Horizon Fitness BQ-270 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

• This manual is designed to help you to install, operate and maintain the BQ-270 Perfect Binder.
Please read and understand this manual, and keep it in a safe and convenient place.
• Do not operate the BQ-270 until you read and understand the instructions in this manual.
• Horizon International Inc. shall not be liable for incidental consequential damages resulting from:
improper or inadequate maintenance by the customer unauthorized modification or misuse, or
operation outside of the environmental specifications for the product.
• Horizon International Inc. pursues a policy of continuing improvement in design and performance
of the product. Therefore, the product design and specifications are subject to change without prior
notice and without our legal obligation.
• All rights are reserved. No part of this manual may be photocopied, reproduced or translated to
another language without the prior written consent of Horizon International Inc.
040425/BQ270/10E/HS, TM, HH, HS
PERFECT BINDER
PERFECT BINDER
Important Information
BQ-270
UM202048-10
