Integrated High Definition
LCD Television
40XF550U
46XF550U
52XF550U
For an overview of steps for setting up your new TV, see page 9.
Note: To display a High Definition picture, the TV must be receiving a
High Definition signal (such as an over-the-air High Definition TV
broadcast, a High Definition digital cable program, or a High Definition
digital satellite program). For details, please contact your TV antenna
installer, cable provider, or satellite provider.
© 2008 TOSHIBA CORPORATION
All Rights Reserved
HIGH-DEFINITION TELEVISION
Owner's Record
The model number and serial number are on the back of
your TV. Record these numbers in the spaces below.
Refer to these numbers whenever you communicate
with your Toshiba dealer about this TV.
Model number:
Serial number:
VX1A000885A0
YC/M
