READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
CONVECTION
CONSTRUCTION HEATER
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— An LP cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light appliance.
•
Extinguish any open flame.
•
Shut off gas to appliance.
— Service must be performed by a qualified service agency.
This is an unvented gas-fired portable heater. It uses air (oxygen) from the area in which it is used.
Adequate combustion and ventilation air must be provided. Refer to page 3.
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
Model #
MH25CVX
MH80CVX
MH200CVX
70486 - 2018 - CB
Advertisement
Table of Contents
Related Manuals for Mr. Heater MH80CVX
Summary of Contents for Mr. Heater MH80CVX
- Page 1 This is an unvented gas-fired portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion and ventilation air must be provided. Refer to page 3. MR. HEATER, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001 70486 - 2018 - CB...
-
Page 2: Table Of Contents
3.5-9.3 LBS/HR YouTube: There are now informational videos on YouTube. Consumption (.71kg/HR) (.74-1.8 kg/HR) (1.44-4.32 kg/HR) WEBSITE: Mr. Heater's full line of product are now at Hose Length 10' (304 cm) 10' (304 cm) 10' (304 cm) WWW.MRHEATER.COM Figure 1 VENTILATION: Minimum openings required... -
Page 3: Operating Precautions
8. IMPORTANT Use only the hose and regulator assembly OPERATING PRECAUTIONS provided with the heater. Match the color stripe on the hang tag attached to the hose assembly with the color on the This is a propane, direct-fired, convection heater. It's intended use is primarily temporary heating of buildings under construction, Inspect hose assembly before each use of the heater. -
Page 4: Odor Fade Warning
ODOR FADING - NO ODOR DETECTED • Some people cannot smell well. Some people cannot ODOR FADE WARNING smell the odor of the man-made chemical added to propane (LP) or natural gas. You must determine if you WARNING can smell the odorant in these fuel gases. Asphyxiation Hazard •... -
Page 5: Caution: Shell Extension Instructions
CAUTION: NEVER IGNITE AND / OR RUN THIS HEATER UNLESS THE SHELLS ARE FULLY EXTENDED AND LOCKED INTO POSITION. (Only for Models: MH80CVX, MH200CVX) STEP 2: LIFT OUTER SHELL STRAIGHT UP. CARE MUST BE TAKEN STEP 1: HEATER AS RECEIVED OUT OF BOX. BEFORE TO PROTECT HANDS DURING LIFT. -
Page 6: Operating Instructions
STOP (All UNITS) OPERATING INSTRUCTIONS Securely close valve on the propane cylinder. PREPARING FOR OPERATION Continue to operate heater until all fuel in the hose has Extend the shell fully and lock into place as shown in the burned. enclosed instructions sheet before lighting or operating the heater. -
Page 7: Size And Capacity Of Propane Cylinders Required
SIZE AND CAPACITY OF PROPANE CYLINDERS REQUIRED The charts below show the approximate size of the cylinder required for these heaters. To use the chart: Select the lowest air temperature expected (at the bottom 25CVX of the chart). Move straight up to time of operation desired (left side of chart). -
Page 8: 200Cvx - Parts
Exploded view and parts list MH200CVX REF # ITEM # Desc. 28590 Combustion Chamber top 200CV 28612 Combustion Chamber Upper 200CV 28613 Combustion Chamber Lower 200CV 28614 Heater Base 28597 Combustion Chamber Ring 28615 Burner Cone 28584 Burner Orifice Holder 28616 Burner Orifice 28617... -
Page 9: 80Cvx- Parts
Exploded view and parts list MH80CVX REF # ITEM # Desc. 28590 Combustion Chamber top 80CVX 28589 Combustion Chamber Upper 80CVX 28588 Combustion Chamber Lower 80CVX 28593 Heater Base 28597 Combustion Chamber Ring 28585 Burner Cone 28584 Burner Orifice Holder... - Page 10 Exploded view and parts list MH25CVX REF # ITEM # Desc. 28605 Combustion Chamber top 25CVX 28606 Combustion Chamber Upper 25CVX 28607 Heater Base 28608 Burner Venturi 28601 Igniter Electrode 28604 Retainer Nut 28600 Valve With Integrated Piezo Igniter 28602 Burner Orifice 28603 Orifice Holder...
-
Page 11: Instructions For Ordering Parts
***Page left intentionally blank*** Convection Construction Heater Operating Instructions and Owner’s Manual... -
Page 12: Warranty
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Mr. Heater, Inc., reserves the right to make changes at any time, without notice or obligation, in colors, specifications, accessories, materials and models.
