LCD Color TV
32A3500A
32A3500E
32A3500T
37A3500A
37A3500E
37A3500T
42A3500A
42A3500E
42A3500T
©2007 TOSHIBA CORPORATION
All Rights Reserved
M
ANUAL
Owner's Record
You will find the model number and serial number on
the back of the TV. Record these numbers in the spaces
provided below. Refer to them whenever you call upon
your TOSHIBA dealer regarding this product.
Model number:
Serial number:
VX1A00071900
