Model RCP-7443
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING the operators of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
Z16053
2M-
WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
IMPORTANT: DO NOT DISCARD THIS MANUAL
telephone: 314-678-6314
fax: 314-781-2714
www.wells-mfg.com
OPERATIONS MANUAL
DROP-IN REFRIGERATED
COLD PANS, 4-THIRDS, NSF7
RCP-7143, RCP-7243,
RCP-7343, RCP-7443,
RCP-7543, RCP-7643.
DROP-IN REFRIGERATED
COLD PANS, 4-THIRDS, NSF2
RCP-143, RCP-243,
RCP-343, RCP-443,
RCP-543, RCP-643.
INCLUDES INSTALLATION, USE,
CARE, SERVICE AND DIAGRAMS.
403
04/18
Advertisement
Related Manuals for Wells RCP-7143
Summary of Contents for Wells RCP-7143
- Page 1 Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.
- Page 2 Wells’ discretion have the parts replaced or codes, including incorrect gas or electrical connection. Wells is not liable repaired by Wells or a Wells-authorized service agency.
- Page 3 ACCESSORY PARTS & SERVICE DATA INTRODUCTION Thank you for purchasing this Wells Bloomfield appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life.
- Page 4 FEATURES & OPERATING CONTROLS NOTE: This is a general arrangement drawing of an RCP-7243, not to scale. All other units are similar. Ac- tual component positions may vary between units.
- Page 5 PRECAUTIONS AND GENERAL INFORMATION This appliance is intended for use in commercial establishments WARNING: only, and is intended to hold pre-chilled prepared food for human ELECTRIC consumption. No other use is recommended or authorized by the SHOCK HAZARD manufacturer or its agents. All servicing requiring Operators of this appliance must be familiar with the appliance use, access to non-insulated...
- Page 6 AGENCY LISTING INFORMATION The RCP-7143 thru RCP-7643 are performance tested to NSF STD 2 Standard 7 for storage of potentially hazardous foods. This appliance STD 7 meets NSF Standard 7 only when the pan rails are installed in the lowest position, otherwise it meets NSF Standard 2.
- Page 7 INSTALLATION NOTE: DO NOT discard UNPACKING & INSPECTION the carton or other packing Carefully remove the appliance from the carton. Remove all materials until you have protective plastic film, packing materials and accessories from the inspected the appliance for Appliance before connecting electrical power or otherwise performing hidden damage and tested it any installation procedure.
- Page 8 This must be plugged into follow this warning can a properly grounded matching receptacle. result in severe electrical b. RCP-143 through RCP-543 and RCP-7143 thru RCP-7543 shock. are equipped with a NEMA 5-15P plug and require matching NEMA 5-15R receptacles.
- Page 9 INSTALLATION IMPORTANT: PLUMBING INSTALLATION Plumbing connections must Install 1" drain valve (provided by others) on unit drain. Plumb to an be made in compliance with appropriate waste as required by local plumbing and sanitation all Federal, State and Local ordinances. Consult local codes for approved drain configurations. Codes and Ordinances.
- Page 10 REFRIGER- ATED PRE-CHILLED prod- 4. Models RCP-7143 thru RCP-7643 are NSF-7 listed for use with potentially hazardous foods. All others are NSF-2 listed. uct at serving temperature. 5. Periodically clean condensing coils to remove accumulated dust RCP series units should not and debris.
- Page 11 CLEANING INSTRUCTIONS PREPARATIONS: Turn POWER SWITCH OFF. Unplug unit or CAUTION: disconnect from electric power. ELECTRIC SHOCK Allow unit to defrost before proceeding. HAZARD Remove any insets, pans and/or adapter tops ( if DO NOT splash or pour water used). Drain water from tank. onto control panel or wiring.
- Page 12 MAINTENANCE INSTRUCTIONS CONDENSER COIL CLEANING INSTRUCTIONS CAUTION: PERSONAL The condenser coil must be kept clean to allow adequate air flow for INJURY HAZARD proper heat dissipation. Recommend this procedure be performed Disconnect appliance from monthly. electrical power before 1. Turn POWER SWITCH OFF. Disconnect unit from electrical cleaning condenser coil.
- Page 13 MAINTENANCE INSTRUCTIONS CAUTION: PERSONAL INJURY HAZARD Disconnect appliance from electrical power before cleaning. Wells refrigerated cold pans are constructed of high quality stainless steel. As long as the stainless steel surface is intact, the equipment will not rust or corrode.
- Page 14 3. Normal temperature setting would be 28ºF. The temperature setting of the NSF-7 Refrigerated Cold Pan RCP-7143 thru RCP-7643 has been pre-set at the factory to meet most The LCD Display provides a readout of the sensor temperature applications.
- Page 15 OPERATING INSTRUCTIONS 3. Press the SET key again to access the differential. The LCD will IMPORTANT: DO NOT adjust the differential display the current differential, and the DIF1 annunciator will blink settings of the refrigeration off and on to indicate that control is in the differential mode. system.
- Page 16 TROUBLESHOOTING...
- Page 17 NO C WHITE WHITE GREEN BLACK BLACK ON/OFF SWITCH PLUG: START CAPACITOR NEMA 5-15P: RCP-143 thru -443 and RCP-7143 thru -7443. WHITE BLACK NEMA 5-20P: RCP-543 thru -643 and RCP-7543 thru -7643. MOTOR ADJUSTABLE PRESSURE CONTROL COLD PAN WITH REFRIGERATION COILS...
- Page 18 NOTES:...
- Page 19 ADAPTER BAR FOR 12" X 20" PANS O3-303100 For factory authorized SHORT ADAPTER BAR XXXXX service, or to order factory PAN RAIL FOR RCP-7143 5O-22696 authorized replacement parts, PAN RAIL FOR RCP-7243 5O-22697 contact your Wells authorized PAN RAIL FOR RCP-7343...
- Page 20 WELLS MANUFACTURING 265 Hobson Street, Smithville, Tennessee 37166 telephone: 314-678-6314 fax: 314-781-2714 www.wells-mfg.com...
