Alcatel-Lucent 9966 Hardware Installation

Alcatel-Lucent 9966 Hardware Installation

Small cell gateway on atca platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Alcatel-Lucent
9966 SMALL CELL GATEWAY
Hardware Installation on ATCA Platform
Alcatel-Lucent – Proprietary
Use pursuant to applicable agreements

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent 9966

Summary of Contents for Alcatel-Lucent 9966

  • Page 1 Alcatel-Lucent 9966 SMALL CELL GATEWAY Hardware Installation on ATCA Platform Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 2 Copyright © 2012 Alcatel-Lucent. All rights reserved. Contains proprietary/trade secret information which is the property of Alcatel-Lucent and must not be made available to, or copied or used by anyone outside Alcatel-Lucent without its written authorization. Not to be used or disclosed except in accordance with applicable agreements.

  • Page 3: Table Of Contents

    How to comment xviii ..................................Safety and general information Overview ...................................... Structure of safety statements ............................... General hazard statements ..............................Basic safety aspects .................................. Product conformance statements Overview ...................................... Canada ......................................China ....................................................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 4 Contents ..............................................European Union ..................................United States ....................................Introduction to ATCAV2 platform Overview ...................................... ATCAV2 platform description Overview ...................................... Hardware platform overview ..............................BSR Gateway on ATCAV2 platform ..........................Hardware Component description Overview ...................................... ATCAV2 cards 3-10 ..................................Shelf manager 3-13 ..................................
  • Page 5 SC01 and SCE1 cabinet installation ..........................SAS chassis installation ................................Grounding the equipment Overview ...................................... Importance of grounding 7-10 ..............................7-11 External grounding of the SC01/SCE1 cabinet ......................Grounding the SAS 7-19 ..............................................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 6 Functional checks ..................................ATCA backplane zones ........................................Installing cage nuts ........................................Removing the chassis from the rack ........................................ESD Safety ........................................Final Checklists Overview ..................................... Using checklists ..................................General checklist ................................................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 7 Contents ..............................................Documentation checklist ............................... Grounding checklist ................................Wiring supplies checklist ............................... Cabinet checklist E-10 ..................................E-12 DC distribution panel checklist ............................Chassis checklist E-14 ..................................Glossary Index...
  • Page 8 ........................... LED checklist ................................General checklist ............................... Documentation checklist ............................Grounding checklist ..............................Wiring supplies checklist ............................Cabinet checklist E-10 ..............................DC distribution panel checklist E-12 ......................... Chassis checklist E-14 ............................................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 9 Power entry modules 3-19 ............................. 4-11 Max configuration in SC01 cabinet layout 4-11 ....................4-12 Max configuration in SCE1 cabinet layout 4-14 ....................Lifting equipment ..............................Lift eyes on cabinet top panel ........................................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 10 -48V Distribution in the SCE1 cabinet (from the fuses) 7-38 ................7-17 Wiring schematic of PDU to customer power unit 7-41 ..................7-18 H-tap connection between the PDU and power taps 7-43 ..............................................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 11 External power cabling for SC01 7-45 ........................7-21 External power cabling for SCE1 7-46 ........................ATCA zones ................................Cage nuts installation .............................. ESD strap terminals on the cabinet and SAV2AC shelves ............................................................xiii Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 12: About This Document

    General and specific safety information relevant to hardware installation.  Additional information relating to Advance Telecommunications Computing Architecture V2 (ATCAV2) based Alcatel-Lucent 9966 Small Cell Gateway interfaces, external cabling, cabinet layout and architecture.  Additional information relating to power supply cabling, excluding internal power wiring....

  • Page 13: New In This Release

    IP reference, IP number Related document that is referenced in the document Document support For support in using this or any other Alcatel-Lucent document, contact Alcatel-Lucent at one of the following telephone numbers: 1-888-582-3688 (for the continental United States) ...

  • Page 14: How To Order

    About this document ..............................................How to order To order Alcatel-Lucent documents, contact your local sales representative or use Online Customer Support (OLCS) (http://support.alcatel-lucent.com). How to comment To comment on this document, go to the Online Comment Form (http://infodoc. alcatellucent. com/comments/enus/) or e-mail your comments to the Comments Hotline (mailto:comments@alcatel- lucent.com).

  • Page 15: Safety And General Information

    Overview Purpose This chapter provides a generic overview of the standard hazard symbols and statements that are currently used in Alcatel-Lucent documentation, and which may appear in this document. Contents Structure of safety statements General hazard statements Basic safety aspects ..............................................

  • Page 16: Structure Of Safety Statements

    Describes the source of the risk of damage or injury Safety message Consequences if protective measures fail Avoidance message Protective measures to take to avoid the hazard Identifier The reference ID of the safety statement (optional) ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 17 Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Indicates a hazardous situation not related to personal injury..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 18: General Hazard Statements

    Electric-shock hazard Contact with energized parts can cause serious injury. Work on energized equipment is only permitted if you are using insulated connection terminals, are adequately trained and follow safe work practices..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 19 Cabinet eyebolts can break, severely damaging the cabinet, if a crane is used to lift the cabinet into an upright position. Ensure that the cabinet is in an upright position before transportation by crane..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 20 Lifting this equipment by yourself can result in injury due to the size and weight of the equipment. Always use three people or a lifting device to transport and position this equipment..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 21 Place modules removed from the equipment on a conductive surface.  Test or handle the module only with grounded tools on grounded equipment.  Handle defective modules exactly like new ones to avoid causing further damage. ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 22: Basic Safety Aspects

     Modifications to any part of the system, including software, must be conducted only by trained and qualified personnel and only in a manner as authorized by Alcatel-Lucent. Alcatel-Lucent disclaims liability for any damages arising from unauthorized modifications, and unauthorized modifications may lead to a voiding of any and all warranties....
  • Page 23 Operate the equipment only from the type of power source indicated on the marking label.  Ensure that the equipment is provided with a readily accessible disconnect device as part of the building installation. ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 24 DC supply circuit. The DC system must not be grounded elsewhere.  Ensure that no switching or disconnection devices are located in the equipment grounding conductor connected to the DC source grounding electrode conductor. ..............................................1-10 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 25: Product Conformance Statements

    However, in certain regions, contract terms determine which statements are required. The presence of a statement indicates that the product complies with that statement wherever it is required to do Contents Canada China European Union United States ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 26: Canada

    This equipment is intended for installation in restricted access locations, where access is controlled, or where access can only be gained by service personnel with an authorized mechanical or electronic access device. Access to this equipment is restricted to qualified service personnel only..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 27 Additionally, reuse, recovery, and/or recycling targets for the return and/or collection of the packaging waste may be established. For more information regarding collection and recovery of packaging and packaging waste within specific jurisdictions, contact the Alcatel-Lucent Environment, Health, and Safety organization ..............................................

  • Page 28: China

    Currently, the legislation requires all Electronic and Information Products (EIP) to comply with certain labeling and documentation requirements. Alcatel-Lucent products manufactured on or after 1 March 2007, that are intended for sale to customers in the China market, must comply with these requirements.

  • Page 29: Alcatel-Lucent - Proprietary

    Declaration of Conformity for equipment not in the scope of Directive 1999/5/EC Hereby, Alcatel-Lucent declares that the equipment documented in this publication is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC for EMC and Directive 2006/95/EC for safety requirements.
  • Page 30 Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel-Lucent products bearing the logo at the end of their useful life, or products displaced by Alcatel-Lucent equipment offers.

  • Page 31: United States

    1. This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Note: Changes or modifications not expressly approved by Alcatel-Lucent, Inc. could void the user's authority to operate the equipment.
  • Page 32 (888) 539-2783. Material content compliance The following notification applies to Alcatel-Lucent products distributed for sale, resale, or use. This product, part, or both may include a lithium-manganese dioxide battery, which contains very small amounts of a perchlorate substance. Special handling may apply.
  • Page 33 Hardware platform overview BSR Gateway on ATCAV2 platform Hardware Component description ATCAV2 cards 3-10 Shelf manager 3-13 Alarm board 3-14 Fillers 3-16 Cooling unit 3-17 Deflectors 3-18 ATCAV2 shelf power entry modules 3-19 ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 34: Introduction To Atcav2 Platform

    ATCAV2 platform description ..............................................ATCAV2 platform description Overview Purpose This section provides an introduction to the ATCAV2-based BSR Gateway and the hardware involved. Contents Hardware platform overview BSR Gateway on ATCAV2 platform ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 35: Overview

    The cabinet has dimensions of 2130 x 600 x 900 mm and weighs 163 kg. The cabinet is a steel enclosure with 2 doors and 2 removable side panels. The framework is a welded construction. The following image illustrates the RA44U9AA rack used: Figure 3-1 Cabinet overview ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 36: Parts List Of Atcav2 Chassis

    Parts list of ATCAV2 chassis Device/Mnemonic Description Weight SAV2AC ATCAV2 chassis with Alarm 17 kg board slot FALARM Alarm board for ATCAV2 0.5 kg chassis FMA10BB Malban10 Switch 2G 2.3 kg ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 37 0.1 kg MABAFBAA 3U Bottom deflector for 3.6 kg ATCAV2 chassis MABAFTAA 3U Top deflector for ATCAV2 2.8 kg chassis KMFT1 Front Cable tray 0.5 kg KMRT2 Rear Cable tray 0.5 kg ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 38: Front And Rear View Of Sava2Ac Chassis

    The following are the key features of the ATCAV2 platform: Consistent and fully integrated solution encompassing housing, switching, computing/IO blades and storage  Designed for cost effectiveness  Best in class computing performance ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 39 The following are the key benefits of the ATCAV2 platform: Highly cost-effective solution  Standard based  Open solution to ease Component Off The Shelf (COTS ) components integration  Powerful and flexible  Modular and scalable  Carrier grade ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 40: Bsr Gateway On Atcav2 Platform

    Domain Name Server/ Time of Day (DNS/ToD)  AAA proxy  Note: For information on how the Small Cell Gateway functionality is achieved in the ATCA cabinet, see Chapter 4, “Small Cell Gateway on the ATCAV2 platform” ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 41: Hardware Component Description

    This section describes the components of the ATCAV2-based BSR Gateway Contents ATCAV2 cards 3-10 Shelf manager 3-13 Alarm board 3-14 Fillers 3-16 Cooling unit 3-17 Deflectors 3-18 ATCAV2 shelf power entry modules 3-19 ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 42: Atcav2 Cards

    Two Hub cards or BGS boards, which are MALBAN10 cards.  Twelve Node cards or BGA boards, which are BONO cards. The following image illustrates a BGS board: Figure 3-3 MALBAN10 card ..............................................3-10 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 43: Bono Card

    Logical slot: This is a slot within the shelf defined by the Zone 1-hardware address. Each slot has a unique logical slot number. Logical slot numbers are used to determine channel mapping between slots. For more information on ATCA backplane zones, see Appendix A, “ATCA backplane zones” ..............................................3-11 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 44: Card Placement In The Front Slots

    Card placement in the slots (rear of the chassis) are as follows: Table 3-3 Card placement in the rear slots Physical Slot Description 01-06 Rear fillers 07-08 RTM of BGS boards for external connectivity 09-14 Rear fillers ..............................................3-12 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 45: Shelf Manager

    C connections, each shelf manager can supervise all shelf elements and the cards. The following image illustrates an ShMC card: Figure 3-6 SHMC card Note: The ShMC card used in ATCAV2 shelf for the Small Cell Solution is NBSHMC..............................................3-13 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 46: Alarm Board

    SAPDUAB Power Distribution Unit (PDU), or directly from the ATCAV2 shelf (in PDU-agnostic mode)  The Remote Alarm Panel (RAP), physically located in a separate room intended for Central Office supervision ..............................................3-14 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 47: Falarm Card

    Introduction to ATCAV2 platform Alarm board Hardware Component description ..............................................The following image illustrates the FALARM board: Figure 3-7 FALARM card ..............................................3-15 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 48: Fillers

    NAFILL: used to fill in unused RTM rear slots  FALFILL: used to fill in unused FALARM board front slot The following image illustrates the three kinds of fillers used: Figure 3-8 Fillers ..............................................3-16 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 49: Cooling Unit

    ..............................................Cooling unit Overview The cooling unit in the shelf consists of the fan trays and the dust filters. For more information on the cooling unit, “Cooling unit” (p. 6-4)..............................................3-17 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 50: Deflectors

    Deflectors Hardware Component description ..............................................Deflectors Overview The deflectors help in the circulation of air through the system. For more information on the cooling unit, see “Air-baffles requirement” (p. 6-8)..............................................3-18 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 51: Atcav2 Shelf Power Entry Modules

    The two-holes lugs of the SAV2AC PEMs can be mounted from right to left or from left to right, depending on the wiring selected. The following image illustrates the PEMs of the SAV2AC shelf: Figure 3-9 Power entry modules ..............................................3-19 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 52: Small Cell Gateway On The Atcav2 Platform

    This chapter describes the devices that are assembled in the ATCAV2 cabinet and the various site configurations possible. Contents Site configurations SC01 configuration 4-03 SCE1 configuration 4-05 ATCA Standalone Shelf (SAS) 4-07 ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 53: Site Configurations

    This section describes the site configurations for the product. All parts in this product can be assembled in two types of layouts, SC01 and SCE1 layout. In addition, this section also describes the ATCA Standalone Shelf (SAS). Contents SC01 configuration 4-03 SCE1 configuration 4-05 ATCA Standalone Shelf (SAS) 4-07 ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 54: Sc01 Configuration

    PDU. These devices can therefore be easily installed in the customer site, as required. Note: All components are arranged in bottom-to-top arrangement..............................................4-03 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 55: Max Configuration In Sc01 Cabinet Layout

    Small Cell Gateway on the ATCAV2 platform SC01 configuration Site configurations ..............................................The following image illustrates two different views of the SC01 configuration in the cabinet: Figure 4-11 Max configuration in SC01 cabinet layout ..............................................4-04 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 56: Sce1 Configuration

    SR7750 and Brick1200 is pre-wired and connected to the PDU. These devices can therefore be installed in the customer site, as required. Note: All components are arranged in bottom-to-top arrangement..............................................4-05 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 57: Max Configuration In Sce1 Cabinet Layout

    Small Cell Gateway on the ATCAV2 platform SCE1 configuration Site configurations ..............................................The following image illustrates two different views of the SCE1 configuration in the cabinet: Figure 4-12 Max configuration in SCE1 cabinet layout ..............................................4-06 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...

  • Page 58: Atca Standalone Shelf (Sas)

    Note: This configuration does not use the pre-installed PDU provided with the SC01 cabinet as the PDU type may vary..............................................4-07 Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
  • Page 59 Moving unpacking equipment Overview Purpose This chapter describes the guidelines to be followed when moving and unpacking equipment. Contents Lifting the equipment Unpacking equipment ..............................................Alcatel-Lucent – Proprietary Use pursuant to applicable agreements...
