- Page 1 H3C OAP Cards User Manual New H3C Technologies Co., Ltd. http://www.h3c.com Manual Version: 6PW102-20180112...
- Page 2 Copyright © 2009-2018, New H3C Technologies Co., Ltd. and its licensors All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd.
- Page 3 To obtain up-to-date documentation and technical support, go to http://www.h3c.com and select your country or region. Depending on your selection, you will be redirected to either of the following websites: At http://www.h3c.com Documentation To access the most up-to-date H3C product documentation, go to the H3C website at http://www.h3c.com Technical Support service@h3c.com http://www.h3c.com...
-
Page 4: Table Of Contents
Table of Contents 1 Overview ·························································································································· 1-1 2 Hardware of the OAP Card ·································································································· 2-1 Appearance ··················································································································· 2-1 Front Panel ···················································································································· 2-1 Appearance ············································································································· 2-1 Description of the LEDs ······························································································ 2-1 Management Ethernet Port ························································································· 2-2 Hardware Specifications ···································································································... -
Page 5: Overview
The Open Application Platform (OAP) cards are developed based on the Open Application Architecture (OAA) by New H3C Technologies Co., Ltd. (hereinafter referred to as H3C). An OAP card has an independent CPU and memory card (CF card), and thus it can load various service software. -
Page 6: Hardware Of The Oap Card
Hardware of the OAP Card The firewall card, IPS card and access controller module are similar in hardware structure and appearance, except that the product model marked on the front panel and the loaded software of the cards are different. The following hardware introduction is made on a firewall card. Appearance Figure 2-1 OAP card appearance (1) Ejector lever... -
Page 7: Management Ethernet Port
Table 2-1 Description of the LEDs provided on the front panel of the OAP card Color Status Description The power system of the OAP card works Steady green normally. Steady red The power system of the OAP card is faulty. PWR LED Green/red No power supply to the OAP card. -
Page 8: Hardware Specifications
Table 2-2 Management Ethernet port specifications Item Specification Connector type RJ-45 Transmission rate 10/100/1000 Mbps, half/full duplex Transmission medium and Category-5 twisted pair cable that supports a maximum maximum transmission distance transmission distance of 100 m (328.08 ft.) Services Upgrade of host software and BootWare, network management. Hardware Specifications Table 2-3 OAP card hardware specifications Item... -
Page 9: Installing An Oap Card
Installing an OAP Card Installing and Removing an OAP Card The installation tools are not provided with the H3C series switches and OAP cards. This section describes the installation and removal of a firewall card on an S5800-60C-PWR switch. The installation and removal of other OAP card models are similar. - Page 10 The insertion and reverse insertion procedures are the same. This manual uses reverse insertion of an OAP card to an S5800-60C-PWR switch as an example. Figure 3-2 Insert an OAP card Figure 3-3 Reversely insert an OAP card Step4 Push the OAP card slowly along the guide rails (see (3) in Figure 3-4) and then push the ejector levers inward to lock the OAP card in position (see (4) in Figure 3-4).
- Page 11 When installing the OAP card, note the following: Do not touch the components on the surface of the OAP card. Do not apply excessive force while installing the OAP card. If you cannot insert the OAP card smoothly, check whether the installation mode (reverse insertion) is correct. Step5 Fasten the captive screws on the OAP card clockwise with the Philips screwdriver until the OAP card is fixed into the chassis.
-
Page 12: Connecting The Management Ethernet Port Cable
When removing the OAP card, note the following: Do not touch the components on the surface of the OAP card. Do not apply excessive force while removing the OAP card. If you do not install a new OAP card in the slot, install a blank panel to prevent dust from entering the switch and ensure normal ventilation in the switch.
