  • Page 1 IPC415™ user manual...
  • Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.

  • Page 3: Table Of Contents

    C O N T E N T S General Information Warranty Safety Instructions and Guidelines Overview Installation System Menu DMX Channel Functions And Values Technical Specifications Optional Accessories www.elationlighting.com...

  • Page 4: General Information

    G E N E R A L I N F O R M A T I O N INTRODUCTION This device has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this device.
  • Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...

  • Page 6: Warranty

    No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof.

  • Page 7: Safety Instructions And Guidelines

    S A F E T Y I N S T R U C T I O N S A N D G U I D E L I N E S This device is an extremely sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual.
  • Page 8 S A F E T Y I N S T R U C T I O N S A N D G U I D E L I N E S DO NOT shake device, avoid brute force when installing and/or operating. DO NOT operate device if the power cord has become frayed, crimped, damaged and/or if any of the power cord connectors are damaged and do not...

  • Page 9: Overview

    O V E R V I E W 1. 5pin DMX IN/OUT 2. Isolated 5pin DMX Outputs (x4) 3. OLED Control Menu Display 4. Encoder Wheel 5. powerCON 15 amp Outputs (NAC3MPB-1 x4) 6. Fuses (15 amp x4) 7. Safety Cable Loop (cable not included) 8.
  • Page 10 O V E R V I E W 10. M10 Screw Clamp Hole (Clamp not included) 11. Wall Mounting Keyhole Cutouts www.elationlighting.com...

  • Page 11: Installation

    I N S T A L L A T I O N F L A M M A B L E M A T E R I A L W A R N I N G Keep device at least 5.0 feet (1.5m) away from any flammable materials, decorations, pyrotechnics, etc.
  • Page 12 CLAMP INSTALLATION When mounting to truss, secure an appropriately rated clamp (not included) to the device. Be sure to attach a Safety Cable (not included) to the device using the safety cable rigging point integrated into the back of the device. (See image below) SAFETY CABLE RIGGING POINT S A F E T Y C A B L E...

  • Page 13: System Menu

    S Y S T E M M E N U Pressing the ENCODER WHEEL once will access the (11) main system menus. Rotate the ENCODER WHEEL clockwise or counterclockwise to scroll through the (11) different system menus then push the ENCODER WHEEL to select a desired menu. Rotate the ENCODER WHEEL clockwise or counterclockwise to navigate the available setting options for each sub-menu.
  • Page 14 MAIN MENU SUB MENUS 1. DMX Address 001-512 1. 1CH 2. DMX Channels 2. 4CH 1. Turn Off 2. Turn On 3. On/Off Via DMX 3. Power Setup 4. On/Off if DMX On 5.Scheduler 6. Exit 1. All Ports On (0-120s) 1.

  • Page 15: Dmx Channel Functions And Values

    D M X C H A N N E L F U N C T I O N S A N D V A L U E S ELATION IPC415 DMX Channel Values / Functions (4 Total DMX Channels) Supports Software Versions: ≥ B1.1 V1.0 Features are subject to change without any prior written notice.

  • Page 16: Technical Specifications

    T E C H N I C A L S P E C I F I C A T I O N S CONTROL / CONNECTIONS (2) DMX Channel Modes (1 / 4) Encoder Wheel Internal On/Off Scheduler OLED Control Menu Display 5pin XLR DMX Input 5pin XLR DMX Output (Thru-put) (4) 5pin XLR DMX Outputs...

  • Page 17: Optional Accessories

    DIMENSIONAL DRAWINGS NOTE: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM PRO-CLAMP...
