Connection Sheet (LAN Connection)
System Setup
1
TV monitor**
3
Camera Unit
2
Microphone
PCS-A1**
PCSA-CG70/CG70P**
5
LAN cable**
6
AC adaptor
* supplied
** not supplied VGP-AC19V45 or
VGP-AC19V15*
2
3
Connect the
Connect the camera.
microphone.
Connect the Camera Unit and Communication
Terminal using the supplied camera cable.
Connect the microphone cable
to Communication Terminal.
Microphone
Communication
Terminal
When using only one camera, connect it to the
MAIN CAMERA connector. A second camera can
be connected to the SUB CAMERA connector.
© 2005 Sony Corporation Printed in Japan
4
Data Solution Box
PCSA-DSB1S**
Communication Terminal
PCS-PG70/PG70P
Remote Control
Plug adaptor*
Receiver*
LAN
• For connection examples using the Remote Control
Receiver and Plug adaptor, refer to the Operating
Instructions on the supplied CD-ROM.
• Both the Remote Control Receiver and the Camera Unit
can receive signals from the Remote Controller. When
Power cord*
both are connected at the same time, the Remote Control
Receiver receives the Remote Controller signals.
4
Connect the Data Solution Box.
Connect the Data Solution Box and Communication Terminal
using the cable supplied with the Data Solution Box.
Camera Unit
Camera cable
(supplied with the
Camera Unit)
Communication Used with the Data Solution Box for the first time, the
Terminal Communication Terminal may automatically upgrade the software of
the Data Solution Box. While the upgrading message is displayed on
the monitor screen, be sure not to turn off the Communication
Terminal. Doing so may cause malfunction of the system.
Video Communication System PCS-G70/G70P
3-869-384-14 (1)
Let's connect
Notes
• Be sure to turn off all the equipment
before making any connections.
• Do not connect/disconnect the camera
cable with the power on. Doing so may
damage the Camera Unit or
Communication Terminal.
5
Data Solution Box
Interface cable (supplied with
the PCSA-DSB1S)
Communication
Terminal
For safety, do not connect the 100BASE-TX/10BASE-T
connector to a network that applies an excess voltage
via the 100BASE-TX/10BASE-T connector.
** not supplied
1
Connect the TV monitor.
Connect the TV monitor and Communication Terminal
using the supplied audio cable and S-video cable.
AUDIO IN S-VIDEO IN
L R
TV monitor
Audio cable* S-video cable*
Communication
Terminal
* supplied
6
Connect the LAN cable. Connect the AC adaptor.
Connect the Communication Terminal to a Connect the supplied AC adaptor to the
LAN using a LAN cable (not supplied). Communication Terminal, and then plug the
power cord into a wall outlet.
Communication
Terminal
UTP cable
(category 5, straight)**
to LAN
to a wall outlet (120V AC)
* supplied
"IPELA" and
• When connecting a second or third
monitor, use the VIDEO OUT
MONITOR 2 or the RGB OUT
connector on the Communication
Terminal, or the RGB OUT
connector on the Data Solution
Box. For details, refer to the
Operating Instructions.
• The AUDIO OUT (MIXED) jack is
used to make an audio recording of
a conference. This is not used
during regular conferences.
Communication
Terminal
AC adaptor*
Power cord*
are trademarks of Sony Corporation.
