HEATING & COOLING
MULTIPOISE, CONDENSING
F U R N A N C
E
G A S
USER'S INFORMATION MANUAL FOR
THE OPERATION AND MAINTENANCE
OF YOUR NEW GAS-FIRED FURNACE
NOTE TO INSTALLER:
THIS MANUAL MUST BE LEFT WITH THE
EQUIPTMENT USER.
WARNING: If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
58MCA, 58MVP, 58MXA
Advertisement
Table of Contents
Related Manuals for Carrier 58MCA
Summary of Contents for Carrier 58MCA
- Page 1 MULTIPOISE, CONDENSING 58MCA, 58MVP, 58MXA ® HEATING & COOLING USER'S INFORMATION MANUAL FOR THE OPERATION AND MAINTENANCE OF YOUR NEW GAS-FIRED FURNACE NOTE TO INSTALLER: THIS MANUAL MUST BE LEFT WITH THE EQUIPTMENT USER. WARNING: If the information in this manual...
- Page 2 WELCOME TO A NEW GENERATION OF COMFORT Congratulations! In light of rising energy costs, the Weather- Maker ® 9200, 58MCA, and WeatherMaker Infinity, Mul- tipoise, Gas-Fired Condensing Furnaces are among the soundest investments today’s homeowner can make. Your new furnace is truly a triumph of technology in home heating.
-
Page 3: Furnace Components
Air filter and retainer. Condensate drain connection. Collects moisture condensed from burned gases for disposal into home drain system. MODELS 58MXA AND 58MCA Heavy-duty blower. Circulates air across the heat exchangers to transfer heat into the home. FURNACES (UPFLOW POSITION) Secondary condensing heat exchanger (inside). -
Page 4: Important Facts
IMPORTANT FACTS This furnace contains SAFETY DEVICES which must be MANUALLY RESET. If the furnace is left unattended for an Your gas furnace uses air from outside the home for com- extended period of time, have it checked periodically for bustion and venting. - Page 5 • If a suspected malfunction occurs with your gas control system, such as the burners not lighting when they should, refer to the shutdown procedures on the furnace, or in the section, “Shutting Down Your Furnace” and call your dealer as soon as possible.
-
Page 6: Shutting Down Your Furnace
When room temperature drops below the temperature selected on the thermostat, the furnace will be switched on automatically. When room temperature reaches the degree selected on the thermostat, the furnace will be switched off automatically. Some thermostats have a FAN switch with 2 selections, AUTO and ON. -
Page 7: Combustion Area And Vent System
FURNACE FILTER TABLE FURNACE CASING FILTER SIZE* FILTER WIDTH (IN.) (IN.) TYPE 17-1/2 (1) 16 x 25 x 1 Cleanable (1) 20 x 25 x 1 Cleanable 24-1/2 (2) 16 x 25 x 1 Cleanable * Furnace with a side return-air inlet may have a different filter size. Measure the filter to obtain the correct size. -
Page 8: Heading South For The Winter
CAUTION Do not use ethylene glycol (Prestone II antifreeze coolant or equivalent). Failure of plastic compo- nents will occur. DANGER If holes are found in the pipes or if any portion has become disconnected, toxic fumes can escape into your home. DO NOT OPERATE YOUR FUR- NACE. -
Page 9: Before You Request A Service Call
To decipher the meaning of the LED code, and suggested • Check thermostat for proper temperature. Is thermostat action, the following cross-reference can be used. set above room temperature? MODEL 58MCA and 58MXA DIAGNOSTIC CHART (See Fig. 3.) FAULT CODE... - Page 10 Have available the Model No., Series Letter & Serial No. of your equipment to insure correct replacement part. Carrier Corporation Syracuse, New York 13221 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations . Copyright 1994 Carrier Corporation Form: OM58-67 Replaces: OM58-61 Printed in the U.S.A.
