EM-70
Unpacking and Setup Instructions
Package Content
The EM-70 Series and its accessories
are packed in a cardboard carton with
foam padding for protection during
shipment. Carefully unpack the system
and keep the packing materials for
future use.
Verify that all of the items shown are
included in the box. If an item is
missing or appears to be damaged,
contact your Partner Tech dealer
immediately.
Product Overview
Status LED
Touch Screen
IC card reader
Charge the Battery
Connect the device using the AC adaptor.
Then plug the other end of the power
adaptor to the wall outlet to start
charging.
The status LED
lights red when
the battery
is charging.
Powering On the Tablet PC
Press and hold the Power button
until the status LED lights up.
RFID Antenna
Earphone
Power button
Volume buttons
Tablet PC (EM-70)
Strap eyelet
Module
Connectors
Slot
jack
USB port
Power jack
Reset pinhole
Connecting to Other Devices
Tablet PC
Earphone with microphone
USB cable
Speaker
Rear camera
Micro SD card slot
POGO pins
SIM card slot
SIM card
AC adaptor
QSG
Quick start guide
Strap eyelet
Micro SD card
Computer
