Bryant 559D Installation Instructions Manual

IMPORTANT — READ BEFORE INSTALLING
1. Read and become familiar with installation instruc-
tions before installing accessory economizer.
2. Be sure installation conforms to all local and national
codes.
SAFETY CONSIDERATIONS
Recognize safety information. This is the safety-alert symbol
( ). When you see this symbol on the unit and in instruc-
tions or manuals, be alert to the potential for personal
injury.
Understand the signal words — DANGER, WARNING and
CAUTION. These words are used with the safety-alert sym-
bol. Danger identifies the most serious hazards which will
result in severe personal injury or death. Warnings, on the
other hand, could result in personal injury. Caution is used
to identify unsafe practices which would result in minor per-
sonal injury or product and property damage.
WARNING: Before performing service or mainte-
nance operations on unit, turn off main power switch
to unit. Electrical shock could cause personal injury.
ITEM #
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
NOTE: If quantity of item is more than one, number of items is listed in parenthesis after the item
name. Example: Screw (16). See Fig. 1 for economizer details.
installation instructions
ACCESSORY INTEGRATED
ECONOMIZER
P/N 389041-201
Package Contents
ITEM NAME
Frame, Middle
Frame, Bottom
Frame, Top
Frame, Side
Frame, Side
Frame, Middle
Channel, End
Channel, Support
Channel, End
Blade, Damper (6)
Blade, Damper (2)
Thermistor
Screw (16)
Screw (2)
Bar
Bar
Rod, Linkage
Bracket, Sensor
Bearing (12)
Shaft (3)
Shaft (6)
Lever, Damper (5)
Screw, Hex Head (5)
Nut (5)
Pin (4)
Cotter Pin (4)
Washer (3)
Linkage (2)
Bushing, Snap (2)
Cancels: 40579DP426-B
INSTALLATION
WARNING: Turn off unit power! Electrical shock and
personal injury could result.
Install economizer damper assembly as follows:
1. If base unit is installed and in operation, turn off all
power to unit.
2. Remove filter access panel then remove 25% air/
economizer hood. See Fig. 2 and 11.
3. Remove and discard 25% outdoor-air damper section.
Save screws. See Fig. 3.
4. Remove and discard shorting plug located in left front
of return-air compartment and behind unit control box.
See Fig. 3.
5. Remove economizer damper assembly from shipping car-
ton. Remove economizer control box cover. See Fig. 4.
6. Slide economizer into unit opening as shown in Fig. 5.
ITEM #
32
33
34
35
36
37
38
39
40
41
42
44
46
47
49
50
52
54
55
56
57
58
59
60
61
542F, 559D,
579D, 599D
Cooling Sizes
150, 180 & 216
IIK 559D-150-1
3/2/92
ITEM NAME
Connector, Wire
Motor, Damper
Screw (40)
Screw (4)
Wire Tie (3)
Bolt, Capscrew (4)
Washer, Lock (4)
Washer, Plate (4)
Nut (4)
Control
Shaft
Shield
Seal Strip
Seal Strip (4)
Channel
Seal Strip (4)
Seal (4)
Switch, Temp
Plug Asy
Wire Asy
Wire Asy
Wire Asy
Wire Asy
Wire Asy
Wire Asy (2)
