CORFLEX Ranger II GS Application Instructions

°°
CORFLEX.COM | 800 426 7353
Ranger
Shoulder Brace
Application Instructions
Waistband Application
Fitting the Metal Waistband
1.
A. the sling from the waistband and
set aside.
B. Orient waistband so the long flat
section is toward body and exercise
ball is in front. For use on left arm
remove elastic ball holder and
rotate 180°, reattach to front end of
waistband/strap.
C. Curve waistband to match patient's
waistline, this will provide a stable
platform for the arm and reduce migration.
D. Shape outer frame section for desired abduction/rotation.
Waistband can be adjusted to provide shoulder abduction from 10°
to 45° and from full internal rotation to 70° of external rotation as
specified by the physician or other qualified healthcare provider.
E. Apply at patient's waist on their affected side. Wrap strap around
the patient's waist and secure buckle at the front of waistband.
F. If the waistband can be easily pushed down, tighten waist strap.
Strap should be snug but not cause discomfort.
Sizing and Applying the Sling
Shoulder sling features a universal
design that accommodates a wide
variety of patients, fitting a forearm
length from 9"-20". Length is
measured from wrist to elbow. Sling
comes shipped as a typical medium
right arm sling.
II GS
TM
Sizing Sling Length and Thumb Loop
1.
A. Ensure that any open wounds and/or surgical sites are properly
covered before applying the sling.
B. Sling is configured for use on the right arm/shoulder. For left arm
application: properly orient sling, unbuckle strap at wrist end of sling
and rotate before reinserting. Check that strap is not twisted and that
front shoulder strap hook adjustment is accessible from front of strap.
C. Release top hook closure at shoulder strap buckle allowing front
panel of sling to open fully. While supporting affected arm at 90°,
gently place arm into sling with elbow positioned as far back as
possible in sling pocket.
D. Sling length fit: Edge of sling should extend to first knuckle (PIP
joint) on the pinkie finger. Adjust sling length, if needed, by removing
the forearm section and reapplying in the desired position.
E. Release thumb loop strap and align bottom fold of strap with
third metacarpal. Thumb should rest comfortably inside loop when
properly fit and maintain the wrist and hand in a neutral position.
F. Trim excess strap and reapply top hook closure to secure the front
panel for use.
G. Hand should rest fully along the bottom of the sling and never be
suspended by the thumb loop.
Securing Sling and Waistband
2.
A. With both the sling and waistband properly fit, remove plastic sleeve
from waistband and discard. Attach the sling by securing hook and
loop portions together.
B. Secure the waistband to the sling by reapplying the 2" x 9" mesh
strap across the top of the sling. Locate close to the elbow to help
prevent the arm from sliding forward in the sling.
Comfort Harness Application
Adjusting Strap Lengths
1.
A. Unbuckle Comfort Harness Strap and guide strap around the back,
sliding opposite arm through the sling loop.
B. Secure front buckle at sling, leaving the strap loose at this time.
