Thule 220 Manual

Thule System Kit 220
HONDA Integra 4-dr, 94–
M A X
LOAD
60 Kg
6,5 Kg
IMPORTANT! As the distance
between the load bars is short, ski
boxes and surfboards should not be
fitted.
mm/inch
Screw the load carrier into position
alternating between the feet, and
maintaining constant pressure on
Front Rear
the bracket.
7
1
875 mm / 34 / inch 860 mm / 33 / inch
2 8
233 233
*
3
475 mm / 18 / inch
4
22
22
255
mm
10 inch
/ 501-0220
350•4DF
