Summary of Contents for Dell Inspiron 5582
- Page 1 Inspiron 5582 Setup and Specifications Regulatory Model: P78F Regulatory Type: P78F001...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents 1 Set up your Inspiron 5582..........................5 2 Create a USB recovery drive for Windows..................... 7 3 Views of Inspiron 5582..........................8 Right....................................8 Left.......................................8 Base..................................... 9 Display....................................10 Bottom....................................11 Modes....................................11 Notebook..................................11 Tablet....................................12 Stand.................................... 12 Tent....................................12 4 Specifications of Inspiron 5582........................ - Page 4 Self-help resources................................25 Contacting Dell.................................25 Contents...
-
Page 5: Set Up Your Inspiron 5582
To conserve battery power, the battery might enter power saving mode. Connect the power adapter and press the power button to turn on the computer. Finish Windows setup. Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: • Connect to a network for Windows updates. - Page 6 Dell Update, see the knowledge base article SLN305843 at www.dell.com/support. Dell Digital Delivery Download software applications, which are purchased but not pre-installed on your computer. For more information about using Dell Digital Delivery, see the knowledge base article 153764 www.dell.com/ support. Create recovery drive for Windows.
-
Page 7: Create A Usb Recovery Drive For Windows
A message appears, indicating that all data in the USB flash drive will be deleted. Click Create. Click Finish. For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's Service Manual at www.dell.com/support/manuals. Create a USB recovery drive for Windows... -
Page 8: Views Of Inspiron 5582
Views of Inspiron 5582 Right SD-card slot Reads from and writes to the SD card. USB 2.0 port Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps. Security-cable slot (wedge-shaped) Connect a security cable to prevent unauthorized movement of your computer. -
Page 9: Base
NOTE: To expand the number of ports and connectors on your system, connect your computer to a USB Type-C docking station. Search for a compatible USB Type-C docking station at www.dell.com. HDMI port Connect to a TV or another HDMI-in enabled device. Provides video and audio output. -
Page 10: Display
If the power button has a fingerprint reader, place your finger on the power button to log in. NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/ support/manuals. Display Left microphone Provides digital sound input for audio recording and voice calls. -
Page 11: Bottom
Bottom Left speaker Provides audio output. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Right speaker Provides audio output. Modes... -
Page 12: Tablet
Tablet Stand Tent Views of Inspiron 5582... -
Page 13: Specifications Of Inspiron 5582
Specifications of Inspiron 5582 Computer model Inspiron 5582 Dimensions and weight Table 2. Dimensions and weight Description Values Height: Front 18.72 mm (0.74 in.) Rear 19.95 mm (0.79 in.) Width 363.86 (14.33 in.) Depth 250.00 mm (9.84 in.) Weight (maximum) 2.19 kg (4.82 lb) -
Page 14: Chipset
8 GB DDR4 at 2400 MHz (1 x 8 GB) • 8 GB DDR4 at 2400 MHz (2 x 4 GB) • 12 GB DDR4 at 2400 MHz (4 GB + 8 GB • 16 GB DDR4 at 2400 MHz (1 x 16 GB) Specifications of Inspiron 5582... -
Page 15: Ports And Connectors
Not supported Security Wedge-shaped lock Legacy ports Not supported Internal: Expansion Not supported • One M.2 slot for WiFi and Bluetooth combo card • One M.2 slot for M.2 2280, M.2 2242, or M.2 2230 solid-state drive Specifications of Inspiron 5582... -
Page 16: Communications
Realtek ALC3204 Stereo conversion Supported Internal interface High-definition audio External interface Headset combo connector Speakers Internal speaker amplifier Integrated External volume controls Using media-control shortcut keys Speaker output: Average Peak 2.5 W Subwoofer output Not supported Specifications of Inspiron 5582... -
Page 17: Storage
Capacity Up to 32 GB Media-card reader Table 11. Media-card reader specifications Description Values Type One SD card slot Cards supported • Secure Digital (SD) • Secure Digital High Capacity (SDHC) • SD Extended Capacity (SDXC) Specifications of Inspiron 5582... -
Page 18: Keyboard
Number of cameras Type HD fixed focus Location Front camera Sensor type CMOS sensor technology Resolution: Camera: Still image 0.92 megapixel (HD) Video 1280 x 720 (HD) at 30 fps Infrared camera: Still image Not supported Specifications of Inspiron 5582... -
Page 19: Touchpad
Table 15. Power adapter specifications Description Values Type 45 W Diameter (connector) 4.5 mm Input voltage 100 VAC-240 VAC Input frequency 50 Hz-60 Hz Input current (maximum) 1.30 A Output current (continuous) 2.31 A Rated output voltage 19.50 VDC Specifications of Inspiron 5582... -
Page 20: Battery
5.5 hours (when the computer is off) NOTE: Control the charging time, duration, start and end time, and so on using the Dell Power Manger application. For more information on the Dell Power Me and My Dell on Manger see, https://www.dell.com/... -
Page 21: Video
4.2 W Anti-glare vs glossy finish Glossy Touch options Video Table 18. Integrated graphics specifications The following table provides the detailed integrated graphics specifications of Inspiron 5582. Controller External display support Memory size Processor Intel UHD Graphics 620 One HDMI 1.4b port... - Page 22 * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use. ‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position. Specifications of Inspiron 5582...
-
Page 23: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Table 20. List of keyboard shortcuts Keys Description Mute audio Decrease volume Increase volume Play previous track/chapter Play/Pause Play next track/chapter Switch to external display... - Page 24 Keys Description Toggle between battery-status light and hard-drive activity light NOTE: Hard-drive activity light is supported only on computers shipped with a hard drive. Keyboard shortcuts...
-
Page 25: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 21. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app...
