- Page 1 Register your product and get support at www.philips.com/welcome EN User manual MCD107...
-
Page 2: Table Of Contents
Contents 1 Important Safety Notice Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Connect Preparations Connect speakers Connect TV Connect power 4 Get started Prepare the remote control Auto install radio stations Set clock Turn on Set up the TV... -
Page 3: Important
1 Important This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The ‘exclamation point’ calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. - Page 4 Remove batteries when the unit is not used for a long time. dripping or splashing. considerations. For disposal or recycling authorities or the Electronic Industries Alliance: www.eiae.org. Warning Never remove the casing of this apparatus. Never lubricate any part of this apparatus. Never place this apparatus on other electrical equipment.
-
Page 5: Notice
Notice device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. This product complies with the radio interference requirements of the European Community. This product complies with the requirements of the following directives and guidelines:... -
Page 6: Introduction
Congratulations on your purchase, and support that Philips offers, register your product at www.Philips.com/welcome. Introduction With this unit, you can: watch video from DVD/VCD/SVCD or USB devices enjoy audio from audio CDs, external devices, or USB devices view pictures from discs or USB devices... -
Page 7: Overview Of The Main Unit
b IR Remote control sensor Show current status. Jack for an external audio device. Headphone jack USB socket Select a source: Disc, USB, FM tuner, or MP3 link. Turn on or off dynamic bass enhancement. Adjust volume. Stop play or erase a program. l ∞/§... -
Page 8: Overview Of The Remote Control
p Power cord Improve FM reception. control Turn on the unit, switch to standby mode, or switch to Eco Power Standby. - Page 9 Select a source. Access or exit the system setup menu. Mark the section for repeat play, or turn off repeat mode. Search fast forward or fast backward. Tune to a radio station. Navigate left/right in the disc menu or system setup menu. Adjust time.
-
Page 10: Connect
3 Connect Preparations surface. Place the unit onto the cloth. Remove the socket cover. Note Ensure that the colors of the speaker wires and terminals are matched. Insert the stripped part of the wire completely. Insert the right speaker wires to “... -
Page 11: Connect Power
S-video provides better picture quality than AV out connections. Connect an S-video cable (not supplied) socket on this unit. the S-Video socket on the TV. S-VIDEO IN Connect power Caution Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back or the underside of the unit. -
Page 12: Get Started
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the rear of the apparatus. Write the numbers here: Model No. -
Page 13: Turn On
DISC source. Turn on the TV and then select the correct video-in channel. » You should see the blue Philips DVD background screen. See the TV user manual for details of how to select the correct video-in channel. -
Page 14: Play
5 Play Caution Risk of damage to the unit! During play, never move the unit. Note If ‘INVALID KEY’ is displayed, the function is Play discs Caution Never look at the laser beam inside the unit. Risk of product damage! Never play discs with accessories such as disc stabilizer rings or disc treatment sheets. -
Page 15: View Pictures
extensions (.srt, .smi, .sub, .ssa, .ass) are navigation menu. Insert a picture disc or connect a USB device. Select a source: For discs, press For USB devices, press USB. Press to start the slide show. Slide show play modes You can view pictures as slide show in different play modes. -
Page 16: Play Options
During music or video play, press at the start point. Press at the end point. » The section starts to play repeatedly. » To cancel repeat play, press again. The section A and B can be set only within the same chapter/track. -
Page 17: Listen To Radio
6 Listen to radio Press to select FM. Press and hold for more than 2 seconds. » [SEARCH] (search) is displayed. » The radio tunes to a station with strong reception automatically. Repeat step 2 to tune to more stations. To tune to a weak station, press reception. -
Page 18: Adjust Sound
7 Adjust sound During play, press decrease the volume level. During play, press repeatedly to select: [POP] (pop) [JAZZ] (jazz) [CLASSIC] (classic) [ROCK] (rock) During play, press to turn on or off dynamic bass enhancement. » If DBB is activated, DBB is displayed. During play, press to mute/unmute sound. - Page 19 Select setup). Select an option, then press language): Select a language for on- screen display. (audio language): Select an audio language for DVD play. language): Select a subtitle language for DVD play. (menu language): Select a language for DVD root menu (DivX language): Select a subtitle language for DivX...
-
Page 20: Video Settings
» Material is unsuitable for children under age 13. Parental guidance suggested. » Recommended that parents restrict children under 17 from viewing or allow them to view only when supervised by a parent or adult guardian. » Not recommended for children under age 17. -
Page 21: Audio Settings
Audio settings Select audio downmix Select a suitable audio downmix when you are playing a DVD recorded in Dolby Digital format. Press Select (downmix), then press Select an option, then press : Select this if the unit is connected to a Dolby Pro Logic decoder. -
Page 22: Set The Alarm Timer
Set the alarm timer This unit can be used as an alarm clock. The DISC, USB or TUNER is activated to play at a preset time. Ensure that you have set the clock correctly. In standby mode, press and hold Press or USB to select a source. - Page 23 10 Product Note Product information is subject to change without prior notice. Rated output power 2 X 5 W RMS Frequency response 60 - 16 kHz, ±3 dB Signal to noise ratio >65 dB Aux input 0.5 V RMS 20 kohm Laser type Semiconductor Disc diameter...
-
Page 24: Usb Playability Information
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www. philips.com/welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available. - Page 25 Disconnect and reconnect the AC power plug, then turn on the system again. As a power-saving feature, the system switches off automatically 15 minutes after track play reaches the end and no control is operated. Before you press any function button, remote control instead of the main unit.
- Page 26 Analog audio Sound that has not been turned into numbers. Analog sound is available when you use the AUDIO LEFT/RIGHT. These red and white jacks send audio through two channels, the left and right. Aspect ratio Aspect ratio refers to the length to height ratio of TV screens.
- Page 27 refers to a structure of sound tracks having three or more channels. Parental control A function of the DVD to limit playback of the disc by the age of the users according to the limitation level in each country. The limitation varies from disc to disc;...
