Nortel Ethernet Routing Switch 8600
Installing and Maintaining the
Ethernet Routing Switch 8000
Series Chassis
NN46205-303 (316314-F Rev 03)
.

Advertisement

Table of Contents
loading

Related Manuals for Nortel 8000 Series

Summary of Contents for Nortel 8000 Series

  • Page 1 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 (316314-F Rev 03)
  • Page 2 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject...

  • Page 3: Table Of Contents

    Installing the cable management brackets 57 Installing 8004DC power supplies with the BIP 59 Grounding the chassis 59 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 4 Physical specifications 94 Network Equipment Building Standard 94 Environmental specifications 95 Maximum airflow 95 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 5: Contents

    8003 chassis 101 Physical specifications 101 Environmental specifications 102 International regulatory requirements 102 Index Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 6 6 Contents Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 7: New In This Release

    Table 6 "Accessories shipped with the 8010, 8006, and 8003 chassis" (page is updated with part numbers. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 8 8 New in this release Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 9: Introduction

    This document provides the instructions to install the Nortel Ethernet Routing Switch 8600 chassis in an equipment rack. This document also describes some of the routine tasks to operate the Nortel Ethernet Routing Switch 8600 and includes technical specifications for the chassis and modules.

  • Page 10: Regulatory Information

    10 Introduction Regulatory information International regulatory statements of conformity This is to certify that the Nortel Networks 8000 Series chassis and components installed within the chassis were evaluated to the international regulatory standards for electromagnetic compliance (EMC) and safety and...
  • Page 11 Regulatory information 11 CE marking statement (Europe only) EN 55 022 statements This is to certify that the Nortel Networks 8000 Series chassis and components installed within the chassis are shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC.
  • Page 12 National safety statements of compliance CE marking statement (Europe only) EN 60 950 statement This is to certify that the Nortel Networks 8000 Series chassis and components installed within the chassis are in compliance with the requirements of EN 60 950 in accordance with the Low Voltage Directive.
  • Page 13 + one redundant supply, two supplies, or two + one redundant supply configuration Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 14 + configuraciones de una fuente redundante Model 8005DC: Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 15 + configuraciones de una fuente redundante Denan statement (Japan/Nippon only) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 16 16 Introduction Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 17: Chassis Installation Fundamentals

    Slots are numbered from left to right. You can install Nortel Ethernet Routing Switch 8600 interface modules in slots 1 through 4 and in slots 7 through 10. Slots 5 and 6 are reserved for Nortel Ethernet Routing Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard...
  • Page 18 Routing Switch 8600 chassis with a mix of power supply models (8004 and 8005). If you upgrade the Nortel Ethernet Routing Switch 8600 and use a redundant power configuration, you can hot swap the 8004 power supply with the 8005 power supply while the Nortel Ethernet Routing Switch 8600 remains in operation.

  • Page 19: 8010 Chassis

    SF/CPU or 8692 SF/CPU modules. Slots are numbered from the top down. You can install Nortel Ethernet Routing Switch 8600 interface modules in slots 1 through 4 and in slots 7 through 10. Slots 5 and 6 are reserved for Nortel Ethernet Routing Switch 8600 SF/CPU modules.
  • Page 20 Routing Switch 8600 chassis with a mix of power supply models (8004 and 8005). If you upgrade the Nortel Ethernet Routing Switch 8600 and use a redundant power configuration, you can hot swap the 8004 power supply with the 8005 power supply while the Nortel Ethernet Routing Switch 8600 remains in operation.

  • Page 21: 8006 Chassis

    8691 SF/CPU or 8692 SF/CPU modules. The top four slots are for the installation of 8600 interface modules. Slots 5 and 6 are reserved for Nortel Ethernet Routing Switch 8600 SF/CPU modules.
  • Page 22 Routing Switch 8600 chassis with a mix of power supply models (8004 and 8005). If you upgrade the Nortel Ethernet Routing Switch 8600 and use a redundant power configuration, you can hot swap the 8004 power supply with the 8005 power supply while the Nortel Ethernet Routing Switch 8600 remains in operation.

  • Page 23: 8003 Chassis

    8691 SF/CPU module. ATTENTION The 8003 chassis does not support the 8692 SF/CPU with 8000 Series Software Release 3.7. The 8003 chassis does not support the following R modules with Software Release 4.x:...

  • Page 24: Power Supplies

    24 Chassis installation fundamentals For information about power supply and fan installation, see Installing an AC Power Supply in an Ethernet Routing Switch 8000 Series Chassis (NN46205-306; 312751-E) and Installing a Fan Tray in an Ethernet Routing Switch 8000 Series Chassis (312752-E).

  • Page 25: Fan Trays

    312751-E) or Installing a DC Power Supply in an Ethernet Routing Switch 8000 Series Chassis (NN46205-307; 313070-E). Fan trays The following table lists the number of fan trays for each Nortel Ethernet Routing Switch 8600 chassis. Table 1 Number of fan trays installed in each chassis...

  • Page 26: Site Requirements

    (page 85). For AC input power specifications for each of the modules, see Installing an AC Power Supply in an Ethernet Routing Switch 8000 Series Chassis (NN46205-306; 312751-E). DC input electrical requirements (8010 and 8006 chassis) The installation site must meet the electrical requirements for DC power as shown in Table 2 "Electrical requirements for the DC models"...

  • Page 27: 8010Co Chassis

    60 A for each DC input Reinforced insulation feed from the main DC power Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 28: Hardware Requirements

    8010 chassis • one bracket each for the 8006 and 8003 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 29 Figure 5 Items in the 8010 chassis shipping container Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 30 30 Chassis installation fundamentals Figure 6 Items in the 8006 chassis shipping container Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 31 AT-compatible modem to allow dial-in access to startup configuration and diagnostics. Cables Unless you specifically order them, Nortel does not include the cables required for your network configuration in the chassis accessory package. If you need the proper cables, contact your network administrator.

  • Page 32: 8010Co Chassis

    Manage network interface cables. bracket Two side cable management Manage network interface cables. brackets Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 33 8010co hardware, ensure that you obtain all the cables, tools, and other equipment you need. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 34: Successful Installation Verification

    If the rack does not use threaded rail holes, you must use the supplied clip nuts with the clip nut screws. Cables Unless you specifically order them, Nortel does not include the cables required for your network configuration in the 8010co chassis accessory package. If you require the proper cables, contact your network administrator.
  • Page 35 Contact your network administrator to verify that the Nortel Ethernet Routing Switch 8600 is now connected to the network. If the LEDs do not light in this sequence, contact your local Nortel Technical Solutions Center. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard...
  • Page 36 36 Chassis installation fundamentals Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 37: 8010, 8006, And 8003 Chassis Installation

    Prerequisites to chassis installation • Inspect all items for shipping damage. If you detect damage, do not install the chassis. Call the Nortel Technical Solutions Center in your area. • Verify that the items in the shipping container match those on the shipment packing list.

  • Page 38: Mounting The Chassis In An Equipment Rack

    (12.7 cm) at the front for power cord clearance. Attach rubber feet to each marked location on the bottom of the chassis. The rubber feet are optional but Nortel recommends that you use them to help keep the unit from moving. —End—...
  • Page 39 Insert and tighten the supplied Phillips-head screws to fasten each bracket to the chassis. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 40 Attaching the rack-mounting brackets to the 8010 chassis Attaching the rack-mounting brackets to the 8006 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 41 8003 chassis" (page 42). Aligning the rack-mounting brackets with the equipment rack: 8010 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 42 (page 43), and "Installing the 8003 chassis in an equipment rack" (page 43). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 43 Installing the 8006 chassis in an equipment rack Installing the 8003 chassis in an equipment rack Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 44: Installing The Cable Management Brackets

    "Loosening the rack-mounting screws: 8003 chassis" (page 45). Loosening the rack-mounting screws: 8010 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 45 "Sliding the bracket onto the screws: 8003 chassis" (page 46). Sliding the bracket onto the screws: 8010 and 8006 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 46 8003 chassis" (page 47). Securing the bracket to the chassis: 8010 chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 47 Securing the bracket to the chassis: 8006 chassis Securing the bracket to the chassis: 8003 chassis —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 48 48 8010, 8006, and 8003 chassis installation Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 49: 8010Co Chassis Installation

    In a 7-ft two-post rack, you can install two 8010co chassis platforms and a BIP. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 50 Add a hex nut to each screw and tighten by using a hex wrench. Tighten each screw with a Phillips screwdriver. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...
  • Page 51 For more information about installing the chassis, see "Installing the 8010co chassis in a 19-in. two-post rack" (page 52). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 52 Make sure that the hole pairs on either side of the vertical support match horizontally. Tighten each screw with a Phillips screwdriver. —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 53: Mounting The Chassis In A Hendry Rack

    Mounting the chassis in a Hendry rack Mount the 8010co chassis in a Hendry rack. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 54 Installing the installation shelf in a Hendry rack Tighten each screw with a nutdriver. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 55 For more information about installing the mounting rails, see "Installing the mounting rails for a Hendry rack" (page 56). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 56 Lift the 8010co chassis onto the installation shelf. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 57: Installing The Cable Management Brackets

    For more information about securing the top cable management bracket, see "Installing cable management brackets" (page 58). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 58 Align the slots on the side bracket with the rods in the chassis. "Installing cable management brackets" (page 58). Push the bracket into place. —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 59: Installing 8004Dc Power Supplies With The Bip

    Install the 8010co chassis as described in previous procedures. Install the 8004DC power supplies as described in Installing a DC Power Supply in an Ethernet Routing Switch 8000 Series Chassis (NN46205-307; 313070-E) Install the BIP as described in Installing the Breaker Interface Panel for the Ethernet Routing Switch 8010co Chassis (312755-G).
  • Page 60 The following figure shows the location of the ground studs on the 8010co chassis rear panel. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 61 Your rack-grounding strip can look different or can be in a different location than the one shown in the example. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...
  • Page 62 Cabinet frame or equipment rack AWG 6 ground lead (provided with BIP) Upper shelf chassis ground stud Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 63 The following figure shows an example of how to ground two 8010co chassis. In this example, each chassis uses three AC power supplies. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...
  • Page 64 Cabinet frame or equipment rack Upper shelf chassis ground stud Upper shelf ground leads (not provided) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 65 Rack ground strip (example only) AC equipment ground (ACEG) leads within individual upper shelf cords (x 3) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 66 66 8010co chassis installation Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 67: Switch Operations

    If you wait longer to turn on the second power supply, one of the power supplies can shut off within Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...
  • Page 68 BIP are in the off position. Wait 1 minute. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 69: Powering On Ac Power Supplies

    On each power supply, turn the power switch to the on position. If the problem persists, contact the Nortel Technical Solutions Center. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...

  • Page 70: Resetting The Switch

    "Inserting a removable flash memory card: 8010, 8006, and 8003 chassis" (page 71). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 71 Insert the card into the card receptacle. Gently push in the card until it fits tightly in place. —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 72: Removing Removable Flash Memory Cards

    8010, 8006, 8003 chassis" (page 73). Removing a flash memory card: 8010co chassis Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 73: Protecting Memory Card Files

    Typically, you do not operate a Nortel Ethernet Routing Switch 8600 with a write-protected memory card. Make a copy of your configuration on another memory card, write-protect the second card, and store it in a safe place. If you do not use a second memory card, you can copy your configuration to a...
  • Page 74 Insert the card into the card receptacle. Gently push in the card until it fits tightly in place. —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 75: Troubleshooting

    Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 76: Apparent Module Failure

    To work around this issue, follow the steps in either workaround 1 or 2. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...

  • Page 77: Module Failure Workaround 1

    Insert a new module. Reboot the chassis. —End— If the module still fails to operate, contact the Nortel Technical Solutions Center for assistance. Failure to get a login prompt from the Console port If you connect a terminal to the Console port of an SF/CPU module and you fail to get a login prompt, the port may have an incorrect DCE/DTE setting.

  • Page 78: Cable Connection Problems

    Cabling for 10BASE-T networks can consist of two-pair Category 3, 4, or 5 unshielded twisted pair (UTP) wiring. However, to prepare for future upgrades to Fast Ethernet, Nortel strongly recommends that you use all Category 5 cable in your network.

  • Page 79: 100Base-T And 1000Base-T Cables

    GBICs, see Installing SFP and XFP Transceivers and GBICs (NN46205-305; 318034-D). Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 80 80 Troubleshooting Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 81: Common Procedures

    For more information, see Installing a Fan Tray in an Ethernet Routing Switch 8000 Series Chassis (312752-E). —End— Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 82 82 Common procedures Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 83: Part Numbers

    DS1405D 8003ACPS 100-240 V AC power supply Includes power cord used in Japan. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 84 8600 series console cable DS14110 8000 series cable management bracket DS14110 3-slot chassis rack-mount replacement kit Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 85: Technical Specifications

    Technical specifications This section details the specifications for the Nortel Ethernet Routing Switch 8600. Navigation • "Chassis weight" (page 85) • "Rack-mount" (page 86) • "Model 8003AC power supply" (page 86) • "Model 8004AC power supply" (page 87) • "Model 8005AC power supply" (page 87) •...

  • Page 86: Rack-Mount

    Hold-up time 20 ms The following table lists the DC output power specifications. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 87: Model 8004Ac Power Supply

    This section provides power ratings for the 8005AC power supply. The following table lists the AC input power specifications. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...

  • Page 88: Model 8004Dc Power Supply

    Input VA 1.4 kVA Input power consumption 1392 W Heat dissipation (thermal/output) 1850 BTU/hour Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 89: Model 8005Dc Power Supply

    12 VDC @ 7.5 A/24 A peak MTBF 108 803 hours (Telcordia TR-332 standard) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 90: Component Input Power

    The following table shows the total module input power consumption for a sample 8010 chassis configuration. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 91: 8004Ac Power Supply Example

    508 W (3.385 V x 150 A) Individual 12 VDC power rating 600 W (12 V x 50 A) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 92: 8004Dc Power Supply Example

    Do not exceed either an individual voltage source or the combined power rating. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 93: 8005Ac Power Supply Example

    8005AC power supply replaces the 8001AC power supply. The 8004DC or 8005DC power supply replaces the 8002DC power supply. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008...

  • Page 94: 8010Co Chassis

    The 8010co chassis complies with Network Equipment Building Standard (NEBS) Level 3 as specified in SR3580. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 95: Environmental Specifications

    ICES-003, Issue-2, Class A Europe EN 55022-1998 Class A; EN 61000-3-2/A14, EN 61000-3-3 (CE Marking) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 96: 8010 Chassis

    "International regulatory requirements" (page 97) Physical specifications The following physical specifications apply to the 8010 chassis. Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 97: Environmental Specifications

    The 8010 chassis conforms to the following international regulatory requirements: • "Electromagnetic emissions" (page 98) • "Electromagnetic immunity" (page 98) Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 98 CSA 22.2 No. 60950 Europe EN60950 (CE Marking) Australia/New Zealand AS/NZS 3260 Mexico NOM-019-SCFI-1998 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 99: 8006 Chassis

    95% maximum relative humidity, noncondensing Operating altitude 3048 m (10 000 ft) maximum Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 100: International Regulatory Requirements

    8006 electromagnetic immunity Parameter Specification Global basis for certification CISPR 24:1997 Europe EN 55024:1998 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 101: 8003 Chassis

    3 for each fan tray Thermal sensors 1 for each fan tray Noise 61 dBa maximum Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 102: Environmental Specifications

    EN 55022-1998 Class A; EN Europe 61000-3-2/A14, EN 61000-3-3 (CE Marking) Australia/New Zealand AS/NZS 3548:1995, Class A Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 103 CSA 22.2 No. 60950 Europe EN60950 (CE Marking) Australia/New Zealand AS/NZS 3260 Mexico NOM-019-SCFI-1998 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 104: Index

    72 ordering 31 chassis 18 components, described 19, 23 installing GBIC 79 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...

  • Page 105: Nortel Ethernet Routing Switch

    78 power specifications 26, 27 voltage specifications 26, 27 power supplies 24 Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 106 106 Index Nortel Ethernet Routing Switch 8600 Installing and Maintaining the Ethernet Routing Switch 8000 Series Chassis NN46205-303 01.02 Standard 4.1 10 January 2008 Copyright © 2008, Nortel Networks...
  • Page 108 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.

This manual is also suitable for:

8010co800380068010
