- Page 1 SIMATIC FM 354/FM 353 Getting Started 04/2007 Edition First Steps in Commissioning...
-
Page 2: Hardware And Software Requirements
This Guide uses a concrete example to guide you through 4 start-up steps in the order given below until you have obtained a functional application. You will then be able to traverse an axis and get to know and try out the basic hardware and software functions of your FM 354 or FM 353. The refer- ences to the Manual are intended to give you an initial overview of the information contained in the Manual. - Page 3 Follow step by step the instructions displayed by the installation routine. The software is installed in the following directories when the defaults are accepted: S “Parameterize FM 354” or “Parameterize FM 353” parameterization tool: “Siemens\Step7\S7FLAG or \S7FSTEP” S Function blocks: “Siemens\Step7\S7LIBS/FMSTSV_L” or “Siemens\Step7\S7LIBS/FM353_354”...
- Page 4 FM 354 When you click on button in the main window, a new Machine Data Data Block (DB-MD) is opened. The parameters of this DB-MD are set to defaults (“Machine Data” display). These defaults will enable you to traverse an axis if your system configuration is as follows: S Power section: SIMODRIVE 611-A S Motor: 1FT5 S Encoder: Rotary incremental encoder with 2,500 increments/rev...
- Page 5 Should an error occur during the test, you can reset the test run by selecting buttons Restart Ack- in the start-up window. You can read the error message with error number and error text by selecting menu items Test → Error Analysis or clicking on button Error Display...
- Page 6 After the CPU and FM 354 or FM 353 have powered up successfully, the following settings have been preset by block OB 100: S “Jog” mode with operating mode parameter BP = 1 (value of velocity level 1) S Override 100% S Servo enable set S Velocity levels: 40 m/min (level 1) and 80 m/min (level 2) You can monitor the status of the FM module in the main display or by selecting...
-
Page 7: Further Examples
Further examples The “zEn14_02_FM354_EX” or “zEn13_02_FM353_EX” project contains further helpful examples which you can adapt to your application. Note You should activate functions alarm generation, alarm selection and all monitors in normal opera- tion. You can set the alarm generation function on index card “Basic Parameters” in dialog “Properties − FM 354 SERVO −... - Page 8 Siemens AG utomation and Drives 90437 Nürnberg E Siemens AG 1998-2007 Federal Republic of Germany Subject to changes without prior notice Siemens Aktiengesellschaft...
