Quick Use
Quick Use
Guide
Guide
AZ1830
1
Choosing Power Supply
a
Connect the AC power cord to the
AC~ Mains inlet and the wall socket.
-OR-
b Open the battery door and insert 6
x C batteries (not included).
2
Listening to the Radio
a
Push the source selector to
TUNER.
b Adjust BAND to MW or FM.
c
Turn TUNING to tune to a
station.
3
Playing a disc
This player plays Audio Discs
including CD-R/CD-RW, and
MP3-CD.
a
Adjust the source selector to
CD/USB.
b Press CD/USB to enter CD
mode if USB DIRECT is displayed.
c
Open the disc door.
d Insert a disc with the printed side
facing up and close the door.
e Press 38 to start playback.
To stop disc playback, press 9.
f
1a
6 x R14 • UM-2 • C-CELLS
1b
R-14, UM-2 or C-cells
(not included)
2a
3a
4a
3c
3e
3f
4d
4c
3b
4b
4
Playing a USB device
a
Push the source selector to CD/USB.
b Press CD/USB to enter USB mode if USB
DIRECT is NOT displayed.
c
Plug a compatible USB mass storage device
to AZ1830's USB port marked
.
d Press 2; on your AZ1830 to start play.
Source selector
Slide to select
function: CD/MP3
(or USB mode), or radio
VOLUME
Turn to adjust volume level
LIFT TO OPEN
Lift to open the disc
door
ALBUM+/-
For MP3-CD/USB play:
Press to select albums
9
Press to stop disc/USB
playback, or erase a disc
program
DBB
Turns the bass
enhancement on/off
2b
2c
PROG
Use to program disc
tracks and review a disc
program.
USB Port
Connects an external
USB mass storage device
Removing the insulation plastic tab
TUNING
Turn to tune to a
station
BAND
Slide to select waveband
Telescopic antenna
Improves FM reception
∞
§
,
Briefly press to skip to
the beginning of the
current/previous/
later disc track;
During disc playback,
press and hold to find a
particular passage
backward/forward.
38
Press to start or pause
disc/USB playback
Display
Shows disc/USB functions
CD/USB
Press to enter disc or
USB mode
MODE
Press to select different
play modes, such as
REPEAT or SHUFFLE
(random order)
