Mackie Industrial SP800S Quick Start Manual

SP800S

Specifications

System
Freq. Range (–10 dB):
60Hz-220Hz
Freq. Response (±3 dB):
75Hz-190Hz
System Sensitivity:
91 dB, 1W@1m
Rated Maximum SPL:
112 dB @ 1 m (3.3 ft) peak
System Input Power Rating:
60W RMS, 240W Peak
Constant Voltage:
70V, 100V
Power Taps:
4, 7.5, 15, 30, 60W
Crossover: 220Hz, 12 dB per octave
Transducers
Low Frequency:
8" (200mm) carbon fiber woofer
Physical
Enclosure:
Rectangular MDF board construction
Attachment Inserts:
6 points M5 threaded
Color: Black or white (SP800SW) PVC covering
Input Connectors:
Terminal strip connector plate
Dimensions HxWxD:
23.82" x 13.82" x 7.87"
(605 mm x 351 mm x 200 mm)
Net Weight:
33 lb. (15.0 kg)
Options
Wall and ceiling vent grilles available
industrial@mackie.com
16220 Wood-Red Road NE Woodinville, WA 98072
TEL +888.337.7404, FAX +425.487.4337
UK +44.1268.570.808, FAX +44.1268.570.809 +industrial@rcf-uk.com
ITALY +39.0522.354.111, FAX +39.0522.332.294 +industrial@rcf.it
FRANCE +33.3.8546.9160, FAX +33.3.8546.9161 +industrial@rcf.fr
GERMANY +49.2572.96042.0, FAX +49.2572.96042.10 +industrial@mackie.de
Part No. 910-186-20 Rev. A 3/00
© 2000 Mackie Industrial. All Rights Reserved. Printed in the USA.
The SP800S is an innovative and compact
subwoofer designed for constant voltage,
parallel connection to a distributed system.
It is ideal for music reinforcement for business
applications. It can be flush-mounted into
standard framed wall, a drop ceiling, or
surface mounted on any flat surface.
The high-power transducer is a unique 8"
carbon fiber woofer.
Connections are made to a terminal strip
connector with a parallel input/output that
allows for easy daisy-chaining. A built-in
70V/100V transformer provides selectable
wattage taps.
The enclosure is constructed of MDF board
with six M5 threaded inserts that can be used
with a variety of optional installation hardware.

Safety First!

Before connecting and using the
equipment, please read this Quick-Start Guide
carefully and keep it for future reference.
WARNING! This equipment has been
designed to be installed by qualified
professionals only! There are many factors to
be considered when installing professional
sound reinforcement systems, including
mechanical and electrical considerations, as
well as acoustic coverage and performance.
Mackie Industrial strongly recommends that
this equipment be installed only by a
professional sound installer or contractor.
SP800S
Subwoofer Speaker
Quick-Start Guide
CAUTION: DO NOT USE
WITH 100V SETTING
SP800S
