half.
- Page 38 Operations Optimal Fresh Zone (applicable models only) To change the temperature of the Optimal Fresh Zone, remove the drawer and use the inner dial. CAUTION The temperature of Optimal Fresh Zone changes according to the temperature setting of the fridge. When storing food in the Optimal Fresh Zone, you must set the fridge temperature for food to store in the Optimal Fresh Zone.
-
Page 39: Maintenance
Maintenance Handle and care Shelves 1. Slightly lift up the rear side of the shelf to pull out. Foldable shelf (applicable models only) 1. Slightly lift up the front side of the shelf to pull out. 2. Twist the shelf diagonally to remove. English Untitled-5 39 2018-08-22... - Page 40 Maintenance CAUTION • Do not put food or objects in front of the Vegetable box. The door will not close properly. • The shelf must be inserted correctly. Do not insert upside down. • When reinserting the shelf, make sure to push in the shelf to the end until it fits.
-
Page 41: Cleaning
You can purchase the deodorizer filter separately from the service center. LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service centre. WARNING The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock. -
Page 42: Troubleshooting
Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution • Power cord is not plugged in • Properly plug in the power properly. - Page 43 Odors Symptom Possible causes Solution • Clean the refrigerator and • Spoiled food. remove any spoiled food. Refrigerator has odors. • Make sure strong smelling • Food with strong odors. food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the •...
-
Page 44: Do You Hear Abnormal Sounds From The Refrigerator
Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. - Page 45 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.
- Page 46 Memo Untitled-5 46 2018-08-22 2:32:27...
- Page 47 Memo Untitled-5 47 2018-08-22 2:32:27...
- Page 48 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) 0800 726 786 (All Product) NEW ZEALAND www.samsung.com/nz/support...
