Summary of Contents for Philips 24HFL3014
- Page 1 User Manual 24HFL3014 32HFL3014 43HFL3014 50HFL3014...
-
Page 2: Table Of Contents
Contents 11.2 Open Source License 1 TV Tour 12 Help and Support 1.1 Professional Mode 12.1 On-line Help 2 Setting Up 12.2 Support and Repair 2.1 Read Safety 13 Safety and Care 2.2 TV Stand and Wall Mounting 13.1 Safety 3 Remote Control 13.2 Screen Care 3.1 Key overview... -
Page 3: Tv Tour
TV Tour Professional Mode What you can do In Professional Mode ON, you can have access to a large number of expert settings that enable advanced control of the TV’s state or to add additional functions. This mode is intended for installations of TV’s in places such as hotels, cruise ships, stadia or any other business area where such control is required. -
Page 4: Setting Up
• Make sure that the power plug, in the wall socket, is accessible at all times. • When you unplug the power cable, always pull the plug, never pull the cable. • 24HFL3014 VESA MIS-F 75x75, M4 (min.: 8mm, max.: 10mm) • 32HFL3014 VESA MIS-F 100, M6 (min.: 10mm, max.:14mm) •... - Page 5 Antenna Cable Insert the antenna plug firmly into the Antenna socket at the back of the TV. You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector. Use this antenna connection for DVB-T and DVB-C input signals.
-
Page 6: Remote Control
1 - EXIT To switch back to watching TV. Remote Control 2 - BACK • To switch back to the previous channel you selected. • To return to previous menu. Key overview 3 - OPTIONS To open or close the options menu. OK key To confirm a selection or setting. -
Page 7: Ir Sensor
IR Sensor The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV. -
Page 8: Switching On And Off
Keys on TV Switching On and If you lost the remote control or its batteries are empty, you can still do some basic TV operations. To open the basic menu… 1 - With the TV switched on, press the joystick key on On or Standby the back of the TV (only available for 32"... -
Page 9: Specifications
Environmental recycled and reused. European Energy Label Product Fiche 24HFL3014 When this crossed-out wheeled bin symbol is • Energy Efficiency Class : A+ attached to a product it means that the product is • Visible Screen Size : 60 cm / 24 inch covered by the European Directive 2012/19/EU. -
Page 10: Reception
Dimensions and Weights • 60 cm / 24 inch • 80 cm / 32 inch • 108 cm / 43 inch 24HFL3014 • 126 cm / 50 inch • without TV stand: Width 559.65 mm - Height 335.78 mm - Depth 54.1 mm - Weight ±... -
Page 11: Sound
Sound • Output power (RMS) : 2x3W (24"), 2x8W (32"/43"/50") • Dolby Audio • Digital 2.0+Digital Out... -
Page 12: Connect Devices
Copy protection Connect Devices HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu- ray Disc. Also referred to as DRM (Digital Rights Management). Connect Devices Connectivity Guide HDMI ARC Always connect a device to the TV with the highest... -
Page 13: Cam With Smart Card - Ci
Note: CAM with Smart Card - CI+ • EasyLink might not work with devices from other brands. • The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and This TV is ready for the CI+ Conditional Access . -
Page 14: Receiver - Set-Top Box
Connect with HDMI Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player. If the Home Theatre System has no HDMI ARC... -
Page 15: Headphones
Headphones Computer You can connect a set of headphones to Connect the connection on the back of the TV. The connection is a mini-jack 3.5mm. You can adjust the You can connect your computer to the TV and use volume of the headphones separately. - Page 16 Ideal Setting If you connect a computer, we advice you to give the connection, on which the computer is connected, the correct device type name in the Source menu. If you switch to Computer in the Source menu, the TV is set to the ideal Computer setting automatically.
-
Page 17: Videos, Photos And Music
menu - Favourites. Videos, Photos and To pause the video, press OK. Press OK again to continue. Music Control bar To show or hide the control bar when a video is playing, press OK. From a USB Connection You can view your photos or play your music and videos from a connected USB flash drive or USB Hard Drive. -
Page 18: Play Your Music
5 - Shuffle: play your files in a random order 6 - Repeat: plays all photos in this folder once or View your Photos continuously 7 - Stop the music playing in the background (Not View Photos available in Professional Mode ON) 8 - Set the speed of the slide show Open photo folder Professional Mode... - Page 19 Professional Mode On Press Home, select Sources . Choose Media Brower and press OK. Select Music and press OK. You can press Mark favourite to add the music folder to favourite menu - Favourites. You can quickly find a music using classification - Genres, Artists, Albums, Tracks.
-
Page 20: Tv Guide
TV Guide Using the TV Guide Open the TV Guide To open the TV Guide, press TV GUIDE. The TV Guide shows the channels of the selected tuner. Press TV GUIDE again to close. The first time you open the TV Guide, the TV scans all TV channels for programme information. -
Page 21: Home Screen
Channels Home Screen Channel Lists About the Home screen About Channel Lists After a channel installation, all channels appear on From the Home Screen, you can start any activity you the channel list. Channels are shown with their name can do with the TV. and logo if this information is available. -
Page 22: Features
Features Settings View TV utilities View settings offered To view the list of TV utilities To view the list of TV settings Select Home > Settings, and press OK. Select Home > Features, and press OK. - Picture Style - TV guide Select ... -
Page 23: Consumer Tv Home Screen
Consumer TV Home Screen 10.1 About the consumer TV Home Screen From the Consumer Home Screen, you can start any activity you can do with the TV. The Consumer Home Screen is organised in rows… 10.3 • Channels Language This row contains all channles. Change the language of the TV menu and - Press OK to open TV guide. - Page 24 3. Select Digital and analogue channels, Only digital Access Module for pay TV services, select Free + channels, or Only analogue channels. scrambled. If you did not subscribe to pay TV 4. Select Start and press OK to update channels. channels or services, you can select Free This can take a few minutes.
-
Page 25: Sources
Store Clock You can store the channel on the current channel number or as a new channel number. Display time on the corner of the TV screen. Select Store and press OK. The new channel number is shown briefly. You can redo these steps until you have found all Channel List available analogue TV channels. -
Page 26: Utilities
10.6 10.8 Utilities All Settings TV guide Picture Settings The TV Guide shows the channels of the selected Picture Style tuner. Channels Select a style View channel list. For easy picture adjustment, you can select a preset picture style. Update software ... - Page 27 (Home) > Settings > Picture > (Home) > Settings > Picture > Advanced > Colour > Colour enhancement Advanced > Contrast > Gamma Select Maximum, Medium, or Minimum to set the Press the arrows (up) or (down) to set a non- level of the colour intensity and the details in bright linear setting for picture luminance and contrast.
- Page 28 TV Placement Sound Settings (Home) > Settings > Sound > TV placement Sound Style Select On a TV stand or On the wall to have best Select a style sound reproduction according to the setting. For easy sound adjustment, you can select a preset sound style.
- Page 29 Digital Output Settings Eco Settings Digital output settings are available for optical and Set energy saving level HDMI ARC sound signals. (Home) > Settings > Eco settings > Energy Digital out fomat saving (Home) > Settings > Sound > Select Minimium, Medium, or Maximium to have Advanced >...
- Page 30 Enter PIN code and select Yes, the TV will reinstall HDMI-CEC Connection - EasyLink completely. All settings will be reset and installed Connect HDMI CEC-compatible devices to your TV, channels will be replaced. The installation can take a you can operate them with the TV remote few minute control.
- Page 31 (Home) > Settings > Universal Correct clock automatically access > Universal access > On. (Home) > Settings > Region and language > Clock > Auto clock mode - The standard setting for the TV clock is Automatic. Universal access for hearing impaired people The time information comes from the broadcasted ...
- Page 32 CAM PIN Update Software (Home) > Settings > Child lock > CAM PIN Search for Updates Set CAM PIN for recording. (Home) > Settings > Update software > Search for updates. You need a computer and a USB memory device to Antenna/cable installlation upload the software on the TV.
-
Page 33: Open Source
Source: http://www.denx.de/wiki/U-Boot Open Source vmlinux (3.1.10) 11.1 linux kernel Open Source Software Source: http://git.kernel.org/cgit/linux/kernel/git/stable/linux- This television contains open source software. TP stable.git Vision Europe B.V. hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source busybox (v1.23.2) software packages used in this product for which such offer is requested by the respective licences. - Page 34 freetype (2.5.3) openssl-0.9.8 (1.0.0) FreeType is a freely available software library to OpenSSL is a robust, commercial-grade, and full- render fonts. featured toolkit for the Transport Layer Security (TLS) and Secure Sockets Layer (SSL) protocols. Source: http://www.freetype.org/license.html Source: http://www.openssl.org/source/license.html libc (2.16) sqlite (3.7.11) The GNU C Library is used as the C library in the GNU systems and most systems with the Linux kernel.
- Page 35 icu (4.2.1) ICU is a mature, widely used set of C/C++ and Java libraries providing Unicode and Globalization support for software applications. Source: http://site.icu-project.org/home pixman (0.19.6) Pixman is a low-level software library for pixel manipulation, providing features such as image compositing and trapezoid rasterization.
-
Page 36: Help And Support
Help and Support 12.1 On-line Help To solve any Philips TV related problem, you can consult our online support. You can select your language and enter your product model number. Go to www.philips.com/support On the support site you can find your country's telephone number to contact us as well as answers to frequently asked questions (FAQs). -
Page 37: Safety And Care
TV to the wall or a suitable support. Contact Philips TV Consumer Care to have the TV - Teach children about the dangers of climbing on checked before use. -
Page 38: Screen Care
Low Temperatures If the TV is transported in temperatures below 5°C or 41°F, unpack the TV and wait until the TV temperature reaches room temperature before connecting the TV to the power outlet. Humidity In rare occasions, depending on temperature and humidity, minor condensation can occur on the inside of the TV glass front (on some models). -
Page 39: Terms Of Use
TP Vision is the warrantor in relation to the apparatus, in general have the ability to emit and TV with which this booklet was packaged. Philips and receive electromagnetic signals. One of TP Vision’s the Philips Shield Emblem are registered trademarks leading business principles is to take all necessary of Koninklijke Philips N.V. -
Page 40: Health Care Facility Apparatus
Health Care Facility Apparatus If this TV is intended for entertainment purposes for use in a hospital, a nursing home, a medical-care center, or a similar health-care facility in which installation is limited to a nonhazardous area, it must be installed wall-mounted or ceiling mounted. It is not intended for use in a critical-care area in which a patient is treated with an externalized electrical conductor, such as a probe, a catheter, or other... -
Page 41: Copyrights
16.4 Other Trademarks Copyrights All other registered and unregistered trademarks are 16.1 the property of their respective owners. HDMI The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 42: Index
Index Philips Support 36 Picture Clean 27 Advanced Picture Contrast Settings 27 Picture Contrast Mode 27 Advanced Picture Settings 26 Picture Format 27 Audio Description 31 Picture Style 26 Audio Effects 31 Picture, Colour 26 Audio Language 30 Picture, Contrast 26...
