MODELS
72"models
Professional 72" Range Models:
RG68BFTGD & RG66BFT2GD
Caliber Pro Range (R) Configurations
RG68BFTGD
Eight burners, French Top &
Griddle
72"
RG66BFT2GD
Six burners, French Top &
Double Griddle
8
PLANNING THE INSTALLATION
IMPORTANT INSTALLATION INFORMATION
The range Is tested In accordance with ANSI Z21.1 Standard for Household Cooking Gas Appliances.
The range must be Installed In conjunction with a suitable overhead vent hood. (See section 'Ventila-
tion
Requirements'). Due to the professional high heat capacity of this unit, particular attention should be
paid to the hood and duct work installation to ensure it meets local building codes. To eliminate risk
of burns or fire by reaching over heated surface units, cabinet storage located above the surface units
should be avoided.
All range and rangetop models have an integral island trim with a hight of 2 5/8" from countertop
level. - See section 'Backguard Installation'.
All range and rangetops have a standard 2 5/8" integral island trim.
• For all ranges and rangetops, the full backguard may be purchased separately from Caliber
(see specifications information below in Fig.1).
33 3/8"
for
all
models
35 7/8" for 36" models
Fig. 1
47 7/8" for 48" models
71 7/8" for 72" models
Check local building codes for the proper method of range installation. Local codes vary.
Installation, electrical connections, and grounding must comply with all applicable codes. In the
absence of local codes, the range should be Installed in accordance with the latest edition of
National Fuel Gas Code ANSI Z223.1 and National Electrical Code ANSI/ NFPA 70.
Be sure that the unit being installed is set up for the kind of gas being used. The gas range is
shipped from the factory set and adjusted for Natural Gas or LP (propane), depending on the
specific model ordered. Verify that the range Is compatible with the gas at the installation site
before proceeding further. Return range to dealer if the unit is not set for site gas supply.
Full Backguard Specifications
Width
Height
48" Range
and Rangetop
47 7/8"
33 3/8"
Models
36" Range
and Rangetop
35 7/8"
33 3/8"
Models
72" Range
71 7/8"
33 3/8"
Models
9
