Clevo WA50SFQ Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WA50SFQ

Advertisement

Table of Contents
loading

Related Manuals for Clevo WA50SFQ

Summary of Contents for Clevo WA50SFQ

  • Page 1 WA50SFQ...
  • Page 3 Preface Notebook Computer WA50SFQ Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the WA50SFQ series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Part List Illustration Location ............A-2 Top ....................A-3 Overview ..................1-1 Bottom ................... A-4 Specifications ..................1-2 COMBO ..................A-5 External Locator - Top View with LCD Panel Open ......1-4 DVD DUAL ................... A-6 External Locator - Front & Right Side Views .........1-5 HDD ....................
  • Page 12 Preface Lynx 4/9 ..................B-24 Lynx 5/9 ..................B-25 Lynx 6/9 ..................B-26 Lynx 7/9 ..................B-27 Lynx 8/9 ..................B-28 Lynx 9/9 ..................B-29 3G, WLAN, mSATA ..............B-30 TPM, CCD, LED, LID ..............B-31 eSATA/USB3.0, USB Charger ............ B-32 Card Reader (RTL8411B) ............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the WA50SFQ series notebook computer. Informa- tion about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Intel® Core™ i7 Processor 15.6" (39.62cm) HD / FHD i7-4702MQ (2.2GHz) Audio 6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W  i7-4610M (3.0GHz), i7-4600M (2.9GHz) High Definition Audio Compliant Interface Latest Specification Information 4MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W 2 * Built-In Speakers Intel®...
  • Page 15 Introduction Interface Environmental Spec One USB 2.0 Port Temperature ° ° Two USB 3.0 Ports Operating: 5 C - 35 One eSATA Port (USB 3.0 Combo) Non-Operating: -20°C - 60°C One HDMI-Out Port Relative Humidity One External Monitor Port Operating: 20% - 80% One Headphone/S/PDIF Out Combo Jack Non-Operating: 10% - 90% One Microphone-In Jack...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View  1. PC Camera 2. Built-In Clickpad/Touchpad Microphone Sensitivity 3. *PC Camera LED The mouse button zones *When the PC at the bottom of the pad camera is in use, measure about 15mm the LED will be...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators 2. Multi-in-1 Card Reader FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. Vent 3. External Monitor LEFT SIDE VIEW Port 4. RJ-45 LAN Jack 5. Combined eSATA/ USB 3.0 Port 6. HDMI-Out Port 7. USB 3.0 Ports Figure 5 REAR VIEW Rear View...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent 4. Hard Disk Drive 5. Speakers 6. Multi-in-1 Card Reader  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Memory Slots DDR3L SO-DIMM 2. CPU Socket (no CPU installed) 3. Platform Controller 4. VGA Chip 5. Mini-Card Connector (mSATA Module) 6. Mini-Card Connector (WLAN Module) 7.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. External Monitor Port 2. RJ-45 LAN Jack 3. Combo eSATA/ USB Port 3.0 4. HDMI-Out Port 5. USB Port 3.0 Connector 6. Speaker Cable Connector 7. Keyboard Cable Connector 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. ODD Connector 2. HDD Connector 3. LCD Cable Connector 4. DC-In 5. CCD + MIC Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the WA50SFQ series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the MSATA Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.

  • Page 30: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 Keyboard Removal 1. Turn off the computer, turn it over and remove the battery (page 2 - 2. Remove screws and carefully press at point , from the bottom of the computer to unsnap the keyboard a.

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7.0mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly 4. Remove the component bay cover (Figure 4c Figure 4 5. Grip the tab to slide the hard disk assembly in the direction of arrow to lift the hard disk assembly (Fig- HDD Assembly ure 4d Removal (cont’d.) 6. Remove the screws and the adhesive cover from the hard disk (Figure 4e...

  • Page 33: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 5 1. Turn off the computer, and remove the battery (page 2 - Optical Device 2. Locate the component bay cover and remove screws (Figure 5a Removal 3. Lift the component bay cover off the computer case by applying pressure at point ;...
  • Page 34 Disassembly 6. Carefully pry the bezel off the optical device at point (Figure 6e 7. Separate the bezel and the optical device. Figure 6 8. Reverse the process to attach the front bezel with the new optical device at point (Figure 6g).

  • Page 35: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 7 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1600 MHz. The main memory can be expanded up to 16GB. The SO-DIMM modules supported are 1024MB and 2048MB DDRIII Modules.
  • Page 36 Disassembly 5. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 8 arrows (Figure 8c). RAM Module 6. The RAM module will pop-up Figure 8d , and you can then remove it Removal (cont’d) 7.

  • Page 37: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 9 Processor Removal Processor Removal Procedure 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the component bay cover (page 2 - a. Locate the CPU heat 2.
  • Page 38 Disassembly 5. Turn the release latch towards the unlock symbol to release the CPU (Figure 10f). Figure 10 6. Carefully (it may be hot) lift the CPU up and out of the socket (Figure 10g). Processor Removal 7. Reverse the process to install a new CPU. (cont’d) 8.
  • Page 39 Disassembly Processor Installation Procedure Figure 11 Processor 1. Insert the CPU (Figure 11a), and pay careful attention to the pin alignment; it will fit only one way (DO NOT Installation FORCE IT!), and turn the release latch towards the lock symbol (Figure 11b).

  • Page 40: Removing The Fan Unit

    Disassembly Removing the Fan Unit Figure 12 Fan Unit Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 5), the component bay cover (page 2 - 9) and (page 2 - 13). a. Remove the screws and 2.

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 13a).

  • Page 42: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 43: Removing The Msata Module

    Disassembly Removing the MSATA Module Figure 14 MSATA Module 1. Turn off the computer, remove the battery (page 2 - 13), and component bay cover (page 2 - Removal 2. Locate the module, it is visible at point Figure 14a 3.

  • Page 44: Removing The Ccd

    Disassembly Removing the CCD Figure 15 CCD Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 13). 2. Run your fingers around the inner frame of the LCD panel at the points as indicated by the arrows a.
  • Page 45 Disassembly 5. Disconnect the cable Figure 16 6. Remove the CCD module (Figure 16f). CCD Removal 7. Reverse the process to install a new CCD module. (cont’d) d. Disconnect the cable. e. Remove the CCD mod- ule.  7. CCD Module Removing the CCD 2 - 21...
  • Page 46 Disassembly 2 - 22...

  • Page 47: Part Lists

    Appendix A:Part Lists This appendix breaks down the WA50SFQ series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 48: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 COMBO page A - 6 DVD Dual Drive page A - 7 page A - 8...

  • Page 49: Top

    Figure A - 1 Top A - 3...

  • Page 50: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 51: Combo

    COMBO Figure A - 3 COMBO COMBO A - 5...

  • Page 52: Dvd Dual

    DVD DUAL Figure A - 4 DVD DUAL A - 6 DVD DUAL...

  • Page 53: Hdd

    Figure A - 5 HDD A - 7...

  • Page 54: Lcd

    Figure A - 6 A - 8 LCD...

  • Page 55: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the WA50SFQ notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 56: System Block Diagram

    Schematic Diagrams System Block Diagram WA50SH WA50SH/SR System Block Diagram (Shark Bay) VDD3,VDD5 SHEET 39 3IN1 6-7P-WA503-002 GPU NVDIDA N14x NVVDD PCIE*8 MAIN BOARD SHEET 42 SHEET 1~42 WA50SH/SR PCB:6-71-WA500-D02 Haswell Nvidia Fermi N14x RTD2136R WA50SH BOM:6-77-WA50SH00-D02 5V,3V,5VS,3VS RAM SIZE 2GB (256MX16)->WA50SH PROCESSOR WA50SR BOM:6-77-WA50SR00-D02...

  • Page 57: Processor 1/7-Dmi, Fdi, Peg

    Schematic Diagrams Processor 1/7-DMI, FDI, PEG Haswell rPGA Processor 1/7 ( DMI,PEG,FDI ) CPU HOLD VCCIOA_OUT U24A Haswell rPGA EDS PEG_IRCOMP 24.9_1%_04 PEG_RCOMP H4_3B6_5D4_3 H4_3B6_5D4_3 H4_3B6_5D4_3 PEG_RXN_0 PEG_RX#0 [14] PEG_RX#1 [14] [22] DMI_TXN0 DMI_RXN_0 PEG_RXN_1 PEG_RX#2 [14] [22] DMI_TXN1 DMI_RXN_1 PEG_RXN_2 PEG_RX#3 [14] [22]...

  • Page 58: Processor 2/7- Clk, Misc

    Schematic Diagrams Processor 2/7- CLK, MISC Haswell Processor 2/7 ( CLK,MISC,JTAG ) 1.05V_LAN_M Processor Pullups/Pull downs H_THRMTRIP_R_N *100_04 R409 VCCIO_OUT CPU_RST_N *75_04 R418 62_04 R388 H_PROCHOT# DDR3 Compensation Signals 10K_04 R385 H_CPUPWRGD_R SM_RCOMP_0 R393 100_1%_04 TRACE WIDTH 10MIL, LENGTH <500MILS SM_RCOMP_1 R394 75_1%_04...

  • Page 59: Processor 3/7- (Ddr3

    Schematic Diagrams Processor 3/7- (DDR3) Haswell Processor 3/7 ( DDR3 ) M_A_DQ[63:0] [10] M_B_DQ[63:0] Haswell rPGA EDS U24C Haswell rPGA EDS U24D M_A_DQ0 AR15 SA_DQ_0 RSVD_AC7 M_A_DQ1 AT14 4.5/ 4.5/ 16 M_B_DQ0 AR18 SA_DQ_1 SA_CK_N_0 M_A_CLK_DDR#0 [9] SB_DQ_0 RSVD M_A_DQ2 AM14 7 / 12 / 25 M_B_DQ1...

  • Page 60: Processor 4/7- Power

    Schematic Diagrams Processor 4/7- Power Haswell Processor 4/7 ( POWER ) VCCIN Haswell rPGA EDS U24E PROCESSOR CORE POWER AA26 AA28 V_VDDQ_DIMM ICCMAX Maximum Processor SV 48 VCCIN AA34 4.2A RSVD AA30 RSVD AA32 RSVD C525 C126 C539 C114 C537 AB26 RSVD AB29...

  • Page 61: Processor 5/7- Gfx Pwr

    Schematic Diagrams Processor 5/7- GFX PWR Haswell Processor 5/7 ( GRAPHICS POWER ) VCCIOA_OUT 3.3VS EDP_RCOMP 24.9_1%_04 EDP_UTIL *10K_04 VCCIO_OUT U24H Haswell rPGA EDS EDP_AUXN DDIB_TXBN_0 EDP_AUXN EDP_AUXP R375 DDIB_TXBP_0 EDP_AUXP DP_HPD DDIB_TXBN_1 EDP_HPD EDP_RCOMP 10K_1%_04 DDIB_TXBP_1 EDP_RCOMP EDP_UTIL Sheet 6 of 46 For RTD2136R DDIB_TXBN_2 EDP_DISP_UTIL...

  • Page 62: Processor 6/7- Gnd

    Schematic Diagrams Processor 6/7- GND Haswell Processor 6/7 ( GND ) Haswell rPGA EDS U24F Haswell rPGA EDS U24G AK34 AL10 AL11 AL12 AL14 AL15 AL17 AL18 AL20 AL21 AL23 AA11 AA25 AA27 AA31 AA29 AB10 AA33 AA35 AM10 AM13 AC25 AM16 AC27...

  • Page 63: Processor 7/7- Rsvd

    Schematic Diagrams Processor 7/7- RSVD Haswell Processor 7/7 ( RESERVED ) CFG Straps for Processor PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS (Default) CFG2 1: (DEFAULT)NORMAL OPERATION; LANE# DEFINITION MATCHES 0: LANE REVERSAL Haswell rPGA EDS U24I CFG2 *1K_04 RSVD_TP RSVD_TP...

  • Page 64: Ddr3 So-Dimm_1

    Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM A_0 V_VDDQ_DIMM 5.2mm 6-86-24204-005 CHANGE TO STANDARD 6-86-24204-002 C132 C137 C101 C136 0.1u_10V_X7R_04 *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 JDIMM1B JDIMM1A M_A_A[15:0] M_A_DQ[63:0] [4] V_VDDQ_DIMM M_A_A0 M_A_DQ0 M_A_A1 M_A_DQ1 V_VDDQ_DIMM M_A_A2 M_A_DQ2 M_A_A3 M_A_DQ3 VDD1 VSS16 C105 *10p_50V_NPO_04 M_A_A4 M_A_DQ4 VDD2...

  • Page 65: Ddr3 So-Dimm_2

    Schematic Diagrams DDR3 SO-DIMM_2 9.2mm SO-DIMM B_0 CHANGE TO STANDARD 6-86-24204-001 6-86-24204-006 JDIMM2B C107 *10p_50V_NPO_04 M_B_CLK_DDR0 M_B_CLK_DDR#0 JDIMM2A V_VDDQ_DIMM M_B_A[15:0] M_B_DQ[63:0] [4] C108 *10p_50V_NPO_04 M_B_A0 M_B_DQ0 M_B_CLK_DDR1 M_B_CLK_DDR#1 M_B_A1 M_B_DQ1 VDD1 VSS16 M_B_A2 M_B_DQ2 VDD2 VSS17 M_B_A3 M_B_DQ3 VDD3 VSS18 M_B_A4 M_B_DQ4 VDD4...

  • Page 66: Rtd2136R

    Schematic Diagrams RTD2136R Power 3.3VS 3.3VS AVCC33 DVCC33 DVCC33 HCB1608KF-121T25 HCB1608KF-121T25 ENBLT ENBLT [12] 10u_6.3V_X5R_06 10u_6.3V_X5R_06 0.1u_10V_X7R_04 0.1u_10V_X7R_04 *10K_04 Note: 1K_04 1. Entire trace of Panel VCC should be wider than 80-mil [6,12] EDP_HPD LVDS-L0N eDP DEL LVDS-L0N [12] LVDS-L0P LVDS-L0P [12] 0.1u_10V_X7R_04 DAUXn...

  • Page 67: Panel, Inverter

    Schematic Diagrams PANEL, INVERTER PANEL POWER PANEL CONNECTOR (30Pin & 40Pin CO-lay) OPEN_2A Short VLED *MTS3572G6 LED PANEL (LVDS Dual Channel). *0.22u_50V_Y5V_06 PLVDD Z1203 J_LCD1 3.3VS [11] LVDS-UCLKN LVDS-UCLKP [11] *4.7K_06 [11] LVDS-U1N LVDS-U2N [11] [11] LVDS-U1P LVDS-U2P [11] *1M_04 LVDS-U0N [11] 1u_6.3V_X5R_04 *100K_04...

  • Page 68: Hdmi, Crt

    Schematic Diagrams HDMI, CRT HDMI Repeater no level shief, D9,D10,D11 mount HDMI CONNECTOR ISET 3.3VS HDMI_SDA-C [23] HDMI_CTRLCLK 5VS_HDMI HDMI_SCL-C [23] HDMI_CTRLDATA For ESD 1.5VS 1.5VS 5VS_HDMI FLG# VOUT1 R607 R608 2.2K_04 2.2K_04 VIN1 VOUT2 VIN2 VOUT3 *BAV99 RECTIFIER *BAV99 RECTIFIER [3,36,39] SUSB C479...

  • Page 69: Vga Pci-E Interface

    Schematic Diagrams VGA PCI-E Interface 3.3V 3V3_RUN 3V3_AON R524 R521 N14x 1.0 3V3_RUN R524 R521 N15x 2.0 R174 10K_04 *10K_04 *10K_04 :$6+ :$65 6 6 PEX_CLKREQ# *MTN7002ZHS3 ,& 9*$ &+,3 19,',$ 13*9%$ 03 ,& 9*$ &+,3 19,',$ 13*7$ [28] PEG_CLKREQ# U34A *.$ )&%*$ %$//6 *.$ 01 )&%*$ %$//6...

  • Page 70: Vga Frame Buffer Interface

    Schematic Diagrams VGA Frame Buffer Interface Frame Buffer Interface Term Description U34C U34D U34B The total trace length measured BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 from GPU ball to capacitor is Under GPU no more than 150 mil COMMON COMMON 1.5V BGA_0908_P080_P085_P100_290X290 FBC_CMD[31:0] COMMON FBC_CMD[31:0] [17] The total trace length measured 3/17 FBB...

  • Page 71: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A 95$0 :$6+8888 ( :$658888 ( FBVDDQ Frame Buffer Partition A C623 C398 C663 C670 C679 C403 C419 C680 C628 C640 C657 C438 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 0.1uF X4 for FBVDDQ one chip VRAM 1.0uF X8 FBVDDQ...

  • Page 72: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B :$6+ DOO XQPRXQW Frame Buffer Partition B FBVDDQ C263 C258 C354 C189 C360 C339 C366 C614 C611 C569 C570 C613 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 *1u_6.3V_X5R_04 FBVDDQ FBVDDQ FBC_CMD[31:0] [15] FBC_CMD[31:0]...

  • Page 73: [18] Vga I/O

    Schematic Diagrams VGA I/O U34M U34K U34L BGA_0908_P080_P085_P100_290X290 COMMON BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 COMMON COMMON Description Term 8/17 IFPEF 6/17 IFPC 7/17 IFPD The total trace length measured ALL PINS NC FOR GF117 from GPU ball to capacitor is Under GPU ALL PINS NC FOR GF117 ALL PINS NC FOR GF117 no more than 150 mil The total trace length measured...

  • Page 74: Vga Nvvdd Decoupling

    Schematic Diagrams VGA NVVDD Decoupling U34F U34G U34H U34I BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 NVVDD BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 NVVDD COMMON COMMON COMMON COMMON 15/17 GND_1/2 13/17 NVVDD 9/17 XVDD 16/17 GND_2/2 AM25 AA17 AA12 CONFIGURABLE AA18 AN10 AA14 POWER AA20 AN13 AA16 C294 C277 C296 CHANNELS AA22...

  • Page 75: Lynx 1/9

    Schematic Diagrams Lynx 1/9 Lynx Point - M (HDA,JTAG,SATA) RTCVCC BAT54CS3 VDD3 C687 1u_6.3V_X5R_04 RTC_VBAT_1 C598 R268 18p_50V_NPO_04 20K_1%_04 RTC_RST# R616 6-22-32R76-0B2 R535 6-22-32R76-0BG LPT_PCH_M_EDS 1K_04 C371 JOPEN2 U32A 1u_6.3V_X5R_04 *OPEN_10mil-1MM MC-306_32.768KHz 10M_04 RTC CLEAR SATARXN0 SATA ODD SATA_RXN_0 R550 C599 RTC_X1 SATARXP0...

  • Page 76: Lynx 2/9

    Schematic Diagrams Lynx 2/9 NO REBOOT STRAP 3.3VS NO REBOOT STRAP: HDA_SPKR High Enable 10K_04 R129 SERIRQ VDD3 RN16 2.2K_8P4R_04 SML0_DATA Lynx Point - M (LPC,SMBUS,SPI,C-LINK) SML0_CLK SMB_DATA iTPM ENABLE/DISABLE SMB_CLK TPM FUNCTION:SPI_SI High Enable SPI_SI *1K_04 R432 PCH_GPIO74 R204 10K_04 LPT_PCH_M_EDS U32D...

  • Page 77: Lynx 3/9

    Schematic Diagrams Lynx 3/9 Lynx Point -M (DMI,FDI,PWRGD) 3.3VS LPT_PCH_M_EDS U32B PM_CLKRUN# R132 8.2K_04 AW22 DMI_RXN0 DMI_RXN_0 AR20 AC_PRESENT R218 *100K_04 DMI_RXN1 DMI_RXN_1 AJ35 FDI_TXN0 [6] FDI_RXN_0 AP17 DMI_RXN2 DMI_RXN_2 AV20 AL35 DMI_RXN3 DMI_RXN_3 FDI_RXN_1 FDI_TXN1 [6] RTCVCC AY22 AJ36 FDI_TXP0 [6] DMI_RXP0 DMI_RXP_0...
  • Page 78 Schematic Diagrams Lynx 4/9 3.3VS D_GPU_PWR_EN# 10K_04 R212 BLON *1K_04 R188 Lynx Point -M (CRT,LVDS,PCI,DISPLAY) L_BRIGHTNESS_R *1K_04 R189 EXTTS_SNI_DRV1_PCH *10K_04 R213 EXTTS_SNI_DRV0_PCH *10K_04 R214 DGPU_HOLD_RST# 10K_04 R547 HDMI_CTRLDATA 2.2K_04 R191 HDMI_CTRLCLK 2.2K_04 R190 CRIT_TEMP_REP#_R *10K_04 R171 [9,24] CRIT_TEMP_REP#_R Boot BIOS Strap 10K_8P4R_04 BBS_BIT1 BBS_BIT0...

  • Page 79: Lynx 4/9

    Schematic Diagrams Lynx 5/9 Lynx Point - M (GPIO,CPU/MISC,NCTF) VDD3 R170 10K_04 HOST_ALERT#1 PCH_GPIO8 R173 10K_04 R165 *10K_04 PLL_ODVR_EN VDD3 LPT_PCH_M_EDS U32F R197 10K_04 PCH_GPIO27_R S_GPIO R137 100_04 S_GPIO_R BMBUSY#/GPIO0 R205 10K_04 PM_LANPHY_ENABLE SMI# [23,35] SMI# TACH1/GPIO1 PM_LANPHY_ENABLE R202 *1K_04 R168 *1K_04 PLL_ODVR_EN...

  • Page 80: Lynx 6/9

    Schematic Diagrams Lynx 6/9 Lynx Point -M (PCIe,USB) PCI-E x1 Usage USB 2.0 P O R T RN13 VDD3 U32I LPT_PCH_M_EDS U S B 2 7 P O R T U S B 3 . 0 10K_8P4R_04 Lane 1 USB_OC#1011 USB_OC#45 AW31 Lane 2...

  • Page 81: Lynx 7/9

    Schematic Diagrams Lynx 7/9 0.1A Lynx Point -M (POWER) 1.5A VCCA_DAC_1_2 1.5VS U32G LPT_PCH_M_EDS CO-LAY CO-LAY 1.05V_LAN_M HCB1608KF-121T25 HCB1608KF-121T25 VCCA_DAC1.5V VCCADAC1_5 AA24 C284 C283 C289 C293 C290 C585 C313 C310 C300 C312 CRT DAC AA26 C183 C218 C234 C220 AD20 VCCADACBG3_3 AD22 10u_6.3V_X5R_06...

  • Page 82: Lynx 8/9

    Schematic Diagrams Lynx 8/9 Lynx Point - M (POWER) 3.3V_PCH PJ33 3.3V *OPEN-3mm 3.3V_PCH 0.015A 3.3V_PCH VDD3 PJ32 *OPEN-3mm C270 C271 *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 LPT_PCH_M_EDS U32H 0.261A VDD3 Default C273 R555 VCCSUS3_3 VCCSUS3_3 *15mil_short_06 0.1u_16V_Y5V_04 VCCSUS3_3 VCCSUS3_3 1.05V_LAN_M VCCSUS3_3 GPIO/LPC Sheet 27 of 46 VCCSUS3_3 R180 *10mil_short...

  • Page 83: Lynx 9/9

    Schematic Diagrams Lynx 9/9 Lynx Point -M (GND) Lynx Point -M (CLK) U32K LPT_PCH_M_EDS AA16 AA20 LPT_PCH_M_EDS AA22 U32C AA28 AB12 AB35 VGA_PEXCLK# [14] CLKOUT_PCIE_N_0 CLKOUT_PEG_A AB34 AB38 BA40 AB36 100MHz CLKOUT_PCIE_P_0 CLKOUT_PEG_A_P VGA_PEXCLK [14] BD11 BD15 PCIECLKRQ0# PEG_CLKREQ# PEG_CLKREQ# [14] PCIECLKRQ0#/GPIO73 PEGA_CLKRQ#/GPIO47 AC44...

  • Page 84: 3G, Wlan, Msata

    Schematic Diagrams 3G, WLAN, mSATA For WA50SR H3_9B6_0D3_7 3G CARD / mSATA C711 *220u_6.3V_6.3*6.3*4.2 C706 220u_4V_V_A 6-34-M56AS-011-1 C488 0.1u_16V_Y5V_04 J_3G1 60mils 3G_3.3V R620 *0_04 [22,29,32] PCIE_WAKE# 3G_3.3V WAKE# 3.3VAUX_0 COEX1 1.5V_0 3G POWER UIM_PWR COEX2 UIM_PWR UIM_DATA UIM_PWR *4.7K_04 UIM_DATA UIM_DATA SIM CONN UIM_CLK...

  • Page 85: [30] Tpm, Ccd , Led, Lid

    Schematic Diagrams TPM, CCD, LED, LID OQDU531 OQDU531 OQDU531 OQDU531 Colay CCD + Digital & Anolog MIC Z2902 R586 *0_04 3.3V C642 C651 R590 0_04 3.3VS 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 TMC:766! TMC:766! TMC:766! TMC:766! CCD_PWR [21,35] LPC_AD0 LAD0 PIN5 PIN5 [21,35] LPC_AD1 GPS! ODQ531 GPS! ODQ531 GPS! ODQ531...

  • Page 86: Esata/Usb3.0, Usb Charger

    Schematic Diagrams eSATA/USB3.0, USB Charger USB CHARGER PORT USB3.0 PORT(PORT3) Smart CDP USBVCC_CH Function W/ USB CHARGER pin8 pin4 DCP autodetect with mouse/keyboard wake up 80 mil S0 Charging with SDP C497 22u_6.3V_X5R_08 C498 22u_6.3V_X5R_08 S0 Charging with CDP C683 *220u_6.3V_6.3*6.3*4.2 If select CB pin contact to SUSB#, you can Support R347...

  • Page 87: Card Reader (Rtl8411B

    Schematic Diagrams Card Reader (RTL8411B) LAN (RTL8411B) Crystal 503 2 SI Z E SD_CARD ONLY RSET R573 2.49K_1%_04 Switching Regulator close to PIN48 meet realtek Freq tolerance 50ppm R583 *1K_04 XTAL2 R601 0_06 J_CARD-REV1 VDD10 R589 10K_04 (>20mil) AVDD33 R579 1M_04 XTAL1 SD_D2/MS_CLK_R...

  • Page 88: Hdd, Tp, Audio & Power Con

    Schematic Diagrams HDD, TP, Audio & Power Con CLICK PAD & Touch PAD for 17" Card Reader HDD CONNECT1 (MASTER) CLICK PAD For 15",17" 3.3VS R112 0_04 3.3V 3.3VS J_HDD1 Gen3 SATA_TXP5_L C693 0.01u_16V_X7R_04 For Touch Pad 14" SATA_TXP5 [20] SATA_TXN5_L C691 0.01u_16V_X7R_04...

  • Page 89: Audio Codec Alc269Q

    Schematic Diagrams AUDIO CODEC ALC269Q For 1.5V HDA Link. R624 *0_04 1.5VS CODEC (AL269Q_VB7) DVDD_IO PVDD1_2 For 3.3V HDA Link. R612 R625 *10mil_short 3.3VS_AUD C702 C490 C474 C685 *15mil_short_06 EMI Require 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 976/ & XQPRXQW $/&4/ & PRXQW *HCB1005KF-121T20 5VS_AUD 3.3VS...

  • Page 90: Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD HCB1005KF-121T20 MODEL_ID Voltage VDD3 VDD3 C402 C367 C365 C400 WA50SH 3.3V 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 C391 C395 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 WA50SR C383 KBC_AGND 0.1u_16V_Y5V_04 3.3VS VDD3 J_KB1 U14A 85208-24051 R283 10K_04 MODEL_ID KB-SI0 R284 *10K_04 [21,30] LPC_AD0 GPM0/LAD0 KSI0/STB#...

  • Page 91: 5Vs, 3Vs, 3.3Vm, 1.5Vs_Cpu

    Schematic Diagrams 5VS, 3VS, 3.3VM, 1.5VS_CPU 3.3VS DD_ON# SUSB SLP_A NMOS PQ65A VDD3 SYS15V 3.3VS VDD3 VDD3 MTS2072G6 VDD3 PR219 PR225 PR218 PC204 PC205 PR50 PR217 10K_04 10K_04 1M_04 22_04 100K_04 DD_ON# [31,39] SUSB [3,13,39] 3.3VS_EN1 SLP_A [36,37] PQ67B PC203 PC209 PC202 [31,35,38]...
  • Page 92 Schematic Diagrams 1.05V PR38 280K_04 1.05V_LAN_M VTT_SELECT VTT VR Output Voltages IMAX:5A 1.1 V PC155 PC151 PC152 high (V1.1S_VTT) 1.05 V OCP:10A 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 PR169 1.05V_LAN_M For CV test PR37 3.3V PC158 10_04 0_06 *CV-40mil PC157 0.1u_50V_Y5V_06 TMPC0603H-1R0M-Z01 PR34 10K_04 PJ28 *OPEN-5mm...

  • Page 93: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR80 *0_04 PR79 *20mil_04 PC77 1u_6.3V_X5R_04 PR81 PR75 EN_3V EN_5V PC75 130K_04 130K_04 PC76 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PC59 PC57 PC74 PR72 *10K_04 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 SYS5V VDD3 LDO3 PC58 PC52 PC56 PC72 0.1u_10V_X7R_04 VDD5 PC73 0.1u_50V_Y5V_06 4.7u_25V_X5R_08...

  • Page 94: 1.5V Or 1.35V / 0.75Vs, 1.5Vs

    Schematic Diagrams 1.5V or 1.35V / 0.75VS, 1.5VS 1.5V or 1.35V/0.75VS PQ21 1.5V or 1.35V MDU1516 PC106 PC111 PC112 PC113 ULTRASO-8 IMAX:8A RB0540S2 G5616 VDDQ_VTT OCP:15A PC96 VDDQ 10u_6.3V_X5R_06 PC14 0.1u_10V_X7R_04 Short VLDOIN VBST PJ18 PR105 Z3701 Z3710 Z3718 Short VDDQ_VTT DRVH VDDQ...

  • Page 95: Power Vcore

    Schematic Diagrams POWER VCORE 3.3VS PR183 100K_1%_NTC_04 PR41 150K_1%_0603 SWN3 100K_04 PUT COLSE PC38 PC48 PC37 PC49 PC50 PJ10 TO VCORE PR45 150K_1%_0603 SWN1 *8mm Phase 1 PJ34 PR148 PR39 Inductor APGND VIN_CPU *CV-40mil 75K_1%_04 165K_1%_04 PC167 PC174 PC46 PC47 PC166 PC39 PQ46...

  • Page 96: Dc In, Charger

    Schematic Diagrams DC IN, CHARGER SMART CHARGER Z4110 PR20 *20mil_04 *EMB20P03V PQ18 V_BAT EMB20P03V PR98 100K_06 EMB20P03V 11/17 6-15-32023-7B0 J_DC_JACK1 VJACK PQ19 PQ20A HCB2012KF-800T80 Close JBATTA2 *EMB20P03V EMB17A03V PR100 PR104 0.01_1%_32 8.2UH_6.8*7.3*3 0.01_1%_32 Z4104 88298-0201 PC114 PR107 PQ20B J_DC_JACK2 EMB17A03V PR18 100K_04 Z4103...

  • Page 97: N14P, Nvvdd, Pex, Fbvddq

    Schematic Diagrams N14P, NVVDD, PEX, FBVDDQ VGA__NVVDD 3V3_RUN 3V3_RUN PR30 PR29 3V3_RUN 3.3V PR157 *1K_04 *0_04 PR31 GPU_3V3_MAIN_EN# 0_04 0_04 PR174 0_04 NVVDD_PSI [18] [18] GPU_PWR_VID PC141 PR175 PR230 *47p_50V_NPO_04 *56K_04 56K_04 UP1462_VREF PR28 PJ31 [18] 1642_DGPU_ON *10K_04 1642_DGPU_ON 40mil FBVDDQ PC136 MTN7002ZHS3...

  • Page 98: [43] Audio Board

    Schematic Diagrams AUDIO BOARD USB2.0 CON USB PORT(PORT9) AC13 *22u_6.3V_X5R_08 AGND *0_04 *0_04 6-71-WA508-D02 *0_04 *0_04 0.1u_10V_X7R_04 A_USBVCC2 AGND *0_04 *0_04 A_5V A_USBVCC2 AC12 22u_6.3V_X5R_08 AGND *10K_04 60 mil AJ_USB2 AUDIO BOARD FLG# VOUT1 60 mil AUSB_PN9 VIN1 VOUT2 DATA_L AC19 AC20 AC18...

  • Page 99: [44] Power Switch Board

    Schematic Diagrams POWER SWITCH BOARD *0_04 *0_04 6-71-WA50S-D02 *0_04 *0_04 *0_04 *0_04 POWER & LED BOARD BH_5VS BJ_SW1 BPWRBTN# BDGND Sheet 44 of 46 BLED_SCROLL# BLED_NUM# BLED_CAP# POWER SWITCH 88486-1001 BOARD BH_5VS BH_5VS BH_5VS BH_5VS 820_06 820_06 820_06 820_06 POWER POWER BUTTON BSW1...
  • Page 100 Schematic Diagrams B - 46...

  • Page 101: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 102: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
