LCD DISPLAY LIGHT
Backlight button is used to illuminate the display when
it becomes too dark to see the display. The light will
remain on approximately 12 seconds after initiated or will
extinguish any other function be activated.
If an AC adapter is being used the LCD display will be
illuminated continuously while the radio is in operation.

SOFTWARE VERSION

The software display cannot be altered and is just for your
reference.
1.
Press and release the Standby button to ensure the
radio is off.

Specification

Power Requirements
Batteries
External Power Supply
Polarity Center
Dimensions in inches (W x H x D)
Weight in oz
Circuit Features
Speaker
Output Power
※ The barcode label on the product is defined as below:
The company reserves the right to amend the specifications without notice.
If at any time in the future you should need to dispose of this product please note that: Waste electrical products
should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice. (Waste Electrical and Electronic Equipment Directive).
2.
Press and release the Enter selection button then
the display shows your radio software information.

RESET SWITCH

The Reset Switch situated at the bottom of the receiver
case will reset the Time and Microprocessor only. All
memory presets will remain intact. Reprogram time in
accordance to earlier instructions.
DATA IN (A / B)
Data in A & B terminals next to reset switch which are for
factory data input and useless for users.
4 x UM3 (AA Size)
9V AC 700mA / Negative Polarity Center
7 3/4 x 5 1/4 x 1 1/2
28
3" / 8Ω / 3W
1W
Serial number
Production month
Production year
Product code
GB
F
E
NL
D
10
