- Page 1 NVIDIA RTX BLADE SERVER DU-09554-001 _v02 | September 2019 Installation Guide...
-
Page 2: Table Of Contents
2.1. Choosing a Setup Location / Site Preparation............4 2.2. Unpacking the RTX Blade Server............... 7 2.3. What's In the Box..................10 2.4. Installing the RTX Blade Server Into a Rack............10 2.4.1. Installing the Rails................. 10 2.4.2. Installing the Rack Shelf................13 2.4.3. Installing the Cage Nuts................14 2.4.4. Mounting the RTX Blade Server..............15... -
Page 3: Chapter 1. Introduction To The Nvidia Rtx Blade Server
Blade Server is a high-density GPU server consisting of 10 twin ™ blades, 20 CPU nodes and 40 NVIDIA Turing GPUs in an 8U form factor. The blade enclosure system provides all the power, cooling and I/O infrastructure needed to support a modular server design for graphical edge cloud applications like gaming and AR/VR. -
Page 4: Hardware Specifications
Introduction to the NVIDIA RTX Blade Server 1.1. Hardware Specifications 1.1.1. Components System Overview Component Description Blades Hot-pluggable. Each blade contains two independent nodes. Power Supply 5+5 redundancy 2200 W each. Management Module Chassis level BMC functionality (CMC/CMM). Aggregate 1Gb management port from each node to 2x 1Gb uplinks... - Page 5 Introduction to the NVIDIA RTX Blade Server Power Feature Specification Comment System Input 200-240 V (ac) The RTX Blade Server contains ten load-balancing power supplies, with 10 kW max. 5+5 redundancy Per Power Supply 2200 W @ 200-240 6 A, 50-60 Hz...
-
Page 6: Chapter 2. Installation And Setup
This chapter provides the basic instructions for installing and setting up the NVIDIA RTX Blade Server. 2.1. Choosing a Setup Location / Site Preparation Decide on a suitable location for setting up and operating the RTX Blade Server. The location should be clean, dust-free, and well ventilated. General Conditions ‣... - Page 7 Examine the power distribution units (PDUs) and cables present in the rack and ensure that ‣ they do not interfere with the installation of the RTX Blade Server, and ‣ they do not obstruct airflow to and around the server.
- Page 8 ‣ Power: ‣ The RTX Blade Server is powered through ten 1200W power supply units, each rated at 200-240VAC, 8A, 50/60 Hz. Total system power requirement: 7500W ‣ C19/C20 cables provided for each power supply to connect to a compatible PDU.
-
Page 9: Unpacking The Rtx Blade Server
‣ To use DHCP, connect the port to a local DHCP server which should provide an IP address and assign a DNS configuration to the RTX Blade Server. ‣ If DHCP is not available, then you will need to set up a static IP for each Ethernet port. - Page 10 Installation and Setup Cut through the tape and open the cardboard box flaps. Remove the wooden frames that support the box. Remove the cardboard box by pulling it straight up until it clears the system. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 8...
- Page 11 Remove the accessory and rail kit boxes. Preserve and retain packaging. Be sure to inspect each piece of equipment shipped in the packing box. If anything is missing or damaged, contact your supplier. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 9...
-
Page 12: What's In The Box
The following guidelines are provided to ensure your safety. • The RTX Blade Server should be mounted at the bottom of the rack if it is the only unit in the rack. - Page 13 Screw position for securing the rail onto the rack. Prongs that enter the holes of the rack. Holes can be square or round. Thread for securing the captive screw in the RTX Blade Server chassis to rack, assuming installed in a Type A rack.
- Page 14 Install one screw for each rail end. a) Install the flat head screws to the front by first pressing on the metal clip and then installing the screws on both left and right side rails. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 12...
-
Page 15: Installing The Rack Shelf
Once installed, it does not allow the system to be moved. All components are serviceable from the front or rear, so this movement is not necessary. https://www.racksolutions.com/downloads/dl/file/id/672/product/1783/ heavy_duty_fixed_shelf_installation_instructions.pdf for instructions on installing the rack shelf. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 13... -
Page 16: Installing The Cage Nuts
Installation and Setup 2.4.3. Installing the Cage Nuts The RTX Blade Server is secured to the rack using four captive screws - one at each corner of the front of the unit. ‣ If your rack has round holes with 10-32 threads, then the screws will attached directly to the rack mounting holes. -
Page 17: Mounting The Rtx Blade Server
Caution Stability hazard — The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before you slide the RTX Blade Server out for servicing. Failure to stabilize the rack can cause the rack to tip over. - Page 18 Remove the supporting foam from both sides. c) Move the lift towards the unit so that the lift platform fits below the unit but above the cardboard. Free the RTX Blade Server from the packaging. www.nvidia.com NVIDIA RTX Blade Server...
- Page 19 Finish pushing the system into the rack until the ears are flush with the rack posts. Complete the installation by tightening the four captive screws on the front of the RTX Blade Server to secure the unit to the rack. www.nvidia.com NVIDIA RTX Blade Server...
-
Page 20: Connecting The Cables
NVIDIA recommends connecting only one of the Ethernet ports to your LAN. If you are connecting both Ethernet ports, each port must be connected to separate networks, The RTX Blade Server is not configured from the factory to have multiple Ethernet interfaces on the same network. -
Page 21: Chapter 3. Customer Support For The Nvidia Rtx Blade Server
Chapter 3. CUSTOMER SUPPORT FOR THE NVIDIA RTX BLADE SERVER There are several options for contacting NVIDIA Customer Support for assistance reporting, troubleshooting, or diagnosing problems with your RTX Blade Server. NVIDIA Enterprise Support Portal The best way to file an incident is to log on to NVIDIA Enterprise Services (https://nvid.nvidia.com/dashboard/). -
Page 22: Chapter 4. Safety
Indicates the presence of a hazard that may result in serious personal injury if the WARNING is ignored. Indicates potential hazard if indicated information is ignored. Indicates shock hazards that result in serious injury or death if safety instructions are not followed www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 20... -
Page 23: Intended Application Uses
‣ Provided with a properly grounded wall outlet. ‣ Provided with sufficient space to access the power supply cord(s), because they serve as the product's main power disconnect. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 21... -
Page 24: Equipment Handling Practices
Caution: To avoid electrical shock or fire, check the power cord(s) that will be used with the product as follows: ‣ The power cord must have an electrical rating that is greater than that of the electrical current rating marked on the product. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 22... -
Page 25: System Access Warnings
The equipment rack must be anchored to an unmovable support to prevent it from tipping when a server or piece of equipment is extended from it. The equipment rack must be installed according to the rack manufacturer's instructions. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 23... -
Page 26: Electrostatic Discharge
After removing a board from its protective wrapper or from the server, place the board component side up on a grounded, static free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide board over any surface. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 24... -
Page 27: Other Hazards
NICKEL NVIDIA Bezel: The bezel’s decorative metal foam contains some nickel. The metal foam is not intended for direct and prolonged skin contact. Please use the handles to remove, attach or carry the bezel. While nickel exposure is unlikely to be a problem, you should be aware of the possibility in case you’re susceptible to nickel-related reactions. - Page 28 Safety ‣ Attach the covers to the chassis according to the product instructions. www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 26...
-
Page 29: Chapter 5. Compliance
Chapter 5. COMPLIANCE The NVIDIA RTX Blade Server is compliant with the regulations listed in this section. 5.1. United States Federal Communications Commission (FCC) FCC Marking (Class A) This device complies with part 15 of the FCC Rules. Operation is subject to the following... -
Page 30: Canada
RoHS Directive for hazardous substances. ‣ Energy-related Products Directive (ErP). A copy of the Declaration of Conformity to the essential requirements may be obtained directly from NVIDIA GmbH (Floessergasse 2, 81369 Munich, Germany). 5.5. Australia and New Zealand Australian Communications and Media Authority www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 28... -
Page 31: Russia/Kazakhstan/Belarus
Voluntary Control Council for Interference (VCCI) This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take corrective actions. VCCI-A www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 29... - Page 32 A Japanese regulatory requirement, defined by specification JIS C 0950, 2008, mandates that manufacturers provide Material Content Declarations for certain categories of electronic products offered for sale after July 1, 2006. To view the JIS C 0950 material declaration for this product, visit www.nvidia.com. Japan RoHS Material Content Declaration www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 30...
-
Page 33: China
Compliance 5.8. China China RoHS Material Content Declaration www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 31... -
Page 34: South Korea
Compliance 5.9. South Korea Korean Agency for Technology and Standards (KATS) www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 32... - Page 35 Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except for home. Korea RoHS Material Content Declaration www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 33...
- Page 36 Compliance www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 34...
-
Page 37: Taiwan
Compliance 5.10. Taiwan Bureau of Standards, Metrology & Inspection (BSMI) www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 35... - Page 38 Compliance www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 36...
- Page 39 Compliance www.nvidia.com NVIDIA RTX Blade Server DU-09554-001 _v02 | 37...
- Page 40 LIFE CRITICAL APPLICATION). NVIDIA EXPRESSLY DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR SUCH HIGH RISK USES. NVIDIA SHALL NOT BE LIABLE TO CUSTOMER OR ANY THIRD PARTY, IN WHOLE OR IN PART, FOR ANY CLAIMS OR DAMAGES ARISING FROM SUCH HIGH RISK USES.
