Setup

Piano Assembly

Follow these instructions to assemble the
piano:
Note: You will need a Phillips-head (+)
screwdriver (not
appropriate size for assembly.
1. Use the 12 TA4*12 screws to attach
the 4 corner brackets to the left and
right piano corner panels.
3. Use the 4 M6*50 screws to connect
the left and right panels to the left and
right ground feet.
5. Use 4 of the M6*50 screws to
connect the left and right panels to the
pedal box; then connect the M6 screw
caps.
4
included) of the

Assembly Parts

1. (12) TA4*12 screws
2. (12) M6*50 screws
3. (4) M6*20 screws
4. (8) Hammer nuts
5. (4) Corner brackets
6. (8) M6 screw plastic caps
2. Press the 8 hammer nuts into the
corresponding holes on the left and
right corner panels and back panel.
4. Use the 4 M6*50 screws to connect
the left and right panels and back panel
together; then connect the M6 screw
caps.
6. Use 4 M6*20 screws to connect the
piano body to the piano brackets
